dallmeier DDZ5200HD Indoor Series Commissioning

In-ceiling mount (im)
Hide thumbs Also See for DDZ5200HD Indoor Series:
Table of Contents

Advertisement

Quick Links

DDZ5200HD Indoor Series
In-Ceiling Mount (IM)
COMMISSIONING
008267 | REV. 1.0.0 | 2021-02-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDZ5200HD Indoor Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dallmeier DDZ5200HD Indoor Series

Summary of Contents for dallmeier DDZ5200HD Indoor Series

  • Page 1 DDZ5200HD Indoor Series In-Ceiling Mount (IM) COMMISSIONING 008267 | REV. 1.0.0 | 2021-02-02...
  • Page 2 Phillips of Phillips Screw Company headquartered in Wakefield, Massachusetts, USA. Third-party trademarks are named for information purposes only. Dallmeier respects the intellectual property of third parties and always attempts to ensure the complete identification of third-party trademarks and indication of the respective holder of rights.

  • Page 3: Table Of Contents

    Audio Out/In Alarm In / Relay Out / RS485 11 Configuration System Requirements Establishing the Connection First-Time Access Login 12 Technical Product Specification (Basic Data) 13 Dimensions COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 4: Validity

    Save digital documents relating to your device (e.g. the technical product specification) on a suitable data storage device. Regularly check the website www.dallmeier.com for the latest product documentation updates. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 5: This Document

    The document entitled “Configuration” contains detailed information con- cerning the configuration of the device. The target audience of the document is trained system integrators (installa- tion contractors of video security/surveillance systems). COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 6: Typographical Conventions

    NOTICE addresses practices not related to physical injury and indicates measures to prevent device and/or property damage due to improper installation, assembly, wiring, operation, configuration or maintenance of the device. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 7 (menu items, buttons, etc.). Paragraphs in italics provide information on basic principles, special features and efficient procedure as well as general recommendations. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 8: Approvals/Certifications

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interfer- ence at his own expense. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 9: Safety Instructions

    Only use internal components that have been tested and approved by Dallmeier. Inappropriate internal components may cause malfunctions, damage and data loss and may result in the loss of warranty. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 10 DIN, VDE and ISO standards and which provide for a standard-compliant earthing/grounding and a correct equipotential bonding of electrical and electronic devices, are mandatory and must be fulfilled by all means. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 11 PoE feature on the corresponding Ethernet port of your PSE). Remove all connected peripherals. Return the device to the sales partner responsible for your area. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 12: General Notes

    Instead, always use the supplied pair of gloves to prevent a reduction in image quality due to fingerprints and to protect the surface coating of the dome bubble from possible damage caused by sweat and grease deposits. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 13: Transportation And Packaging

    Outdoor installation is not permitted and may result in malfunctions, damages, data loss and the loss of warranty. ➡ Do not install and operate the cameras in outdoor environments. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 14: Operation

    Mixed light (consisting of artificial light and daylight) may cause color distortions (inaccurate color reproduction). • Poor lighting can lead to an incorrect white balance. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 15: Requirements

    • areas of explosive hazard due to flammable material (gas, vapor, mist or dust), • poor air circulation or heat dissipation (e.g. in insufficiently dimen- sioned cavities). COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 16: Power Supply

    Damage to electronic components or serious malfunctions ➡ Do not operate the device with Power over Ethernet (PoE+) if the device is powered by an external AC power supply unit. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 17 PoE injector from the power supply before un-mating the jack-plug connection in order to prevent damage to the contacts of the RJ45 connectors by contact erosion. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 18: Earthing/Grounding

    DIN, VDE and ISO standards in order to ensure the safety of the device (protection against lightning strikes and over-voltages) and its immunity to electromagnetic interferences (EMI). COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 20: Maintenance, Inspection And Cleaning

    Instead, always use the supplied pair of gloves to prevent a reduction in image quality due to fingerprints and to protect the surface coating of the dome bubble from possible damage caused by sweat and grease deposits. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 21 To dry the dome bubble, dab it carefully and gently with a clean, soft, dry and antistatic cloth (e.g. a glasses cleaning cloth) to avoid scratching the surface coating. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 22: Mounting, Connection And Commissioning

