Summary of Contents for CF MOTO 600

Page 2 TABLE OF CONTENTS Foreword ......................1 Welcome .......................... 1 EVAP System (Evaporative Emission Control System) ........... 2 Signal Words ........................3 Introduction ........................8 Vehicle Identification Number ................... 9 Specification ........................10 Operator Safety ..................... 17 Equipment Modifications ....................18 Safety Training .......................
Page 3 Transmission Gear Selector ................... 68 CVT System ........................70 Avoiding CVT drive belt and component problems ............71 Vehicle Features ......................73 Dashboard Indicators and Warnings ................80 Operation of your ATV ................... 87 Pre-Ride Inspection ......................89 Starting the Engine ......................90 Gear Selector Operation ....................
Page 4 Engine Pings or Knocks ....................178 Engine Stops or loses power ..................179 Engine Turns Over, Fails to Start ................. 179 Engine Backfires ......................180 Engine Runs Irregularly, Stalls or Misfires ..............180 Engine Runs Irregularly, Stalls or Misfires ..............181 Engine Stops or Loses Power ..................
Page 5 FOREWORD Foreword Welcome Thank you for purchasing a CFMOTO vehicle, and welcome to our world-wide family of CFMOTO enthusiasts. Be sure to visit us online at www.cfmoto.com for the latest news, new product introductions, upcoming events, and more. CFMOTO is an international company that specializes in the development, manufacture, and marketing of all-terrain vehicles, utility vehicles, large displacement motorcycles, and their core components.
Page 6 FOREWORD WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. EVAP System (Evaporative Emission Control System) Do not modify the EVAP system. Modification is a violation of EPA regulations. Ensure that all the hoses are not clogged or kinked, otherwise it could damage the fuel pump or distort the fuel tank.
Page 7 FOREWORD Signal Words A signal word calls attention to a safety message or messages, a property damage message or messages, and designates a degree or level of hazard seriousness. The standard signal words in this manual are WARNING, CAUTION and NOTE or NOTICE. The following signal words and symbols appear throughout this manual and on your vehicle.
Page 8 FOREWORD WARNING FOR TYPE I ATVs (1-person vehicle) Improper vehicle use can result in SEVERE INJURY or DEATH ALWAYS NEVER USE NEVER CARRY NEVER USE AN ON PUBLIC PASSENGERS USE WITH APPROVED ROADS DRUGS OR HELMET AND ALCOHOL PROTECTIVE GEAR...
Page 9 FOREWORD WARNING FOR TYPE II ATVs (2-person vehicle) Improper vehicle use can result in SEVERE INJURY or DEATH ALWAYS NEVER USE NEVER NEVER USE AN ON PUBLIC CARRY MORE USE WITH APPROVED ROADS THAN ONE DRUGS OR HELMET AND PASSENGER ALCOHOL PROTECTIVE GEAR FOR...
Page 10 FOREWORD NEVER: • Operate without proper training or instruction. • Operate on public roads. A collision can occur with another vehicle. • Operate at speeds too fast for your skill or the conditions. • Carry multiple passengers, Type II ATVs are designed for a single passenger only. •...
Page 11 FOREWORD READ THE OWNER’S MANUAL FOLLOW ALL INSTRUCTIONS AND WARNINGS WARNING Read, understand, and follow all of the instructions and safety precautions in this manual and on all product labels. Failure to follow the safety precautions could result in serious injury or death.
Page 12 INTRODUCTION Introduction Thank you for purchasing a CFMOTO vehicle, and welcome to our world-wide family of CFMOTO enthusiasts. For safe and enjoyable operation of your vehicle, be sure to follow the instructions and recommendations in this owner’s manual. Information about major repairs are outlined in the CFMOTO Service Manual, and should only be performed by a CFMOTO service dealer and technician.
Page 13 INTRODUCTION Vehicle Identification Number Record your vehicle’s identification numbers in the spaces provided. Remove the spare key and store in a safe place. Your key can be duplicated only by mating a key blank with one of your existing keys. If both keys are lost, the complete lock assembly must be replaced.
Page 14 SPECIFICATION Specification CFORCE 600 CFORCE 600 TOURING Item CF600AU-3S CF600AU-3L 2035 mm 2235 mm Overall Length 1180 mm 1180 mm Overall Width 1220 mm 1390 mm Overall Height 1280 mm 1480 mm Wheel Base 270 mm Ground Clearance 3625 mm...
Page 15 SPECIFICATION CFORCE 600 CFORCE 600 TOURING Item CF600AU-3S CF600AU-3L Bore × Stroke 91 mm × 89.2 mm Displacement 580 cc Compression Ratio 10.68 : 1 Starting Type ECU ignition Splash lubrication Lubrication Type Engine Coolant: Type Commercially available – Safe for aluminum engines Coolant Volume 2.3 qt ( 2.18 L )
Page 16 SPECIFICATION CFORCE 600 CFORCE 600 TOURING Item CF600AU-3S CF600AU-3L Rear gear case Oil: SAE80W/90GL-5 Type 6.7 oz ( 200 mL ) Volume: Periodic Oil Change 6.7 oz ( 200 mL ) Front Gear Case Oil: SAE80W/90GL-5 Type 7.7 oz ( 230 mL ) Volume 7.7 oz ( 230 mL )
Page 17 SPECIFICATION CFORCE 600 CFORCE 600 TOURING Item CF600AU-3S CF600AU-3L Spark Plug Type DCPR8E/NGK Spark Plug Gap 0.8 mm ~ 0.9 mm CVT+gear shift Transmission Gear Shift/Order Manual L/H/N/R/P 0.67 ~ 3.02 CVT Ratio Transmission 2.533 Low Gear Gear Ratio 1.35 High Gear 2.071...
Page 18 SPECIFICATION CFORCE 600 CFORCE 600 TOURING Item CF600AU-3S CF600AU-3L Tire Pressure: Front 45 kPa Rear 45 kPa Front: hydraulic disc Brake System: Rear: hydraulic disc Foot Brake Type / Operation Front/rear united brake Operated by right foot Hand Brake Type / Operation...
Page 19 Hydraulic damping / oil damper Rear Shock Absorber Hydraulic damping / oil damper Wheel Travel: Front Wheel Travel 160 mm Rear Wheel Travel 210 mm Electrical System: ECU ignition Ignition Charging A/C 600 Watt @ 5000 rpm 12 Vdc / 30 Amp Hr Battery...
Page 20 SPECIFICATION CFORCE 600 CFORCE 600 TOURING Item CF600AU-3S CF600AU-3L Light System: LED 14.4W×2 Head Lamp, Low Beam LED 28.5W×4 Head Lamp, High Beam LED 3.6W×2 Front Position Light LED 2.9W×2 / LED 2W×2 Tail Light/Brake Light LED and LCD -- non-maintenance...
Page 21 OPERATOR SAFETY Operator Safety WARNING Failure to heed the warnings contained in this manual can result in serious injury or death. An ATV is not a toy and can be hazardous to operate. This vehicle handles differently from other vehicles, such as motorcycles and cars.
Page 22 OPERATOR SAFETY Equipment Modifications CFMOTO is concerned with the safety of our customers and for the general public. Therefore, we strongly recommend that consumers do not install on a vehicle, any equipment that may increase the speed or power of the vehicle, or make any other modifications to the vehicle for these purposes. Any modifications to the original equipment of the vehicle create a substantial safety hazard and increase the risk of body injury.
