Excel Airide B-Ace User Manual page 23

22
Specifications
Overall length with leg rests
Total width 14 "rear wheels
Total weight without batteries
Batteries 50 Ah (C20) (Set of 2)
Batteries 75 Ah (C20) (Set of 2)
Leak-free drive wheels (set of 2)
Electric backrest adjustment;
Electric height adjustment 30 cm;
Combined electrically adjustable
height 30 cm / adjustable tilt-in-
space 45 degrees;
Electric adjustable tilt-in-space 0-
25 degrees;
Combined electrically adjustable
height 30 cm / adjustable tilt-in-
space 30 degrees;
Electrical length compensation
elevating leg rest
Static stability:
Backward-
Up
Sideways
Turning distance
Range* with 50 Ah batteries *
Range * 75 Ah batteries
Grade ability obstacles (outside)
Maximum speed forward
Maximum speed backward
Seat angle adjustment
effective seat depth
effective seat width
Seat height (pillow) **
Seat height (including pillow) **
back angle
back height
Lower leg length
Maximum safe slope
* The following aspects influence the action radius negatively: obstacles, rugged terrain, driving on slopes,
temperatures below freezing point, and the frequent use of options. The range will be 10% lower in these
conditions.
** Seat height including tax, seat angle.
Excel Airide
FWD RWD
1190mm 1115mm
655 mm
73 kg
29.6 kg
45.8 kg
8.4 kg
9.8 kg
9.8 kg
18.8 kg
9.8 kg
18.8 kg
4 kg
15º
15º
15º
1200 mm 1330 mm 1880mm 2010mm 1880mm 2010mm
20 km
30 km
60 mm 80 mm
6 - 10 km/u
5 km/u
0-6 º
420 – 600 mm
420 – 540 mm
415 mm
485 mm
89 – 118º
500 – 640 mm
350 – 515 mm
8º (14,1%)
Airide Go! Airide Compact
FWD RWD FWD
1190mm 1115mm 1190mm 1115mm
800 mm 800 mm
73 kg 73 kg
29.6 kg 29.6 kg
x x
8.4 kg 8.4 kg
9.8 kg 9.8 kg
9.8 kg 9.8 kg
18.8 kg 18.8 kg
9.8 kg 9.8 kg
18.8 kg 18.8 kg
4 kg 4 kg
15º 15º
15º 15º
15º 15º
20 km 20 km
x x
60mm 80mm 60mm
6 km/u 6 km/u
5 km/u 5 km/u
0-6 º 0-6 º
420 – 600 mm 420 – 600 mm
420 – 540 mm 420 – 540 mm
390 mm 390 mm
460 mm 460 mm
89 – 118º 89 – 118º
500 – 640 mm 500 – 640 mm
350 – 515 mm 350 – 515 mm
8º (14,1%) 8º (14,1%)
RWD
80mm