    When mounting (or removing) the device, always use the supplied pair of gloves to avoid fingerprints on the device. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 23 However, be careful not to touch the polycarbonate dome bubble with bare fingers. Instead, use the supplied pair of gloves to avoid fingerprints. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 24 ❷ Fig. 3 ➡ Push the release tab of both snap-in elements inward against spring pressure and carefully pull the PTZ dome camera out of the housing. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 25 Fig. 4 COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 26 ❸ Fig. 5 ➡ Carefully detach the adhesive tape from the camera unit and remove the lens protection cap. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 27 ❹ Fig. 6 ➡ Screw the supplied eye bolt M6 clockwise into the provided thread on the bottom of the housing until it is fully tightened. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 28 195 mm into the suspended ceiling or ceiling panel (tile) using a suitable tool (e.g. a drilling machine with hole saw or a drywall utility saw). ➡ Screw a suitable ceiling hook into the supporting structure. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 29 224 – 225 mm, you should first attach the supplied installation aid (two plastic attach- ment parts) to the housing, as shown on page 39. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 30 ❼ Fig. 9 ➡ Attach the supplied safety cable to the eye bolt M6 (use the included carabiner) and the ceiling hook. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 31 ➡ Tighten the Phillips PH2 screw on both retaining wings clockwise with a suitable screwdriver until both retaining wings swivel out and the housing is firmly anchored in the ceiling panel (see following figures). COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 32 Fig. 11 COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 33 When removing the device at a later date, the retaining wings on the housing must be swiveled back to their default position (by simply turning the corresponding screws counterclockwise). COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 34 ➡ Carefully insert the PTZ dome camera into the housing while holding it straight (make sure the connectors on the bottom of the PTZ dome camera are correctly aligned). COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 35 ➡ Make sure that both snap-in elements of the PTZ dome camera are fully engaged (have clicked into place) and that the PTZ dome camera is securely fixed. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 36 ➡ Attach the cover ring with bubble to the housing and turn it clock- wise until it noticeably locks into place (see Fig. 16). COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 37 Fig. 16: Cover ring locked in place COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 38 ➡ Establish the power supply to the device (via PoE+ or external 24 V AC power supply unit). The device starts to boot and is ready for operation after a short self-test. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 39 ➡ For an easier and more precise centering of the housing in an already existing ceiling hole with a diameter of 224 – 225 mm, use the supplied installation aid (two plastic attachment parts), as shown in Fig. 18. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 40: 10 Connections And Pin Assignment

    10 Connections and Pin Assignment Fig. 19: Terminal area Detailed pinout information for each connector can be found on the following pages. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 41: Power In

    RJ45 female connector – 10BASE-T/100BASE-TX / PoE+ (IEEE 802.3at) Do not operate the device with Power over Ethernet (PoE+) if the device is powered by an external AC power supply unit. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 42: Audio Out/In

    Unavailable audio signals due to improper cabling/connections ➡ Always use a ground loop isolator (with galvanic isolation) for both the Audio In and the Audio Out interface. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 43: Alarm In / Relay Out / Rs485

    Alarm In 3 Alarm 3 GND Alarm In 1 – 3 For use with potential-free switch contacts. Relay Out Max. 30 V DC, 1 A; no AC. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 44: Configuration

    Microsoft Edge*) • Google*) Chrome*) • Mozilla*) Firefox*) (each in the latest version) Browser settings JavaScript*) enabled Sound Sound card or on-board sound chip (min. 16 bit) COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 45: Establishing The Connection

    The language of the graphical user interface (WebConfig-GUI) can be switched in the top-left corner of the screen without the need to login. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 46: First-Time Access

    (the strength of the selected password is displayed during input). ➡ Click “OK”. After the first successful access to the device, the login dialog is displayed. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 47: Login

    ➡ Finally, click “LOGOUT” to properly log out of the device. Detailed descriptions of the configuration settings can be found in separate documentations that are available at www.dallmeier.com. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 48: Technical Product Specification (Basic Data)

    Bubble Polycarbonate (clear) Color Housing: black Cover ring: white Dimensions ∅ 245 × H 267 mm (∅ 9.65" × H 10.50") Weight Approx. 3.1 kg (6.83 Ibs) COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 49 Detailed information and possible updates can be found in the currently valid product specification at www.dallmeier.com. COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 50: 13 Dimensions

    13 Dimensions ∅ 245 mm (9.65") ∅ 195 mm (7.68") ∅ 156 mm (6.12") Fig. 24 COMMISSIONING – DDZ5200HD Indoor Series IM | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 52 HEADQUARTERS Dallmeier electronic GmbH & Co.KG Bahnhofstr. 16 93047 Regensburg Germany +49 941 8700-0 +49 941 8700-180 mail info@dallmeier.com www.dallmeier.com...

This manual is also suitable for:

Ddz5220hd indoor imDdz5232hd indoor im