Page 23 OPERATOR SAFETY Safety Training When you purchased your new ATV, your dealer offered a hands-on safety training course that covers all aspects of vehicle safety. You were also provided with printed materials that explain safe operating procedures. You should review this information on a regular basis. If you purchased a used ATV from a party other than a dealer, you can request safety training from any authorized dealer.
Page 24 OPERATOR SAFETY has completed a certified safety training course. • Never operate an ATV without wearing an approved helmet that fits properly . Always wear eye protection (goggles or face shield), gloves, boots, a long-sleeved shirt or jacket, and long pants. •...
Page 25 OPERATOR SAFETY • Never go over the top of a hill at high speed. • Always follow proper procedures for going downhill and for braking on hills. Check. the terrain carefully before you start down a hill. Shift your weight backward. Never go down a hill at high speed. Avoid going down a hill at an angle, which would cause the vehicle to lean sharply to one side.
Page 26 OPERATOR SAFETY • Wet brakes may have reduced stopping ability. Test your brakes after leaving water. If necessary, apply them lightly several times while driving slowly to allow friction to dry out the pads. • Always check for obstacles or people behind the ATV before operating in reverse. When it’s safe to proceed in reverse, move slowly and avoid turning at sharp angles.
Page 27 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Operating this ATV without proper instruction. WHAT CAN HAPPEN: The risk of an accident is greatly increased if the operator does not know how to operate the ATV properly in different situations and on different types of terrain. HOW TO AVOID THE HAZARD: Beginning and inexperienced operators should complete a certified training course offered by a dealer.
Page 28 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Carrying a passenger on an ATV that is not designed for carrying a passenger. WHAT CAN HAPPEN: A passenger riding on the ATV could be ejected from the vehicle unexpectedly or make contact with moving components, both of which can result in severe injury or death.
Page 29 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Operation on paved surfaces such as sidewalks, trails parking lots, or public highways and streets. WHAT CAN HAPPEN: ATV tires are designed for off-road use. Driving on paved surfaces greatly affects how an ATV handles, which can result in loss of control and/or an accident.
Page 30 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Operating this ATV without wearing an approved helmet, eye protection, and protective clothing. WHAT CAN HAPPEN: Operating an ATV without an approved helmet increases the risk of a severe head injury or death in the event of an accident. Operating without eye protection could result in an accident and could increase the chance of a severe eye injury in the event of an accident.
Page 31 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Operating the ATV after consuming alcohol or drugs. WHAT CAN HAPPEN: Consumption of alcohol and/or drugs could seriously affect operator judgment. Reaction time may be slower and operator balance and perception could be affected. Consumption of alcohol and/or drugs before or while operating an ATV could result in an accident causing severe injury or death.
Page 32 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Operating the ATV at excessive speeds. WHAT CAN HAPPEN: Excessive speed increases the operator’s chance of losing control of the ATV, which can result in an accident. HOW TO AVOID THE HAZARD: Always operate the ATV at a speed that’s proper for the terrain, visibility and operating conditions, and your experience.
Page 33 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Failure to inspect the ATV before operating. Failure to properly maintain the ATV. WHAT CAN HAPPEN: Poor maintenance increases the possibility of an accident or equipment damage. HOW TO AVOID THE HAZARD: Always inspect your ATV before each use to make sure it’s in safe operating condition. Always follow the inspection and maintenance procedures and schedules described in the owner’s manual.
Page 34 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Failure to use extra caution when operating the ATV on unfamiliar terrain. WHAT CAN HAPPEN: Unfamiliar terrain may contain hidden rocks, bumps, or holes that could cause loss of control or overturn. HOW TO AVOID THE HAZARD: Travel slowly and use extra caution when operating on unfamiliar terrain.
Page 35 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Failure to use extra caution when operating on excessively rough, slippery or loose terrain. WHAT CAN HAPPEN: Operating on excessively rough, slippery or loose terrain could cause loss of traction or loss of control, which could result in an accident or overturn.
Page 36 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Turning improperly. WHAT CAN HAPPEN: Improper turns could cause loss of control and lead to a collision or overturn. HOW TO AVOID THE HAZARD: Always follow proper procedures for turning as described in the owner’s manual. Practice turning at slow speeds before attempting to turn at faster speeds.
Page 37 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Climbing excessively steep hills or climbing hills improperly. WHAT CAN HAPPEN: Improper hill climbing could cause loss of control or overturn. HOW TO AVOID THE HAZARD: Never operate on hills too steep for the ATV or for your abilities. Practice on smaller hills before attempting large hills.
Page 38 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Traveling down excessively steep hills. WHAT CAN HAPPEN: Improper downhill travel could cause loss of control or overturn. HOW TO AVOID THE HAZARD: Never operate on hills too steep for the ATV or for your abilities. Practice on smaller hills before attempting large hills.
Page 39 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Improperly crossing hills and turning on hills. WHAT CAN HAPPEN: Improperly crossing or turning on hills could cause loss of control or overturn. HOW TO AVOID THE HAZARD: Never attempt to turn the ATV around on any hill until you’ve mastered the turning technique on level ground as described in the owner’s manual.
Page 40 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Stalling, rolling backwards or improperly dismounting while climbing a hill. WHAT CAN HAPPEN: The vehicle could overturn. HOW TO AVOID THE HAZARD: Maintain a steady speed when climbing a hill. IF ALL FORWARD SPEED IS LOST: Close the throttle.
Page 41 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Improperly operating over obstacles. WHAT CAN HAPPEN: Operating over obstacles could cause loss of control or overturn. HOW TO AVOID THE HAZARD: Before operating in a new area, check for obstacles. Avoid operating over large obstacles such as rocks and fallen trees when possible.
Page 42 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Skidding or sliding. WHAT CAN HAPPEN: Skidding or sliding can cause loss of control. If the tires regain traction unexpectedly, the ATV could overturn. HOW TO AVOID THE HAZARD: On slippery surfaces such as ice, travel slowly and use extra caution to reduce the chance of skidding or sliding out of control.
Page 43 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Operation of the ATV through deep or fast-flowing water. WHAT CAN HAPPEN: The tires may float, causing loss of traction and loss of control, which can lead to an accident or overturn. HOW TO AVOID THE HAZARD: Avoid operating the ATV through deep or fast-flowing water.
Page 44 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Improperly operating in reverse. WHAT CAN HAPPEN: The ATV could collide with an obstacle or person, resulting in severe injury. HOW TO AVOID THE HAZARD: Before shifting into reverse gear, always check for obstacles or people behind the ATV. When it’s safe to proceed, back slowly.
Page 45 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Operating the ATV with improper modifications. WHAT CAN HAPPEN: Improper installation of accessories or modification of the ATV may cause changes in handling which could lead to an accident. HOW TO AVOID THE HAZARD: Never modify the ATV through improper installation or use of accessories. All parts and accessories added to the vehicle must be genuine parts or equivalent components designed for use on this ATV and should be installed and used according to approved instructions.
Page 46 OPERATOR SAFETY WARNING POTENTIAL HAZARD: Operating on frozen bodies of water. WHAT CAN HAPPEN: Severe injury or death can result if the ATV and/or the operator fall through the ice. HOW TO AVOID THE HAZARD: Never operate the ATV on a frozen body of water.
Page 47 OPERATOR SAFETY WARNING Leaving the keys in the ignition can lead to unauthorized use of the vehicle, resulting in serious injury or death. Always remove the ignition key when the vehicle is not in use. WARNING After any overturn or accident, have a qualified service dealer inspect the entire vehicle for possible damage, including (but not limited to) brakes, throttle and steering systems.
