Type 2 - Directed MIT4 Firmware Specific Manual

Directed digital system
Table of Contents

Advertisement

Type 2

Refer to "Vehicle wiring reference charts" on page 11 for more information on vehicle-specific connections.
For Manual Transmission ONLY
Relay pin 30
Relay pin 87a
Cut
Clutch:
Brown/Black,
pin 2
87
85
1
87a
86
30
Clutch
Pedal
(+) Ignition: Red or
Black/White, pin 2
(+) 12V:
White, pin 1
1
2
3
Ignition Switch Connector
4
5
6
(left side of steering column)
(+) Starter:
Black/Yellow,
pin 5
(+) Accessory 1:
Blue/Red, pin 4
Junction Block
rear view
(Driver Kick Panel)
The siren is only compatible with hybrid systems.
[1]
The green wire is only required for starter kill and antigrind connections.
[2]
All adapters are displayed from the wire side (unless specified otherwise).
8
Junction Block
front view
C-204 White Connector
(Front of Junction Block
at Driver Kick Panel)
C-204
15
14
13
11
10
9
12
7
6
5
4 3 2 1
(-) Driver Door Trigger:
2
Lt. Green, pin 6
(+) Starter Output (Car Side): Violet: 8
Starter Input (Key Side): Green: 7
[2]
(+) 12V Input: Red: 6
(+) Accessory 1 Output: Orange: 5
(+) 12V Input: Red: 4
(+) Ignition Input/Output: Pink: 3
(+) Accessory 2 Output: Orange: 5
(+) Accessory 2:
Blue/Black, pin 6
(-) Lock:
(-) Unlock:
Violet/White
Lt. Green/Red,
or Violet, pin 13
pin 14
1
2
3
4
5
6
7
8 9
10 11 12
13
14
15
16 17 18
19 20 21
22 23 24
C-219 White 24-pin Connector
(Rear of Junction Block.
at Driver Kick Panel)
HS CAN High: Red, pin 6
1
8
9
16
HS CAN Low: Black, pin 14
8
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
(-) Auto Headlamp Shutoff: Green/Black: 10
MC501
Hood Pin
(-) Hood Input: Gray: 3
(-) Unlock Output: Dk. Blue: 7
(-) Lock Output: Dk. Green: 15
(+) Siren Output: Brown: 17
[1]
(-) GWR Output: Blue/White: 18
Siren
OBDII Diagnostic Connector
under Driver Dash
(connector side view)
Manual/Auto. Transmission Type
Manual/Auto. Transmission Type
Prog.
Prog.
Button
Button
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
10: Red: (+) 12V
9: Black: (-) Ground
2 & 8: White/Brown: (+) 12V
1 & 7: White: (+) Parking Lights
(+) Parking Lights:
Green/White, pin 2
2
1
3 4
5
6
7
12
8 9 10 11
13
14
15
C-208 White Connector
(Junction Block at Driver Kick Panel)
Directed Digital System MIT4
© 2015 Directed. All rights reserved.
