DDZ5200HD Outdoor Series
COMMISSIONING
008316 | REV. 1.0.0 | 2021-04-13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDZ5200HD Series and is the answer not in the manual?

Questions and answers

Related Manuals for dallmeier DDZ5200HD Series

Summary of Contents for dallmeier DDZ5200HD Series

  • Page 1 DDZ5200HD Outdoor Series COMMISSIONING 008316 | REV. 1.0.0 | 2021-04-13...
  • Page 2 Mozilla and Firefox of Mozilla Foundation headquartered in Mountain View, California, USA. Third-party trademarks are named for information purposes only. Dallmeier respects the intellectual property of third parties and always attempts to ensure the complete identification of third-party trademarks and indication of the respective holder of rights.
  • Page 3 COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 5: Table Of Contents

    9 Mounting, Connection and Commissioning 10 Connections and Pin Assignment Alarm/Audio Power In 11 Configuration System Requirements Establishing the Connection First-Time Access Login 12 Technical Product Specification (Basic Data) 13 Dimensions COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 6: Validity

    Save digital documents relating to your device (e.g. the technical product specification) on a suitable data storage device. Regularly check the website www.dallmeier.com for the latest product documentation updates. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 7: This Document

    The document entitled “Configuration” contains detailed information con- cerning the configuration of the device. The target audience of the document is trained system integrators (installa- tion contractors of video security/surveillance systems). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 8: Typographical Conventions

    NOTICE addresses practices not related to physical injury and indicates measures to prevent device and/or property damage due to improper installation, assembly, wiring, operation, configuration or maintenance of the device. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 9 (menu items, buttons, etc.). Paragraphs in italics provide information on basic principles, special features and efficient procedure as well as general recommendations. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 10: Approvals/Certifications

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interfer- ence at his own expense. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 11: Safety Instructions

    Only use internal components that have been tested and approved by Dallmeier. Inappropriate internal components may cause malfunctions, damage and data loss and may result in the loss of warranty. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 12 DIN, VDE and ISO standards and which provide for a standard-compliant earthing/grounding and a correct equipotential bonding of electrical and electronic devices, are mandatory and must be fulfilled by all means. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 13 PoE feature on the corresponding Ether- net port of your PSE). Remove all connected peripherals. Return the device to the sales partner responsible for your area. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 14: General Notes

    Instead, always use the supplied pair of gloves to prevent a reduction in image quality due to fingerprints and to protect the surface coating of the dome bubble from possible damage caused by sweat and grease deposits. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 15: Transportation And Packaging

    No fan/heater support if operated with Power over Ethernet. The cameras of the DDZ5200HD Outdoor series are designed exclusively for hanging installations on ceilings or walls (optionally available Mountera® bracket required). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 16: Operation

    Mixed light (consisting of artificial light and daylight) may cause color distortions (inaccurate color reproduction). • Poor lighting can lead to an incorrect white balance. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 18: Formation Of Condensation

    Pressure equalization elements are used to prevent the formation of con- densation in sealed enclosures, where humidity normally cannot escape to the outside. Fig. 1: Pressure equalization element COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 19 This results in condensation on the outer surface of the polycarbonate bub- ble (like dew on the grass). This phenomenon is due to physical reasons and, therefore, does not consti- tute a defect. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 20: Requirements

    (gases, vapors, solvents, chemicals, etc.), • areas of explosive hazard due to flammable material (gas, vapor, mist or dust), • poor air circulation or heat dissipation (e.g. in insufficiently dimen- sioned cavities). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 21: Earthing/Grounding

    (EMI). ➡ Observe the locally applicable regulations (regional and country-specific legal requirements and standards) regarding the required minimum cross-section for the earthing/grounding cable used. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 22: Power Supply

    Damage to electronic components or serious malfunctions ➡ Observe the correct polarity when connecting the device to the used power supply unit (see chapter “Connections and Pin Assignment” on page 66). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 23 PoE injector from the power supply before un-mating the jack-plug connection in order to prevent damage to the contacts of the RJ45 connectors by contact erosion. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 24: Maintenance, Inspection And Cleaning