Page 48 OPERATOR SAFETY Safe Riding Gear Always wear clothing suited to the type of riding. ATV riding requires special protective clothing for comfort and to reduce the chance of injury: Helmet Your helmet is the most important piece of protective gear for safe riding.
Page 49 SAFETY DECALS & LOCATIONS Safety Decals and Locations Warning decals have been placed on the ATV for your protection. Read and follow the instructions on each decal carefully. If a decal becomes illegible or comes off, contact your dealer to purchase a replacement.
Page 50 SAFETY DECALS & LOCATIONS TYPE I TYPE II...
Page 51 SAFETY DECALS & LOCATIONS TYPE I TYPE II...
Page 52 SAFETY DECALS & LOCATIONS TYPE I TYPE II...
Page 53 SAFETY DECALS & LOCATIONS TYPE I TYPE II...
Page 54 SAFETY DECALS & LOCATIONS TYPE I TYPE II...
Page 55 SAFETY DECALS & LOCATIONS TYPE I TYPE II...
Page 56 SAFETY DECALS & LOCATIONS...
Page 57 FEATURES & CONTROLS Features & Controls Left Hand Controls (Without turning light) Engine Stop Switch When the switch is at position, the engine shuts off. When the switch is at position, the engine can be started. Horn Button Press the button, the horn will sound.
Page 58 FEATURES & CONTROLS Headlight Switch The headlight switch consists of 4 positions: : When the switch is at this position, Hi beam, front position light, tail light, and license plate light are on. : When the switch is at this position, Lo beam, front position light, tail light, and license plate light are on.
Page 59 FEATURES & CONTROLS Override Button The engine is normally limited when operating in 4WD-LOCK If conditions require more engine power in 4WD-LOCK: • Release the throttle and press the button to override the speed limiting function. While this button is depressed, the override indicator light will come on.
Page 60 FEATURES & CONTROLS Left Hand Controls (With turning light) Hazard Switch Press the button . Front turn lights, rear turn lights and turn signal indicators on dashboard flash. Engine Stop Switch When the switch is at position, the engine shuts off. When the switch is at position, the engine can be started.
Page 61 FEATURES & CONTROLS Headlight Switch The headlight switch consists of 4 positions: : When the switch is at this position, Hi beam, front position light, tail light, and license plate light are on. : When the switch is at this position, Lo beam, front position light, tail light, and license plate light are on.
Page 62 FEATURES & CONTROLS Override Button The engine is normally limited when operating in 4WD-LOCK If conditions require more engine power in 4WD-LOCK: • Release the throttle and press the button to override the speed limiting function. While this button is depressed, the override indicator light will come on.
Page 63 FEATURES & CONTROLS Right Hand Controls Front Brake The front brake lever is located on the right handlebar and controls only the front brakes. Pull it toward the handlebar to apply the front brake. When squeezed, the lever or pedal should feel firm. Any sponginess would indicate a possible fluid leak or low master cylinder fluid level, which must be corrected before riding.
Page 64 FEATURES & CONTROLS Four Wheel Drive (4WD) System Switch This ATV is equipped with on-command “2WD”/”4WD” and “LOCK”/”4WD” switches: • Two-wheel drive (2WD) : Power is supplied to the rear wheels only. The mode lever (A) is moved to the left and the switch button is outward.
Page 65 FEATURES & CONTROLS Throttle Lever Once the engine is running, movement of the throttle lever will increase the engine speed. Regulate the speed of the machine by varying the throttle position. Because the throttle is spring loaded, the machine will decelerate, and the engine will return to an idle any time the hand is removed from the throttle lever.
Page 66 FEATURES & CONTROLS Parking Brake Hydraulic parking brake is mounted on the right hand brake. To apply parking brake, grasp tightly the right hand brake first, and press foot brake at the same time, then press the hydraulic parking brake by left hand.
Page 67 FEATURES & CONTROLS Mechanical Speed Limiter A mechanical speed limiter keeps the throttle from fully opening, even when the throttle lever is pushed to maximum travel. Turning in the screw limits the throttle lever travel, which reduces the maximum engine power available and decreases the maximum speed of the ATV.
Page 68 FEATURES & CONTROLS Foot Brake The foot brake pedal is located on the right side floor board of the vehicle. Pushing down on the pedal applies the front and rear brakes at the same time. When applied, the pedal should feel firm. A soft brake pedal would indicate a possible fluid leak or low master cylinder fluid level, which must be corrected before riding.
Page 69 FEATURES & CONTROLS Foot Brake Reservoir Fluid Level Check NOTE Remove the front access cover and then check the fluid level. When checking the fluid level, the ATV must be on level ground. If fluid level is lower than the “lower”mark , add DOT4 brake fluid.
Page 70 FEATURES & CONTROLS Fuel Tank Fuel tank cap is located at the front of the vehicle. Open the fuel tank cap to fill fuel. Fuel Minimum Octane Rating The recommended fuel for your ATV is minimum 89 Octane unleaded (maximum 10% ethanol is allowed). Non-oxygenated (ethanol-free) fuel is recommended for best performance in all conditions.
Page 71 FEATURES & CONTROLS Fuel Safety WARNING Gasoline is highly flammable and explosive under certain conditions. • Always exercise extreme caution whenever handling gasoline. • Always refuel with the engine stopped, and outdoors or in a well ventilated area. • Never carry a plastic container with gasoline in the racks while riding. Static electricity between the rack and container could cause a spark.
Page 72 FEATURES & CONTROLS Transmission Gear Selector The transmission gear selector is located on the left side of the vehicle. CAUTION Always stop the ATV and press the foot brake pedal before shifting the transmission. Shifting gears with the engine speed above idle or while the vehicle is moving could cause transmission damage.
Page 73 FEATURES & CONTROLS Parking To park the ATV, stop the engine, press the foot brake, and shift the gear selector Lever into the park position. CAUTION When shifting the transmission in PARK, always push the brake pedal. Shake the vehicle forward and backward to verify that park is engaged.
Page 74 FEATURES & CONTROLS CVT System This vehicle has a Continuously Variable Transmission (CVT) system that utilizes a belt and clutch pulleys to automatically vary transmission ratios, allowing infinite variability between the highest and lowest vehicle speeds with no discrete steps or shifts. The CVT consists of a primary clutch , which is an advanced form of centrifugal clutch that is mounted to the engine crankshaft...
Page 75 FEATURES & CONTROLS Avoiding CVT drive belt and component problems CVT clutch and belt life can be dramatically extended by avoiding these common operating mistakes: CVT Fail Reason How To Avoid CVT Failure Attempting to load the vehicle onto a truck bed Shift transmission to low gear during loading of the ATV to or tall trailer in high gear.
Page 76 FEATURES & CONTROLS CVT Fail Reason How To Avoid CVT Failure Stuck in mud or snow. Shift the transmission to low gear, and carefully use fast, aggressive throttle application to engage clutch. WARNING: Excessive throttle may cause loss of control and vehicle overturn. Climbing over large objects from a stopped position.
Page 77 FEATURES & CONTROLS Vehicle Features Main Switch The functions of the main key switch positions are as follows: : All electrical circuits are switched on. The engine can be started at this position. The key cannot be removed in this position. : All electrical circuits are switched off.
Page 78 FEATURES & CONTROLS Front Storage Box / Rear Storage Box This vehicle is equipped with storage boxes on the front right side and the rear position.
Page 79 FEATURES & CONTROLS Trailer Power Socket This vehicle is equipped with 7-pin trailer power socket, located under the rear cargo rack. The socket wires are configured to this standard as shown in the image provided . An accessory trailer power converter is required for trailers that do not have a 7-pin connector.
