TriangleTube instinct SOLO 110 Application Manual

Hide thumbs Also See for instinct SOLO 110:

Advertisement

Quick Links

Download this manual
Application
Guide
SOLO 110 - 155 - 199 & COMBI 155 - 199
•
This manual is applicable to all Instinct boilers with AA or no letter in the serial number after the S or C (e.g. IN110SAA000001).
•
If this guide does not apply to your boiler, Please visit triangletube.com to obtain the correct application guide.
This document is intended to be used by a
factory trained and qualified heating contractor
or service technician only. Read all Instructions
within this document and within the relevant
Boiler Installation and Maintenance Manual
before proceeding. It is recommended to follow
•
When receiving the Instinct unit, any claims for damage or shortage in shipment must be filed immediately against the
transportation company by the consignee.
•
Customer must register unit within sixty (60) days of installation in order to gain warranty coverage. See Warranty Card for
details.
•
Leave all documentation received with appliance with the owner for future reference.
•
Installation and service should only be performed by a qualified installer or service technician.
•
Installations and service should be performed by a licensed plumber or gas fitter in the Commonwealth of Massachusetts.
2020-52 – Instinct WHB Application
Guide AA or no letter in Serial No.
after S or C
October 4, 2021
NOTICE
WARNING
the procedures in the steps given. Skipping
or missing procedural steps could result in
substantial property damage, serious injury, or
death.
NOTICE
T H E
O R I G I N A L
I N N O V AT O R S

Advertisement

loading
Need help?

Need help?

Do you have a question about the instinct SOLO 110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TriangleTube instinct SOLO 110

