3-3 Thermal Printer Specifications

3-3-1 Printer Specification

1) 180dpi
Item
Model
Print Method
Dot Density
Printing Direction
Printing Width
Character / Line
Character Spacing
Printing Speed
Paper feeding Speed
2) 203 dpi
Item
Model
Print Method
Dot Density
Printing Direction
Printing Width
Character / Line
Character Spacing
Printing Speed
Paper feeding Speed

3-3-2 Character Specification

Item
Number of Character
Character Structure
Rev. 1.00
All manuals and user guides at all-guides.com
• SRP-F310 (TPH: KRB-72-7TA02-BIX2,KYOCERA CORPORATION)
• Thermal Line Printing
• 0.141 mm(7 Dots/mm)
• Unidirection with friction feed
• 72.2mm, 512 dot Position
• 42 (Font A: 12x24) • 56 (Font B: 9x17 )
• 0.28mm (0.01) (2 dots) (Font A)
• 0.28mm (0.01) (2 dots) (Font B)
• Mono Max. 270mm (63.82 Lines/sec, 1/6inch feed)
• 2color Max. 130mm (30.73 Lines/sec, 1/6inch feed)
• Ladder Barcode: Mono 270mm/sec, 2Color 130mm/sec
• Approx. 270mm/sec
Table 3-2 Thermal Printer Specification
• SRP-F312 (TPH: KRC-80-8TA02-BIX2,KYOCERA CORPORATION)
• Thermal Line Printing
• 0.125mm(8 Dots/mm)
• Uni-direction with friction feed
•80.0mm, 640 dot Position
• 48 (Font A: 12x24) • 64 (Font B: 9x17 )
• 0.25mm (0.01) (2 dots) (Font A)
• 0.25mm (0.01) (2 dots) (Font B)
• Mono Max. 270mm (72 Lines/sec, 1/7inch feed)
• 2color Max. 130mm (34.6 Lines/sec, 1/7inch feed)
• Ladder Barcode: Mono 270mm/sec, 2Color 130mm/sec
• Approx. 270mm/sec
Table 3-3 Thermal Printer Specification
• Alphanumeric Characters: 95
• Extended Characters: 128 x 34 Page
(Including one space page)
• International Characters: 32
• 12 x 24 (Font A) (Including 2-dot spacing in horizontal)
• 9 x 17 (Font B) (Including 2-dot spacing in horizontal)
Font A is selected as the default
Table 3-4 Thermal Printer Character Specification
- 18 -
Description
Description
Description
SRP-F310/312
Remark
Remark
Remark