    Instead, always use the supplied pair of gloves to prevent a reduction in image quality due to fingerprints and to protect the surface coating of the dome bubble from possible damage caused by sweat and grease deposits. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 25 COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 26: Mounting, Connection And Commissioning

    (safety cable) on the outside of the housing. In addition, strictly observe the locally applicable regulations regard- ing the mandatory measures for securing your camera system against falling while in operation. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 27 In the following, the mounting of the device on the Mountera® Ceiling Bracket is described. Fig. 3: Mountera® Ceiling Bracket with internal cable routing and pre-assembled internal safety cable (secondary safety component – supplied with bracket) COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 28 ➡ Open the device packaging. Be careful not to damage the original packaging for future transpor- tation. ➡ Remove the accessories box and put on the supplied gloves. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 29 ❷ Fig. 5 ➡ Carefully pull the top foam insert out of the device packaging. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 30 ❸ Fig. 6 ➡ Place the top foam insert upside down (rotated by 180°) on a level, clean and stable surface. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 31 ❹ Fig. 7 ➡ Carefully pull the device by its plastic carrying handle (red) out of the bottom foam insert inside the device packaging. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 32 ❺ Fig. 8 ➡ Place the device upside down into the rotated top foam insert (the carrying handle does not have to be removed beforehand for this purpose). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 33 ➡ Loosen the four hexagon socket head screws of the housing cover with bubble in counterclockwise direction using a suitable tool (e.g. hexagon socket screw key – wrench size 4; not included in delivery). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 34 ❼ Fig. 10 ➡ Carefully lift the housing cover with bubble and disconnect the cable lug of the earthing/grounding cable from the ground lug in the housing body. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 35 Fig. 11 ➡ Completely remove the housing cover with bubble from the housing body. ➡ Remove the transport protection (adhesive tape and lens cap) from the PTZ camera unit. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 36 ➡ Reattach the housing cover with bubble to the housing body (before doing so, reconnect the earthing/grounding cable inside the housing cover to the ground lug in the housing body). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 37 ➡ Tighten the four hexagon socket head screws of the housing cover with bubble in clockwise direction using a suitable torque screw- driver (3.8 Nm) with hex bit (size 4 mm). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 38 ⓫ Fig. 14 ➡ Carefully pull the device out of the foam insert with both hands. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 39 ⓬ Fig. 15 ➡ Insert the device firmly back into the foam insert with the plastic carrying handle (red) pointing upwards. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 40 The foam insert is necessary to prevent the polycarbonate dome bubble from being damaged or scratched when placing down the device. ➡ Rotate the carrying handle vertically by 90°. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 41 (Fig. 17). ➡ Separate the two halves of the remaining cap and then remove both parts from the device (Fig. 18). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 42 Place the individual parts of the plastic handle back into the original packaging of the device for later reuse. Fig. 19 COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 43 ⓯ Fig. 20 ➡ Attach the supplied flexible rubber sleeve (bellows) from the accessories box to the connecting plate of the Mountera® Quick-Lock System. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 44 Fig. 21 ➡ Make sure that the rubber sleeve is correctly seated on all sides to prevent any moisture, dust and dirt from penetrating the device later on. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 45 ➡ Make sure that the locking screw of the Mountera® Quick-Lock System is fully open (turned in counterclockwise direction). For this purpose, use the supplied hexagon socket screw key (wrench size 5) from the accessories box. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 46 (secondary safety component), as shown in Fig. 23, in order to pre- vent the device from accidentally falling down during the following mounting steps. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 47 ➡ Before assembling the device to the bracket, hold the device so that the adjusting screw of the Mountera® Plug is aligned with the lock- ing screw of the bracket. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 48 ➡ Insert the Mountera® Plug into the Mountera® Lock until the spring mechanism inside the bracket locks into place (make sure to keep the device straight when inserting so that the Mountera® Plug does not get jammed). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 49 ➡ Secure the Mountera® Quick-Lock System by turning the locking screw of the bracket fully in clockwise direction. For this purpose, use the supplied hexagon socket screw key (wrench size 5) from the accessories box. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 50 ㉑ Fig. 27 ➡ Carefully remove the foam insert from the device. ➡ Place the foam insert back into the original packaging of the device for later reuse. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 51 ㉒ Fig. 28 ➡ Open the rubber protective cover (captive) of the housing cover locking screw. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 52 ㉓ 5.0 mm Fig. 29 ➡ Loosen the housing cover locking screw in counterclockwise direction with the supplied hexagon socket screw key (wrench size 5). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 53 ㉔ Fig. 30 ➡ Turn the housing cover lock ring in counterclockwise direction as far as it will go. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 54 ㉕ Fig. 31 ➡ Open the housing cover (first lift the cover slightly and then slide it carefully backwards and downwards). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 55 ㉖ Fig. 32 ➡ Unhook the safety cable (secondary safety component) from the safety cable fixation point on the outside of the housing. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 56 ➡ Carry out the cabling and a proper earthing/grounding of the device (see chapter “Connections and Pin Assignment” on page 66). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 57 ㉘ Fig. 34 ➡ Close the housing cover. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 58 ㉙ Fig. 35 ➡ Turn the housing cover lock ring in clockwise direction as far as it will COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 59 ➡ Tighten the housing cover locking screw in clockwise direction with the supplied hexagon socket screw key (wrench size 5). ➡ Close the rubber protective cover of the housing cover locking screw. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 60 ㉛ Fig. 37 By default, the Mountera® Plug is perpendicular to the housing. Therefore, the device should usually be exactly level to the ground after mounting. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 61 ➡ Check whether the device is exactly level to the ground by means of a spirit level. If this is not the case, follow the instructions described for Fig. 39 and Fig. 40 (see below). COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 62 (wrench size 5) in counterclockwise direction (beyond a noticeable end-stop) until you can tilt the device with your hands in all directions with little effort. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 63 ➡ Using a spirit level, align the device so that it is exactly level to the ground. ➡ Finally tighten the locking screw of the ball head in clockwise direction. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 64 “Connections and Pin Assignment” on page 66). ➡ Connect the used power supply unit to the mains socket. The device starts and is ready for operation after a few minutes. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 65 Make sure that the rubber sleeve is correctly seated on all sides to prevent any moisture, dust and dirt from getting between the device and the Mountera® bracket later on. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 66: 10 Connections And Pin Assignment

