FIT SERIES
LEG CURL/EXTENSION
ASSEMBLY INSTRUCTIONS
Part # 7488801
1
Revision:5/06/03
Rev A.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FIT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Life Fitness FIT Series

Summary of Contents for Life Fitness FIT Series

  • Page 1 FIT SERIES LEG CURL/EXTENSION ASSEMBLY INSTRUCTIONS Part # 7488801 Revision:5/06/03 Rev A.

  • Page 2: Parts List

    PARTS LIST DESCRIPTION PART # DESCRIPTION PART # TOWER ACU04-1651 ACU06-0375 3/8 X 3” NYLON SPACER ADJUST PLATE ACU02-1329 ACU06-0396 3/8 X 4” NYLON SPACER PEDESTAL ACU04-1372 ACU05-0312 5/16 X 1/2” SHOULDER BOLT HANDLE ACU04-1374 3/8 X 32mm BOLT ACUDA1C03803216NU LEG CURL/EXT BACK ACU04-1373 ACUDA1C03804316NU...
  • Page 3 32 3/8 X 32mm BOLT 3/8” LOW HEIGHT LOCK 33 3/8 X 43mm BOLT 3/8” SAE WASHER 34 3/8 X 67mm BOLT 35 3/8 X 82mm BOLT 3/8” BLACK FLAT WASHER 36 3/8 X 90mm BOLT RH CAP 37 3/8 X 97mm BOLT (WHITE/PLATINUM/BLACK) 1/2”...
  • Page 4 38 3/8 X204mm BOLT 39 3/8 X 25mm BUTTON HEAD BOLT 52 3/8 X 90mm BUTTON HEAD BOLT 40 3/8 X 203mm BUTTON HEAD BOLT 31 5/16 X1/2” SHOULDER BOLT 3/8 X 1” SPACER Bolt Length Ruler NOTE: BOLT LENGTH IS MEASURED FROM THE UNDERSIDE OF THE HEAD OF THE BOLT. BOLT LENGTH...
  • Page 5 3/8 X 90mm 36 FIGURE 1 STEP 1: • LOOSELY assemble the BASE (8) to the FRAME (7) and TOWER (1) using eight RH CAPS (46), four 3/8 X 90mm BOLTS (36), eight 3/ 8” SAE WASHERS (43), eight 3/8” RH WASHERS (44) and four 3/8” LOW HEIGHT LOCK NUTS (42) as shown in FIGURE 1.
  • Page 6 3/8 X 67mm 34 FIGURE 2 STEP 2: • LOOSELY assemble the UPPER SUPPORT (9) to the FRAME (7) and the TOWER (1) using eight RH CAPS (46), four 3/8 X 67mm BOLTS (34), eight 3/8” SAE WASHERS (43), eight 3/8” RH WASHERS (44) and four 3/8” LOW HEIGHT LOCK NUTS (42) as shown in FIGURE 2.
  • Page 7 TIGHTEN! TIGHTEN! FIGURE 4 STEP 4: • Securely tighten all loose frame connections made to this point, then proceed to snap RH CAPS (46) over the RH WASHERS (44) on all tightened connections.
  • Page 8 BLACK 36 3/8 X 90mm FIGURE 5 37 3/8 X 97mm STEP 5: • SECURELY assemble the LEG CURL/EXT SEAT (6) to the FRAME (7) using two RH CAPS (46), one 3/8 X 97mm BOLT (37), two 3/8” SAE WASHERS (43), two 3/8” RH WASHERS (44), and one 3/8” LOW HEIGHT LOCK NUT (42) as shown in FIGURE 5. (NOTE: Tighten connections enough to remove play, yet allowing the part to rotate freely.) •...
  • Page 9 BLACK 26 38 3/8 X 204mm 45 BLACK 40 3/8 X 203mm FIGURE 7 BUTTON HEAD STEP 7: • SECURELY assemble one 3/8 X 4” NYLON SPACER (30) between the bushings on the LEG CURL/EXT BACK (5) using one 3/8 X 203mm BUTTON HEAD BOLT (40) and one 3/8”...
  • Page 10 3/8 X 97mm 37 FIGURE 9 STEP 9: • SECURELY assemble the PEDESTAL (3) to the FRAME (7) using four RH CAPS (46), two 3/8 X 97mm BOLTS (37), one 3/8 X 3” NY- LON SPACER (29), four 3/8” SAE WASHERS (43), four 3/8” RH WASHERS (44) and two 3/8” LOW HEIGHT LOCK NUTS (42) as shown in FIGURE 9.
  • Page 11 34 3/8 X 67mm FIGURE 11 STEP 11: • Route the LEG CURL/EXT CABLE (47) through the TOWER (1) as shown, and SECURELY assemble two 4-1/2” PULLEYS (16) to the TOWER (1) using two 3/8 X 67mm BOLTS (34), four 3/8 X 1/2” FLANGE SPACERS (28) and two 3/8” LOW HEIGHT LOCK NUTS (42).
  • Page 12 LUBRICATION NOTE: When finished assembling the Weight Stack, open the lube Pack provided with this unit and apply a thin film of Lubricant around the first 2 to 3 inches of each Guide Rod above the Head Plate Assembly. After the cables are installed, use of the ma- chine will spread the lubricant over the length of the Guide Rods and into the...
  • Page 13 34 3/8 X 67mm TIGHTEN! FIGURE 13 STEP 13: • Route the threaded end of the LEG CURL/EXT CABLE (47) through the GUIDE ROD SUPPORT (14) and SECURELY assemble the GUIDE ROD SUPPORT (14) to the TOWER (1) using two 3/8 X 67mm BOLTS (34), four 3/8” FLAT WASHERS (54) and two 3/8” LOW HEIGHT LOCK NUTS (42) as shown in FIGURE 13.
  • Page 14 33 3/8 X 43mm 33 3/8 X 43mm FIGURE 14 STEP 14: • Route the LEG CURL/EXT CABLE (47) through the vertical bracket on the BASE (8) and SECURELY assemble one 4-1/2” PULLEY (16) to the bracket using two RH CAPS (46), one 3/8 X 43mm BOLT (33), two 3/8” SAE WASHERS (43), two 3/8” RH WASHERS (44) and one 3/8”...
  • Page 15 ADJUSTMENT FIGURE 16 STEP 16: • Adjustments can be made in the above locations to set the correct amount of tension in the cables. • If upon completion of assembly, the HEAD PLATE (22) does not sit on top of the first WEIGHT PLATE (20), push the HEAD PLATE (22) down, insert the WEIGHT STACK PIN (23) and perform several repetitions.
  • Page 16 BOLTS (52), twenty 3/8” BLACK FLAT WASHERS (41) and ten 3/8” ACORN NUTS (53) as shown above. Thank you for purchasing the LifeFitness FIT SERIES LEG CURL/EXTENSION. If unsure of proper use of equipment, call your local LifeFitness distributor or call the LifeFitness customer service department at...

  • Page 17: Warranty Information

    • Lube the Guide Rods. Apply the lubricant to a cotton cloth, then run the cotton cloth up and down the guide rods as needed. Do not spray lubricant directly on the Guide Rods. Thank you for purchasing the LifeFitness FIT SERIES CURL/EXTENSION. If unsure of proper use of equipment, call your local LifeFitness distributor or call the LifeFitness customer service department at...