Page 80 FEATURES & CONTROLS Winch This vehicle is equipped with a 3000-lb winch. The winch control is located on the left handle bar. To preserve battery power, only operate the winch when the engine is running. Please consult with your dealer on the use of the winch before using your vehicle.
Page 81 FEATURES & CONTROLS • Prior to initiating winching operation be sure any element which can interfere with safe winching is removed. • Do not disengage clutch if winch is under load or wire rope is in tension. • Take your time. Sloppy rigging causes accidents. •...
Page 82 FEATURES & CONTROLS Alarm This vehicle is configured with an alarm that performs the following functions: ≥ • When oil pressure signal is in GND, and RPM 1000 r/min, alarm sounds one short/time. When the oil pressure rises to the normal range, the alarm disappears. >...
Page 83 FEATURES & CONTROLS Front panel access Your vehicle is equipped with an access panel on the front rack. To remove the panel: 1. Lift and pull the rubber retaining strap away from the panel until the strap releases from the front tab. 2.
Page 84 FEATURES & CONTROLS Dashboard Indicators and Warnings...
Page 85 FEATURES & CONTROLS 1 Engine RPM 10 Turning light, RH 19 Gear position indicator 2 Clock 11 Drive mode 20 Coolant Temperature 3 Turning light, LH 12 EPS indicator 21 SEL - mode select button 4 Neutral indicator 13 Parking brake indicator 22 Override indicator 5 High beam indicator 14 ADJ - mode adjust button...
Page 86 FEATURES & CONTROLS Neutral indicator - This indicator displays when the transmission is in neutral. High beam indicator - This indicator illuminates when the headlight switch turns to high beam position. EFI fault indicator - This indicator displays when a fault occurs in the Electronic Fuel Injection system. Please stop the vehicle and contact your dealer to eliminate the fault.
Page 87 FEATURES & CONTROLS Turning light, RH (If equipped) - When switch turns to right turning light position, the indicator is on. Drive mode - Display the current drive mode, there are 3 drive modes, 2WD, 4WD and 4WD-LOCK EPS fault indicator - This indicator displays when a fault occurs in the Electronic Power Steering system.
Page 88 FEATURES & CONTROLS Rider Information Center - Rider Information Center. This dashboard section can be toggled using the ‘SEL’ button to display: ‘TOTAL’ -The odometer accumulated vehicle distance traveled in miles/kilometers, ‘TRIP’ - The trip distance traveled, ‘H’ - The accumulated engine run time, ‘V’ - Battery voltage, ‘Brightness’ - Set the dashboard display brightness using the ‘ADJ’...
Page 89 FEATURES & CONTROLS Gear position indicator - Display the current gear position. Coolant Temperature - This dashboard section displays the current coolant temperature, ‘C’ is low temperature, ‘H’ is high temperature. Both over-low and over-high are abnormal. Idle the vehicle to warm the engine when it’s too cold, and park the vehicle when it’s too hot to prevent the coolant from boiling.
Page 90 FEATURES & CONTROLS Dashboard Navigation / Settings / Adjustments Item Display Operation Result Odometer TOTAL Short press Shift to trip TRIP Short press Shift to engine hour Engine hour Trip distance TRIP Long press Trip resets to be zero TRIP Engine hour Short press Shift to fault code...
Page 91 OPERATION OF YOUR ATV Operation of your ATV Break-In Period The break-in period for your new ATV is very important. Careful treatment of a new engine at the beginning of ownership will result in more efficient performance and longer life. Perform the following procedures carefully: 1.
Page 92 OPERATION OF YOUR ATV CAUTION During the break-in period: • Do not load or tow cargo. • Do not operate at sustained full throttle. Damage to engine parts or decrease engine life may result if excessive wide open throttle is used during the first 20 hours of use. •...
Page 93 OPERATION OF YOUR ATV Pre-Ride Inspection Before each use of the vehicle, a best practice is to check the vehicle according to the “Perform daily before operating the vehicle” checklist in maintenance sheet. WARNING If a proper inspection is not done before each use, severe damage to the vehicle, severe injury, or death could result.
Page 94 OPERATION OF YOUR ATV Starting the Engine Starting a Cold Engine WARNING Engine exhaust contains poisonous carbon monoxide and can cause loss of consciousness resulting in severe injury or death. Never run an engine in an enclosed area. CAUTION Operating the vehicle immediately after starting could cause engine damage. Allow the engine to warm up for several minutes before operating the vehicle.
Page 95 OPERATION OF YOUR ATV NOTE Do not activate the starting system more than 10 seconds on each attempt. If the engine fails to start, release the start switch, pause a few seconds before the next attempt, then push the start switch again. Each attempt should be as short as possible to preserve battery energy.
Page 96 OPERATION OF YOUR ATV Gear Selector Operation Shifting CAUTION To avoid transmission damage, return the throttle to the closed position, stop the vehicle, and apply the foot brake before shifting. NOTE Low gear is the preferred transmission gear selection for all forward motion other than prolonged high speed travel.
Page 97 OPERATION OF YOUR ATV Shifting out of Park 1. Verify the throttle is closed. 2. Apply the foot brake. 3. Shift to the desired gear by moving the gear selector along the shift guide. Shifting: Neutral to High Gear 1. Verify the throttle is closed and the vehicle is stopped completely. 2.
Page 98 OPERATION OF YOUR ATV 4. Check behind you for people or obstacles, then release the foot brake pedal. 5. Apply the throttle lever gradually and continue to watch behind you while moving backward. WARNING When you shift into reverse, make sure there are no obstacles or people, and the area is safe behind you. When it is safe to proceed, go slowly.
Page 99 OPERATION OF YOUR ATV Hauling Cargo Your vehicle is equipped with front and rear cargo racks, and a hitch receptacle for towing. Follow these guidelines for hauling and towing of cargo: WARNING Overloading the vehicle, carrying or towing cargo improperly, can alter vehicle handling and may cause loss of control or brake instability.
Page 100 OPERATION OF YOUR ATV • Carrying a load on only the front rack or the rear rack may cause an imbalanced condition and increases the possibility of vehicle overturn. Balance loads proportionally between the front rack and the rear rack, but do not exceed the stated load capacity. •...
Page 101 OPERATION OF YOUR ATV Load Distribution Your ATV has been designed to carry or tow a certain amount of load. Always: • Read and understand the load distribution warnings listed on the warning labels. • Never exceed the specified weights. •...
Page 102 OPERATION OF YOUR ATV Driving Safely Responsibilities of the operator As the operator of this ATV, your common sense, judgment, and abilities are the only factors that will prevent injury to yourself, to others around you, and/or damage to the vehicle or environment. Recreational, group, and distance riding One of the benefits of this vehicle is that it can take you off-road away from most communities.
Page 103 OPERATION OF YOUR ATV Practice The driving procedures described in this manual should be practiced at slow speed many times in a large area with no obstacles. If an incorrect technique is used, your ATV may continue to go straight. If the ATV does not turn, come to a stop and then practice the procedure again.
Page 104 OPERATION OF YOUR ATV Driving procedure 1. Sit upright with both feet on the footrests and both hands on the handlebars. 2. Start the engine and allow it to warm up. Apply the foot brake, then shift the transmission into low gear. 3.
Page 105 OPERATION OF YOUR ATV Making Turns To make a turn, steer in the direction of the turn, leaning your upper body to the inside of the turn while supporting your weight on the outer footrest. This technique alters the balance of traction between the wheels, allowing turn to be made smoothly.