    Power In Fig. 43 No fan/heater support if operated with Power over Ethernet. Important information on the earthing/grounding connection can be found in the section “Earthing/Grounding” on page 21. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 67: Alarm/Audio

    Audio Out Audio In GND Audio Alarm Out 1 Alarm Inputs For use with potential-free switch contacts. Alarm Relay Outputs Max. 30 V DC, 1 A; no AC. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 68: Power In

    / ③ not used black / ④ not used black / Functional Earth green-yellow Fig. 46: Power cable (5-core, HARTING plug on multi-stranded wires with wire-end ferrules) COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 70: Configuration

    • Microsoft Edge*) • Google*) Chrome*) • Mozilla*) Firefox*) (each in the latest version) Browser settings JavaScript*) enabled Sound Sound card or on-board sound chip (min. 16 bit) COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 71: Establishing The Connection

    The language of the graphical user interface (WebConfig-GUI) can be switched in the top-left corner of the screen without the need to login. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 72: First-Time Access

    (the strength of the selected password is displayed during input). ➡ Click “OK”. After the first successful access to the device, the login dialog is displayed. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 73: Login

    ➡ Finally, click “LOGOUT” to properly log out of the device. Detailed descriptions of the configuration settings can be found in separate documentations that are available at www.dallmeier.com. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 74: Technical Product Specification (Basic Data)

    48 V DC ±5% or PoE+* No fan/heater support if operated with Power over Ethernet. PoE standard IEEE 802.3at Power consumption Max. 25 W (camera) Max. 85 W (with fan/heater) COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 75 The technical product specification (basic data) in this document is based on the information at the time of this document’s compilation. Detailed information and possible updates can be found in the currently valid product specification at www.dallmeier.com. COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...

  • Page 76: 13 Dimensions

    13 Dimensions Fig. 47 COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
  • Page 77 245 mm (9.65") Fig. 48 COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier...