Summary of Contents for TriangleTube instinct SOLO 110

  • Page 1 This manual is applicable to all Instinct boilers with AA or no letter in the serial number after the S or C (e.g. IN110SAA000001). • If this guide does not apply to your boiler, Please visit triangletube.com to obtain the correct application guide. WARNING This document is intended to be used by a the procedures in the steps given.
  • Page 2 Instinct Application Guide Sections Flexible Pump Configuration ..................... 3 Pump Selection ......................5 Instinct Solo Piping Diagrams ..................... 6 Instinct Combi Piping Diagrams ..................13 Figures Fig. 1: Installer Button ....................... 3 Fig. 2: Installer Access Code ....................3 Fig. 3: CH & DHW Settings ....................3 Fig.
  • Page 3 Instinct Application Guide 1. Flexible Pump Configuration 3. Press the OK button while the CH & DHW Settings icon is highlighted. This allows the installer to customize the flexible Pump Output (relays) to a specific installation arrangement that is not addressed in the Preset Pump Configuration options.
  • Page 4 Instinct Application Guide 7. A list of 6 Flex Relays are clickable. These are the 9. Once the Relay's actions have been selected, scroll down and hit enter on the Save and Exit option Boiler actions to be edited. at the bottom. This relay shown in Fig. 8 is set to turn on the pump wired to the CH1 terminal only for CH1 calls.
  • Page 5 Instinct Application Guide 2. Pump Selection Refer to Table 1 for the Boiler pump recommendations when using primary secondary piping. Table 1: Instinct Solo Pump Requirements Model Heating Temperature Required Minimum Minimum Boiler Pump Size Boiler Pipe Capacity Rise Boiler Flow Size Grundfos Taco...
  • Page 6 Instinct Application Guide 3. Instinct Solo Piping Diagrams Fig. 10: Instinct Solo Near Boiler Piping with Closely Spaced Tees Fig. 11: Instinct Solo Near Boiler Piping with Hydraulic Separator...
  • Page 7 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump OFF → ON* * A custom pump setting is required via flexible pump configuration Fig. 12: Instinct Solo - Multiple Zones with Circulators NOTICE Piping layout is shown with a Hydraulic Separator. Closely spaced tees and an air separator can be used as shown in Fig. 10 on page 6.
  • Page 8 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump Note. Instinct Solo is pre-configured for this installation Fig. 13: Instinct Solo - Multiple Zones with Circulators - Domestic Piping Alternate NOTICE Piping layout is shown with a Hydraulic Separator. Closely spaced tees and an air separator can be used as shown in Fig. 10 on page 6.
  • Page 9 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump OFF → ON* * A custom pump setting is required via flexible pump configuration Fig. 14: Instinct Solo - Piping with Zone Valves NOTICE Piping layout is shown with a Hydraulic Separator. Closely spaced tees and an air separator can be used as shown in Fig. 10 on page 6.
  • Page 10 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump Note. Instinct Solo is pre-configured for this installation Fig. 15: Instinct Solo - Piping with Zone Valves - Domestic Piping Alternate NOTICE Piping layout is shown with a Hydraulic Separator. Closely spaced tees and an air separator can be used as shown in Fig. 10 on page 6.
  • Page 11 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump OFF → ON* * A custom pump setting is required via flexible pump configuration Fig. 16: Instinct Solo - Piping with Zone Valves and Zone Valve Control Panel NOTICE Piping layout is shown with a Hydraulic Separator.
  • Page 12 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump Note. Instinct Solo is pre-configured for this installation Fig. 17: Instinct Solo - Piping with Zone Valves and Zone Valve Control Panel - Domestic Piping Alternate NOTICE Piping layout is shown with a Hydraulic Separator.
  • Page 13 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump OFF → ON* * A custom pump setting is required via flexible pump configuration Fig. 18: Instinct Solo - Single Zone with Circulator NOTICE Piping layout is shown with a Hydraulic Separator. Closely spaced tees and an air separator can be used as shown in Fig. 10 on page 6.
  • Page 14 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump Note. Instinct Solo is pre-configured for this installation Fig. 19: Instinct Solo - Single Zone with Circulator - Domestic Piping Alternate NOTICE Piping layout is shown with a Hydraulic Separator. Closely spaced tees and an air separator can be used as shown in Fig. 10 on page 6.
  • Page 15 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump ON→ OFF* OFF → ON* * A custom pump setting is required via flexible pump configuration Fig. 20: Instinct Solo - Multiple Temperature Zones with Circulators NOTICE Piping layout is shown with a Hydraulic Separator.
  • Page 16 Instinct Application Guide Instinct Solo Pump Configuration Heat Call Flame CH Pump DHW Pump ON→ OFF* * A custom pump setting is required via flexible pump configuration Fig. 21: Instinct Solo - Multiple Temperature Zones with Circulators - Domestic Piping Alternate NOTICE Piping layout is shown with a Hydraulic Separator.
  • Page 17 Instinct Application Guide Fig. 22: Instinct Solo - Cascade Layout...
  • Page 18 Instinct Application Guide 4. Instinct Combi Piping Diagrams Fig. 23: Instinct Combi Near Boiler Piping with Timesaver Manifold Fig. 24: Instinct Combi Near Boiler Piping with Hydraulic Separator...
  • Page 19 Instinct Application Guide Instinct Combi Pump Configuration Heat Call Flame CH Pump DHW Pump Note. Instinct Combi is pre-configured for this installation Fig. 25: Instinct Combi - Multiple Zones with Circulators NOTICE Piping layout is shown with a Hydraulic Separator. The Timesaver manifold (INSRKIT84) and air separator can be used as shown in Fig.
  • Page 20 Instinct Application Guide Instinct Combi Pump Configuration Heat Call Flame CH Pump DHW Pump Note. Instinct Combi is pre-configured for this installation Fig. 26: Instinct Combi - Single Zones with Circulator NOTICE Piping layout is shown with a Hydraulic Separator. The Timesaver manifold (INSRKIT84) and air separator can be used as shown in Fig.
  • Page 21 Instinct Application Guide Instinct Combi Pump Configuration Heat Call Flame CH Pump DHW Pump ON → OFF * OFF → ON* ON → OFF * * Custom pump settings are required via flexible pump configuration Fig. 27: Instinct Combi - Multiple Temperature Zones with Circulators NOTICE Piping layout is shown with a Hydraulic Separator.
  • Page 22 Instinct Application Guide Instinct Combi Pump Configuration Heat Call Flame CH Pump DHW Pump Note. Instinct Combi is pre-configured for this installation Fig. 28: Instinct Combi - Multiple Zones with Zone Valves NOTICE Piping layout is shown with a Hydraulic Separator. The Timesaver manifold (INSRKIT84) and air separator can be used as shown in Fig.
  • Page 23 Instinct Application Guide Instinct Combi Pump Configuration Heat Call Flame CH Pump DHW Pump Note. Instinct Combi is pre-configured for this installation Fig. 29: Instinct Combi - Multiple Zones with Zone Valves and Zone Valve Control Panel NOTICE Piping layout is shown with a Hydraulic Separator. The Timesaver manifold (INSRKIT84) and air separator can be used as shown in Fig.