Page 106 OPERATION OF YOUR ATV ATV turning dynamics To achieve maximum traction while operating in 2WD or 4WD, the two rear wheels perform as one axle and turn together at the same speed. Furthermore, when operating in 4WD-LOCK mode, the front wheels will also turn together at the same speed.
Page 107 OPERATION OF YOUR ATV Driving in reverse To operate in reverse: 1. Ensure the throttle is closed and the vehicle is stopped completely. 2. Apply the foot brake, then shift the transmission into reverse gear. 3. Check for obstacles or people behind the vehicle. 4.
Page 108 OPERATION OF YOUR ATV Driving on Slippery Surfaces Whenever riding on slippery surfaces such as wet trails, loose gravel, sand, or during freezing weather, follow these precautions: • Slow down when entering slippery areas. • Maintain a high level of alertness, reading the trail and avoiding quick, sharp turns which can cause skids.
Page 109 OPERATION OF YOUR ATV Driving on rough terrain Whenever driving on rough surfaces such as trails with large rocks or other obstacles, follow these precautions: • Slow down when encountering rough terrain. • Maintain a high level of alertness, reading the trail in front of you as you drive.
Page 110 OPERATION OF YOUR ATV Driving over obstacles Be alert! Learn to look ahead and to read the terrain as you drive. Be constantly alert for hazards such as logs, rocks, and low hanging branches. Never attempt to cross over an obstacle higher than the ground clearance of the vehicle.
Page 111 OPERATION OF YOUR ATV Driving through water Yo u r AT V c a n o p e r a t e t h r o u g h w a t e r w i t h a m a x i m u m recommended depth equal to the bottom of the footrests.
Page 112 OPERATION OF YOUR ATV Drying the CVT system after submersion If water has been ingested into the CVT housing, the drive belt will likely slip and poor performance will result. To expel water and dry the CVT housing: • Drain the CVT housing. •...
Page 113 OPERATION OF YOUR ATV Driving Uphill Whenever traveling uphill, follow these precautions: • Always travel straight uphill. • Avoid steep hills (22° maximum). • Keep both feet on the footrests. • Shift your weight forward. • Proceed at a steady rate of speed and throttle opening. •...
Page 114 OPERATION OF YOUR ATV If the ATV begins rolling backwards: Keep your weight uphill. Never apply engine power. Never apply the foot brake while rolling backwards. Apply the front brake. When fully stopped, apply the foot brake, and then shift gear selector into the parking position.
Page 115 OPERATION OF YOUR ATV Sidehilling WARNING Improperly crossing hills or turning on hills can result in loss of control or vehicle overturn, resulting in severe injury or death. Avoid crossing the side of a hill when possible. Follow proper procedures as outlined in the owner’s manual.
Page 116 OPERATION OF YOUR ATV Driving downhill When traveling down a hill, follow these precautions: • Never operate on hills over 22 degrees incline or hills too steep for your abilities. • Slow down. • Shift your weight to the rear of the vehicle. •...
Page 117 OPERATION OF YOUR ATV Turning Around on a Hill One maneuver that can be used when it’s necessary to turn around if stranded while climbing a hill is the K-turn: 1. Release the throttle, then apply the hand and foot brake while keeping your body weight uphill.
Page 118 OPERATION OF YOUR ATV Parking on an lncline Avoid parking on an incline if possible. If it's unavoidable, follow these precautions: • Turn the engine off. • Place the gear selector to parking position. • Always block the rear wheels on the downhill side as shown. CAUTION The rear output shaft is locked when the transmission is in the parking position.
Page 119 MAINTENANCE Maintenance Schedule Periodic maintenance schedule Careful periodic maintenance will help keep your vehicle in the safest, most reliable condition. Inspection, adjustment and lubrication of important components are explained in the periodic maintenance chart. Inspect, clean, lubricate, adjust, and replace parts as necessary. When inspection reveals the need for replacement parts, please use genuine parts available from your dealer.
Page 120 MAINTENANCE NOTE Pay special attention to the oil level. A rise in oil level during cold weather can indicate contaminants collecting in the oil sump or crankcase. Change oil immediately if the oil level begins to rise. Monitor the oil level, and if it continues to rise, discontinue to use and determine the cause or see your dealer.
Page 121 MAINTENANCE KEY POINTS OF LUBRICATION SCHEDULE: Check all components at the intervals outlined in the Periodic Maintenance Schedule. Items not listed in the schedule should be lubricated at the general lubrication interval. • Change lubricants more often under severe use, such as wet or dusty conditions. •...
Page 122 MAINTENANCE Pre-Ride Maintenance Checklist Perform these inspections before operating the vehicle: Maintenance before operation Item Hour Calendar Miles (km) Remarks Pre-Ride ■ Steering system Pre-Ride ■ Throttle return Pre-Ride Front suspension and axles Visually inspect, test, Pre-Ride Rear suspension and axles or check components.
Page 123 MAINTENANCE Maintenance before operation Item Hour Calendar Miles (km) Remarks Inspect. If deposits are visible, clean intake Pre-Ride ► Air box sediment tube tubes, air box, and replace air filter. Inspect. If deposits are visible, drain / clean Pre-Ride ► CVT sediment tube the CVT or have it serviced by a dealer.
Page 124 MAINTENANCE Break-In Maintenance Checklist Perform these maintenance items when the vehicle break-in is completed: Break-in Maintenance (Perform at the interval that arrives first) Item Hour Calendar Miles (km) Remarks Lubricate all grease 200 (320) General lubrication points, pivots, cables, etc. Change oil and filter.
Page 125 MAINTENANCE Break-in Maintenance (Perform at the interval that arrives first) Item Hour Calendar Miles (km) Remarks Check terminals, 200 (320) Battery clean, test battery condition if required. Inspect for proper rpm. See dealer for 200 (320) ■ Idle condition service if out of spec or erratic.
Page 126 MAINTENANCE Periodic Maintenance Schedule Perform these maintenance items when the vehicle break-in is completed: Periodic Maintenance Intervals (Perform at the interval that arrives first) Item Hour Calendar Miles (km) Remarks Monthly 100 (160) ► Brake pads Inspect pad thickness. Check terminals. Clean and test 200 (320) Battery...
Page 127 MAINTENANCE Periodic Maintenance Intervals Item (Perform at the interval that arrives first) Hour Calendar Miles (km) Remarks Inspect level. Change yearly if hours or 500 (800) ► Front gear case oil distance interval is not met. Inspect level. Change yearly if hours or 500 (800) ►...
Page 128 MAINTENANCE Periodic Maintenance Intervals Item (Perform at the interval that arrives first) Hour Calendar Miles (km) Remarks Inspect. clean external surfaces. Clean more 500 (800) ► Radiator frequently if subjected to severe use. 500 (800) Inspect. Lubricate. ■ Steering system L u b r i c a t e .
Page 129 MAINTENANCE Periodic Maintenance Intervals (Perform at the interval that arrives first) Item Hour Calendar Miles (km) Remarks Inspect. Replace 1500 (2400) ► ■ CVT drive belt as necessary. See dealer for service. Clean and Inspect pulleys. Replace 100h 500 (800) ■...
Page 130 MAINTENANCE Periodic Maintenance Intervals Item (Perform at the interval that arrives first) Hour Calendar Miles (km) Remarks Inspect fuel tank, cap, ● 100h 500 (800) Fuel system fuel pump and fuel pump relay. Inspect. Replace if 100h 2000 (3200) Spark plug worn or fouled.
