FEATURES & CONTROLS
Gear position indicator -
19
Display the current gear position.
Coolant Temperature -
20
This dashboard section displays the current coolant temperature, 'C' is low temperature, 'H' is high
temperature. Both over-low and over-high are abnormal. Idle the vehicle to warm the engine when it's too
cold, and park the vehicle when it's too hot to prevent the coolant from boiling. Keep the coolant temperature
in a normal range.
SEL - mode select button -
21
Use this button together with the "ADJ" button to adjust functions on the dashboard. Refer to 'Dashboard
Navigation / Settings / Adjustments'.
Override indicator -
22
When depress the override button, override indicator is on, 4WD-LOCK speed limitation will be released in
this state.
Coolant temperature warning indicator -
23
o
When the coolant temperature is higher than 115 C, the coolant temperature warning indicator will be on.
o
When the coolant temperature is higher than 120 C, the temperature warning indicator will be on and also
the warning buzzer will alarm.
85
