Type 3 - Directed MIT4 Firmware Specific Manual

Type 3

Refer to "Vehicle wiring reference charts" on page 11 for more information on vehicle-specific connections.
For Manual Transmission ONLY
Relay pin 30 Relay pin 87a
Clutch:
Cut
Brown/Black,
pin 2
87
85
1 2
87a
86
30
Clutch
Pedal
(+) Ignition: Red or
Black/White, pin 2
(+) 12V: Blue/Yellow, pin 1
Ignition Switch Connector
1 2
(left side of steering column)
4 5
(+) Accessory 1: (+) Starter:
Blue/Red, pin 4 Black/Yellow, pin 5
Junction Block
rear view
(Driver Kick Panel)
The installation of an aftermarket hood pin is only required on vehicles
[1]
that are not equipped with a factory hood pin.
The siren is only compatible with hybrid systems.
[2]
The green wire is only required for starter kill and antigrind connections.
[3]
All adapters are displayed from the wire side (unless specified otherwise).
9
Junction Block
front view
C-204
C-204 White Connector
(Front of Junction Block.
at Driver Kick Panel)
15 14 13 11 10 9
12
7 6 5 4 3 2 1
(-) Driver Door Trigger:
Lt. Green, pin 6
(+) Starter Output (Car Side): Violet: 8
Starter Input (Key Side): Green: 7
[3]
(+) 12V Input: Red: 6
(+) Accessory 1 Output: Orange: 5
(+) 12V Input: Red: 4
(+) Ignition Input/Output: Pink: 3
(+) Accessory 2 Output: Orange: 5
(+) Accessory 2:
3
Blue/Black, pin 6
6
(-) Unlock/Disarm:
Red/Green, pin 5
1 2 3 5 6 7 8 9
4
10 11 12 13 14 15 16 17 18
19 20 21 22 23 24
(-) Lock/Arm:
Lt. Green/Black, pin 22
C-217 White 24-pin Connector
(Rear of Junction Block,
at Driver Kick Panel)
HS CAN High: Red, pin 6
1 8
9 16
HS CAN Low: Black, pin 14
8
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
(-) Auto Headlamp Shutoff: Green/Black: 10
MC501
Hood Pin
(-) Hood Input: Gray: 3
[1]
(-) Unlock/Disarm Output: Dk. Blue: 7
(-) Lock/Arm Output: Dk. Green: 15
(+) Siren Output: Brown: 17
[2]
(-) GWR Output: Blue/White: 18
Siren
If there's no Lock/Unlock wires, you can either insert
Lock/Unlock wires directly as shown below or use
Installation Type 4 on page 10.
Solder onto a diode, cut away the unneeded
Solder the wire to secure it on the metal pin.
Empty pin
Diode
*Lock: Same procedure have to be done for missing Lock wire.
OBDII Diagnostic Connector
under Driver Dash
(connector side view)
Manual/Auto. Transmission Type
Manual/Auto. Transmission Type
Prog.
Prog.
Button
Button
This part can be removed
because only the metal pin is
Unlock* wire from Remote Starter
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
10: Red: (+) 12V
9: Black: (-) Ground
2 & 8: White/Brown: (+) 12V
1 & 7: White: (+) Parking Lights
(+) Parking Lights:
Green/White, pin 2
2
1 3 4 5 6 7
12
8 9 10 11 13 14 15
C-208 White Connector
(Junction Block at Driver Kick Panel)
Directed Digital System MIT4