Page 131 MAINTENANCE Periodic Maintenance Intervals Item (Perform at the interval that arrives first) Hour Calendar Miles (km) Remarks Inspect for noise or 100h 1500 (2400) ► ■ Wheel bearings looseness Replace as necessary. Visually inspect belts and test latches. Clean latch 100h 2000 (3200) ►...
Page 132 MAINTENANCE Periodic Maintenance Intervals (Perform at the interval that arrives first) Item Hour Calendar Miles (km) Remarks Inspect for proper rpm. See dealer for Idle condition service if out of spec or erratic. Inspect steering system. See dealer for service whenever ■...
Page 133 MAINTENANCE Maintenance Procedures Engine oil check Always check and change the engine oil at the intervals outlined in the Maintenance Schedule. 1. Place the ATV on a level surface. 2. Start the engine and let it idle for (20 ~ 30) seconds. Stop the engine.
Page 134 MAINTENANCE Engine oil change 1. Place the ATV on a level surface. 2. If the engine was running, wait a sufficient period for the oil to settle and cool. 3. Place an oil pan under the engine to collect the used oil. 4.
Page 135 MAINTENANCE Oil filter replacement 1. Use wrench to unscrew bolts . Then remove cover remove oil filter Attention: Confirm cover O-ring is good, then install it into groove of the crankcase correctly. 2. Install new oil filter and use wrench to tighten cover bolts to the specified torque.
Page 136 MAINTENANCE Engine valve train adjustment The intake and exhaust valve clearances change with use of the vehicle, which can result in improper fuel/air supply or engine noise. To prevent this, the valve clearances must be adjusted according to the maintenance schedule.
Page 137 MAINTENANCE Gear case oil The gear cases must be checked for oil leaks before each ride. If an oil leak is found, have your dealer check and repair the ATV. Rear case oil measurement Because of its unique design, draining and filling the gear case is required to produce the correct lubricant level.
Page 138 MAINTENANCE Front gear case oil measurement Because of its unique design, draining and filling the gear case is required to produce the correct lubricant level. Refer to ‘Rear gear case oil change’ NOTE: Oil filler bolt tightening torque: 18.4 ft-lb. (25 N•m). Front gear case oil change 1.
Page 139 MAINTENANCE Cooling system Coolant level check 1. Place the ATV on a level surface. 2. Coolant reservoir is located on the front left of the vehicle. Check the coolant level in the coolant reservoir when the engine is cold as the coolant level will vary with engine temperature.
Page 140 MAINTENANCE Front access cover Removal: Grasp the access cover edge, pull upward to release the grommet pins, then remove the front access cover A by direction of front of vehicle. Grasp the edge of front top cover B, pull upward to release the grommet pins, then remove the cover B by direction of front of vehicle.
Page 141 MAINTENANCE Changing the coolant CAUTION After running the engine, never remove the radiator cap immediately. Wait for the engine to cool down before removing the radiator cap. Hot coolant can cause serious burns. 1. Place the ATV on a level surface. 2.
Page 142 MAINTENANCE 8. Replace the coolant drain bolt washer if it is damaged, then install and tighten the coolant drain bolt, but do not torque to specification. 9. Reinstall the coolant reservoir hose. 10. Fill the recommended coolant into the radiator until it is full. NOTE When filling coolant, at the same time loosen the coolant drain bolt to draw out potential air bubbles inside the coolant hose until...
Page 143 MAINTENANCE NOTE Recommended antifreeze: Any high quality ethylene glycol antifreeze containing corrosion inhibitors for aluminum engines. CFMOTO recommended coolant freeze protection level: -35 Antifreeze and distilled water mixing ratio: 1:1 Total Coolant Capacity (except coolant reservoir): 2.3 qt. (2.18 L) Coolant Change (except coolant reservoir): 2.22 qt.
Page 144 MAINTENANCE Axle dust boots Check the protective boots for holes or wear. If any damage is found, have them replaced by your dealer. Rear : Front:...
Page 145 MAINTENANCE Spark plug inspection To access the spark plug, the following components must be removed: Left Deco Panel Remove the expansion screws Remove the bolt Remove the cover ； Shifter Cover Remove the screw ； Remove the bolts ；...
Page 146 MAINTENANCE Remove the cover ； Lower Side Cover Remove the bolts ； Remove the left lower side cover ；...
Page 147 MAINTENANCE Removal Remove the spark plug cap. Use the spark plug wrench in the tool kit to remove the spark plug. Inspection The spark plug is an important engine component and is easy to inspect. The condition of the spark plug can indicate the condition of the engine.
Page 148 MAINTENANCE Measure the electrode gap with a thickness gauge, and if necessary, adjust the gap to specification. NOTE: Spark plug gap : 0.8 mm ~ 0.9 mm Installation 1. Clean the gasket surface. Wipe off any grime from the threads. 2.
Page 149 MAINTENANCE Spark plug removal to expel water from the engine If water has been ingested into the engine, it is important to remove the water as soon as possible by removing the spark plug and using the starter system to rotate the engine for a short period to expel water out of the cylinder.
Page 150 MAINTENANCE Air filter element There is a check hose at the bottom of the air filter housing. If dust or water can be viewed in this hose, empty the hose and clean the air filter housing thoroughly. If the vehicle was submerged, please contact your local dealer to check for water inside the engine crankcase.
Page 151 MAINTENANCE lubricant on the inside diameter of the air filter rubber seal. 10. Install the air filter and clamp onto the air filter housing inlet. Tighten the clamp securely. 11. Reinstall the air filter housing cover and spring clips. Verify the cover is installed correctly and is sealing properly.
Page 152 MAINTENANCE Drying the air filter housing after submersion If water has been ingested into the air filter housing, Drain the air filter housing, remove the air filter, and thoroughly dry the components. Do not use compressed air. Contact your dealer if vehicle performance issues exist.
Page 153 MAINTENANCE Spark Arrestor Clean spark arrestor while muffler and exhaust are in normal temperature. 1. Remove nut 2. Remove spark plug arrestor from muffler. 3. Tap the tailpipe lightly, and then use a wire brush to remove any carbon deposits from the spark arrestor portion of the tailpipe.
Page 154 MAINTENANCE CVT air-outlet check hose If dust or water can be viewed in this hose , empty the hose and clean or drain the CVT housing. If the vehicle was submerged, contact your local dealer to check the CVT housing and components thoroughly.
Page 155 MAINTENANCE Throttle freeplay adjustment Check the throttle freeplay at regular intervals. NOTE Check the engine idling speed after adjusting throttle lever freeplay. 1. Loosen nut 2. Turn adjustment nut to lever travel: = 3 mm ~ 5 mm. 3. Fasten nut Brake pad inspection Check the brake pads for damage and wear.
Page 156 MAINTENANCE Brake system inspection Check the fluid level Insufficient brake fluid may let air enter the brake system, possibly causing the brakes to become ineffective. Before riding, check that the brake fluid is above the lower level and replenish when necessary.
Page 157 MAINTENANCE Inspect brake fluid level Observe these precautions: 1. When checking the front brake fluid level, make sure the master cylinder reservoir is level by turning the handlebar until the steering is centered and the wheels are pointed forward. 2. Use only the designated quality brake fluid. Otherwise, the rubber seals may deteriorate, causing leakage and poor brake performance.
Page 158 MAINTENANCE Brake fluid change Complete fluid replacement should be done only by trained service personnel. Have your dealer replace the following components during periodic maintenance or when they are damaged or leaking. • Replace the brake hoses every four years. Front lever free play The front brake lever should have a free play of 10 mm (0.4 in) at the lever end.
Page 159 MAINTENANCE Parking brake RH parking brake When parking, stop the engine and grasp tightly the right hand brake, press foot brake at the same time, then press the hydraulic parking brake by left hand. WARNING Operating the ATV while the parking brake is engaged could result in an accident and serious injury or death.
Page 160 MAINTENANCE Foot brake pedal height adjustment NOTE The top of the brake pedal should be positioned 95 mm ~ 100 mm above the top of the footrest. If it is not, have your dealer to adjust DANGER After servicing: • Make sure the brakes operate smoothly and that the freeplay 95 mm ~ 100 mm is correct.
Page 161 MAINTENANCE Cable inspection and lubrication WARNING Inspect cables frequently. Replace damaged cables. Lubricate the inner cables and the cable ends. If the cables do not operate smoothly, ask your dealer to replace them. NOTE Recommended lubricant: SAE 10W/30 Suspension Pivot Lubrication Lubricating rear stabilizer bar.
Page 162 MAINTENANCE Wheel and Tires Removal and installation Removal 1. Loosen the wheel nuts 2. Elevate the ATV and place a suitable stand under the frame. 3. Remove the nuts from the wheel. 4. Remove the wheel. Installation: 1. Install the wheel and the nuts. NOTE •...
Page 163 MAINTENANCE Tire pressure Inspect the tire pressure before operation: Front: 6.5 psi (45 kPa) Rear: 6.5 psi (45 kPa) Tread depth Inspect the tread depth regularly and replace the tires if the minimum tread depth is less than: Minimum tread depth: 3/32 in. (3.0 mm)
Page 164 MAINTENANCE Battery This machine is equipped with low maintenance battery which is located under the seat. Therefore, it is not necessary to check the electrolyte or add distilled water in the battery. If the battery seems to have discharged, consult your dealer. NOTE Battery specification: 12V 30Ah WARNING...
Page 165 MAINTENANCE Battery maintenance guidelines: • If the vehicle will not be used for a month or longer, remove the battery and store it in a cool, dry place. Completely recharge the battery before reinstallation. • A special battery charger (constant low voltage/ampere) is required for recharging low maintenance batteries.
Page 166 MAINTENANCE Battery Disassembly Turn off all electrical parts and the engine before disassembly. Disassembly (The L model) Remove the passenger and operator seats. Remove the expansion screws Remove the deco panel Remove bolt Remove the rear seat mounting bracket Remove the belt and electrode cover Remove the fixing bolt of battery negative wire together with the wire.
Page 167 MAINTENANCE Assembly (The L model) Mount the battery in place. Mount the positive wire onto the battery positive bolt. Mount the negative wire onto the battery negative bolt. Mount the belt and electrode cover Mount the rear seat mounting bracket Mount the bolt Mount the deco panel Mount the expansion screws...
Page 168 MAINTENANCE Disassembly (The S model) Remove the expansion screws Remove the deco panel Remove the bolt Remove the front seat assembling bracket Take out the belt and electrode protector Remove the fixing bolt of battery negative wire together with the wire. Remove the fixing bolt of battery positive wire together with the wire.
Page 169 MAINTENANCE Fuse and Relay replacement 1. Relay / Fuse box is located under the front access cover. Main fuse 30A and EPS fuse 40A are located under the seat. 2. If a fuse is blown, turn off the main switch and install a new fuse of the specified amperage.
Page 170 MAINTENANCE Relay / Fuse Box For vehicle without turning light...
Page 171 MAINTENANCE Relay / Fuse Box For vehicle with turning light...
Page 172 MAINTENANCE WARNING To prevent accidental short-circuit, turn off the main switch when checking or replacing a fuse. Headlight bulb replacement NOTE: Both headlight and taillight assy are LED lights, which cannot be repaired if damaged or failed. Please have your dealer replace the entire assembly when the LED light is damaged or failed.
Page 173 MAINTENANCE Headlight beam adjustment WARNING It is advisable to have your dealer make this adjustment. Turn the adjusting screws can raise or lower the beam. Tail/brake light replacement: Tail/brake light bulb is LED, it can not be replaced separately. Replace the whole light as necessary.
Page 174 MAINTENANCE Front and rear suspension adjustment Standard shock absorber The spring preload can be adjusted to suit the rider's weight and riding conditions. NOTE When adjusting the rear shock absorbers, the rear wheels need to be removed. Adjust the spring preload as follows. To increase the spring preload, turn the adjusting ring in direction To decrease the spring preload, t urn the adjusting ring...
Page 175 MAINTENANCE WARNING If your vehicle becomes immersed, major engine damage can result if the machine is not thoroughly inspected. Take the vehicle to your dealer before starting the engine. For example, if engine is not properly handled after immersion, starting will damage the engine. Fuel Evaporation System (EVAP) Your vehicle contains a fuel evaporation system (EVAP) that prevents fuel vapors from entering the atmosphere from the fuel tank and fuel system.
Page 176 CLEANING & STORAGE Cleaning & Storage Cleaning the ATV Keeping your ATV clean will not only improve its appearance, but it can also extend the life of various components. With a few precautions, your ATV can be cleaned much like an automobile. Washing the ATV The best and safest way to clean your ATV is with a garden hose and a pail of mild soap and water.
Page 177 CLEANING & STORAGE Waxing the ATV Your ATV can be waxed with any non-abrasive automotive paste wax. Avoid the use of harsh cleaners since they can scratch the body finish. CAUTION Certain products, including insect repellents and chemicals, will damage plastic surfaces. Use caution when using these products near plastic surfaces.
Page 178 CLEANING & STORAGE Oil and Filter Warm the engine, then stop the engine and change the oil and filter. Air Filter/ Air Box Inspect and clean or replace air filter. Clean the air box and drain the sediment tube. Check fluid levels Inspect the following fluid levels and change if necessary: •...
Page 179 CLEANING & STORAGE Lubricate Inspect all cables and lubricate with cable lubricant according to the product label directions. Grease the vehicle pivot points with all season grease. ‘Fog’ the engine 1. Remove the left side panel to access the spark plug. 2.
Page 180 CLEANING & STORAGE Engine Anti-Freeze Test engine coolant strength and change if necessary. Coolant should be replaced every two years. Storage Area/Covers Set the tires to specified air pressure and support the ATV with tires 30 mm ~ 40 mm off the ground. Be sure the storage area is well ventilated and cover the machine with a ATV cover.
Page 181 CLEANING & STORAGE Transporting the ATV Follow these procedures when transporting the vehicle: • Turn off the engine and remove the key to prevent loss during transporting. • Ensure the fuel cap is installed correctly and secure. • Ensure the seat is installed correctly and secure. •...
Page 182 VEHICLE DIAGNOSIS Vehicle Issue Diagnosis This section is intended to guide an average owner to simple items that could cause operating problems. Diagnosis of vehicle issues may require the experience of a dealership technician. Please contact your dealer if a solution is not apparent. Engine doesn’t turn over Fail Reason How To Avoid Failure...
Page 183 VEHICLE DIAGNOSIS Engine Stops or loses power Fail Reason How To Avoid Failure Overheated engine Clean radiator screen and core Clean engine exterior See your dealer Engine Turns Over, Fails to Start Fail Reason How To Avoid Failure Out of Fuel Refuel Clogged fuel valve or filter Inspect and clean or replace...
Page 184 VEHICLE DIAGNOSIS Engine Backfires Fail Reason How To Avoid Failure Weak spark from spark plugs Inspect, clean and/or replace spark plugs Incorrect spark plug gap or heat range Set gap to specs or replace plugs Old or non-recommended fuel Replace with new fuel Incorrectly installed spark plug wires See your dealer Incorrect ignition timing...
Page 185 VEHICLE DIAGNOSIS Engine Runs Irregularly, Stalls or Misfires Fail Reason How To Avoid Failure Kinked or plugged fuel vent line Inspect and replace Incorrect fuel Replace with recommended fuel Clogged air filter Inspect and clean or replace Reverse speed limiter malfunction See your dealer Electronic throttle control malfunction See your dealer...
Page 186 VEHICLE DIAGNOSIS Engine Stops or Loses Power Fail Reason How To Avoid Failure Out of fuel Refuel Kinked or plugged fuel vent line Inspect and replace Water present in fuel Replace with new fuel Fouled or defective spark plugs Inspect, clean and/or replace spark plugs Worn or defective spark plug wires See your dealer Incorrect spark plug gap or heat range...
Page 187 VEHICLE DIAGNOSIS EFI Malfunction Indicator Light The Electronic Fuel Injection system on your vehicle contains a self-diagnostic feature that will illuminate the malfunction indicator light ( M IL ) if it detects a problem. When this indicator is on, the fault code will display on the dashboard directly, record the fault code and contact your dealer for diagnosing.
Page 188 VEHICLE DIAGNOSIS EPS Malfunction Indicator Light The Electronic Power Steering system on your vehicle contains a self-diagnostic feature that will illuminate the malfunction indicator light (MIL- ) if it detects a problem. In normal operation, the EPS indicator will be on after the ignition switch is turned to ON, but EPS will not work.
Page 189 VEHICLE DIAGNOSIS EPS fault diagnosis and solution Trouble shooting Possible causes Repair procedures Improper plug connection Check the plugs and connections No steering assist Burnt fuse Replace fuse to handlebar Contact authorized dealer and replace the Failure of Controller, Motor or sensor parts.
Page 190 CFMOTO LIMITED WARRANTY FOR USA CFMOTO Limited Warranty For USA Dear Customer, Thank you for purchasing a CFMOTO product, if any component on your vehicle is found to be defective in materials or workmanship within the terms and conditions of this Limited Warranty, the defective component will be repaired or replaced (at the option of CFMOTO) without charge for parts and/or labor at any authorized dealer located within the United States.
Page 191 CFMOTO LIMITED WARRANTY FOR USA A. A 30-DAY WARRANTY coverage period applies to all new CFMOTO vehicles in relation to the vehicle’s: • Battery • Spark Plugs • Air Filters • Oil and Fuel Filters B. A 90-DAY WARRANTY coverage period applies to all new CFMOTO vehicles in relation to the vehicle’s: •...
Page 192 CFMOTO LIMITED WARRANTY FOR USA 3.EXCLUSIONS FROM WARRANTY COVERAGE: Any Damage resulting from the following acts or circumstances is not covered by the CFMOTO POWERSPORTS, Inc., Limited Warranty: • Fire • Collision • Theft • Unavoidable natural disasters • Improper storage or transportation •...
Page 193 CFMOTO LIMITED WARRANTY FOR USA 5.TRANSFER OR CONTINUATION OF WARRANTY: This warranty is transferable only under the following conditions: • Transfer information must be provided to an authorized CFMOTO POWERSPORT S, Inc. dealer, who will then forward the information to CFMOTO POWERSPORTS, Inc.. •...
Page 194 CFMOTO LIMITED WARRANTY FOR USA 8.CUSTOMER ASSISTANCE: Any questions regarding your CFMOTO vehicle or related products should be directed to an authorized CFMOTO dealer. However, if a dealer is not available to answer customer concerns or address a technical issue with a CFMOTO vehicle or product, CFMOTO POWERSPORTS, Inc., customer representatives can be contacted directly at (763) 398-2690 or by e-mail: info@cfmoto-us.com.Please note that Customer Service cannot approve or deny warranty, and cannot provide technical repair data, diagnosis, instruction, or other information beyond what is provided in the Owner’s Manual.
Page 195 CFMOTO LIMITED WARRANTY FOR USA 12. INTEGRATION: This limited warranty supersedes any and all oral, express, or written warranties, statements, or undertakings that may previously have been made, and contains the entire agreement of the parties with respect to the warranty of CFMOTO vehicles. Any and all warranties not contained in this Agreement are specifically excluded.
Page 196 CFMOTO LIMITED WARRANTY FOR USA CALIFORNIA EVAPORATIVE EMISSIONS CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS INTRODUCTION: The California Air Resources Board (CARB) and CFMOTO Powersports, Inc. (CFMOTO) are pleased to explain the evaporative emissions control system warranty on your 2020 and later-model year off-highway recreation vehicles (OHRVs).
Page 197 CFMOTO LIMITED WARRANTY FOR USA As an owner, you are responsible for presenting your OHRV to a CFMOTO dealer as soon as a problem exists. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days. As an OHRV owner, you should also be aware that CFMOTO may deny you warranty coverage if your OHRV or a part has failed due to abuse, neglect, improper maintenance or unapproved modifications.
Page 198 CFMOTO LIMITED WARRANTY FOR USA U.S.A. EPA and CARB Emissions Control Limited Warranty This emissions limited warranty is in addition to the CFMOTO Powersports, Inc. standard limited warranty for your vehicle. CFMOTO Powersports, Inc. warrants that at the time it is first purchased, this emissions- certified vehicle is designed, built and equipped so it conforms to applicable U.S.
Page 199 CFMOTO LIMITED WARRANTY FOR USA For exhaust emissions, emission-related components include any engine parts related to the following systems: • Air-induction system (excludes filters) • Ignition system (excludes spark plugs) • Fuel system (excludes filters) • Exhaust gas recirculation systems The following parts are also considered emission-related components for exhaust emissions: •...
Page 200 CFMOTO LIMITED WARRANTY FOR USA THE REMEDIES SET FORTH IN THIS LIMITED WARRANTY ARE THE ONLY REMEDIES AVAILABLE TO ANY PERSON FOR BREACH OF THIS WARRANTY. CFMOTO POWERSPORTS, INC. SHALL HAVE NO LIABILITY TO ANY PERSON FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES OF ANY DESCRIPTION, WHETHER ARISING OUT OF EXPRESS OR IMPLIED WARRANTY OR ANY OTHER CONTRACT, NEGLIGENCE OR OTHER TORT OR OTHERWISE.
Page 201 CFMOTO LIMITED WARRANTY FOR USA Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply if it is inconsistent with the controlling state law. This limited warranty excludes failures not caused by a defect in material or workmanship.
Page 202 CFMOTO LIMITED WARRANTY FOR USA Noise Control System and Tampering Warranty time period: 1, 865 miles (3000 km) Federal law prohibits the following acts or causing thereof: (1)The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement, of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or.
Page 203 CHANGE OF OWNERSHIP If you sell the product, any valid remainder of the warranty can be transferred to the new Owner. Please record the details of the exchange below and inform an Authorized CFMOTO Dealer. REGISTRATION OF OWNER OWNER OWNER CHANGE OF OWNERSHIP OWNER’S NAME ADDRESS...
Page 204 9DSV-380101-1400-13 US208 TYPE TYPE I...

This manual is also suitable for:

600 touringCf600 au-3s Cf600 au-3l

CF MOTO 600 Owner's Manual

Quick Links

Related Manuals for CF MOTO 600

Summary of Contents for CF MOTO 600

This manual is also suitable for:

Table of Contents
