TuffStuff PXLS-7920 Owner's Manual

Dual rack ( 2 half racks back to back )
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
It is the Purchaser's/Owner's obligation:
1. To disclose and post all Rules & Regulations, Danger, Warning and Caution
labels affixed on the machine to their customers/users.
2. Equipment to be installed by TuffStuff Authorized Dealer or a service
company approved by TuffStuff.
3. Provide trained personnel, supervision and correct usage of the equipment.
4. Provide scheduled inspection, maintenance & repairs and must be performed
by TuffStuff Authorized Dealer or a service company approved by TuffStuff.
5. Must use only genuine TuffStuff replacement parts.
6.
Machine must be anchored to a solid and level surface.
PXLS-7920_Rev1
Revision Date 06-23-2015
OWNER'S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
NOTICE
PXLS-7920
Dual Rack ( 2 Half Racks Back to Back )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PXLS-7920 and is the answer not in the manual?

Questions and answers

Related Manuals for TuffStuff PXLS-7920

Summary of Contents for TuffStuff PXLS-7920

  • Page 1 1. To disclose and post all Rules & Regulations, Danger, Warning and Caution labels affixed on the machine to their customers/users. 2. Equipment to be installed by TuffStuff Authorized Dealer or a service company approved by TuffStuff. 3. Provide trained personnel, supervision and correct usage of the equipment.
  • Page 2 L 96 1/2” x W 65 1/4” x H 97” TuffStuff Fitness Equipment Inc. continually engages in research related to product improvements. Please take the time to carefully read through this manual thoroughly. Instructions contained in this manual are not intended to cover all details or variations possible with this equipment, or to cover every contingency that may be met in conjunction with assembly, installation, operation, mainte- nance or troubleshooting of the equipment.
  • Page 3 Carefully read ALL Danger, Warning & Caution labels posted on the machine TUFFSTUFF SER# 0 0 0 0 0 0 0 PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 4 Facility Sign with your order, you can obtain one at no cost to personnel so that it may be evaluated and you from TuffStuff Fitness by contacting our service department at: service promptly. DO NOT ATTEMPT to use or fix any piece of 1 (888) 884-8275 equipment that is not functioning properly.
  • Page 5 Carefully read ALL Danger, Warning & Caution labels posted on the machine Front View PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 6 Carefully read ALL Danger, Warning & Caution labels posted on the machine Rear View PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )

  • Page 7: Anchoring Unit

    Holes on footplates are provided for anchoring the unit to the floor� (See anchoring hole locations below) 9/16” Diameter Anchoring Hole 9/16” Diameter Anchoring Hole PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )

  • Page 8: Important Safety Instructions

    Always warm-up before and cool-down after weight training. 11. Use only genuine TuffStuff replacement parts. Failure to do so will Warm-up for 10-15 minutes with stretching and cardiovascular void warranty and could result in serious injury or death to the users.

  • Page 9: Registration, Service & Assembly

    Registration, Service & Assembly Thank you for purchasing the PXLS-7920 Dual Rack ( 2 Half Racks Back to Back ). This machine is part of the TuffStuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly.

  • Page 10: Inspection & Maintenance

    Perform regular maintenance (see Inspection Label). Pay special attention to areas most susceptible to wear and tear. TuffStuff recommends you maintain a service contract with a TuffStuff Authorized Dealer or a Professional Service Company approved by TuffStuff. Keep a service log of all maintenance and repair activities. Extra copies can be downloaded from our website.

  • Page 11: Assembly Step

    SPLIT LOCK WASHER Z/P 1/2” Fully Fasten Wrench tighten all hardware in this step. IT IS RECOMMENDED TO HAVE ANOTHER PERSON ASSIST YOU WITH THE INSTALLATION OF THIS UNIT. PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 12 RUBBER WASHER 1 7/8 ID X 4 1/4 OD X 9/16 TK SPLIT LOCK WASHER Z/P 1/2” Fully Fasten Wrench tighten all hardware in this step. Note: Some parts have been removed for Clarity. PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 13 OLYMPIC BAR STORAGE HOOK (PXLS) HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 2 3/4 Fully Fasten Wrench tighten all hardware in this step. Note: Some parts have been removed for Clarity. PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 14 Finger tighten all hardware in this step. DO NOT wrench tighten. Some component(s) may need pre-assembly and alignment during the assembly process. Note: Some parts have been removed for Clarity. PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 15 SAFETY BAR SPOTTER RT Note: Labels facing towards Note: the inside of the Unit. Labels facing towards the inside of the Unit. Note: Some parts have been removed for Clarity. PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 16 FLAT WASHER Z/P 1/2 X 1 3/4 X 3/16 FLAT WASHER SAE Z/P 1/2” NYLON INSERT LOCK NUT Z/P 1/2-13 Fully Fasten Wrench tighten all hardware in this step. Note: Some parts have been removed for Clarity. PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 17 FLAT WASHER Z/P 1/2 X 1 3/4 X 3/16 FLAT WASHER SAE Z/P 1/2” NYLON INSERT LOCK NUT Z/P 1/2-13 Fully Fasten Wrench tighten all hardware in this step. Note: Some parts have been removed for Clarity. PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 18 Note: MAKE SURE ALL FASTENERS ARE Some parts have been removed for Clarity. TIGHT AND COMPONENTS ARE PROPERLY ASSEMBLED. PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 19 Notes PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )

  • Page 20: Exploded View Diagram

    Exploded View Diagram PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 21 Exploded View Diagram PXLS-7920 Dual Rack ( 2 Half Racks Back to Back )
  • Page 22 PXLS-7920 Parts List ITEM DESCRIPTION REV PART NO. BAR-CATCH, SINGLE HOOK (PXLS-7950, 7930, 7910, 7900) UP7601 BOTTOM CONNECTOR 43" (PXLS-7950, 7930, 7910) UP7602 BOTTOM SIDE FRAME 44 3/4" LT (PXLS-7950, 7900) UP7603 BOTTOM SIDE FRAME 44 3/4" RT (PXLS-7950, 7900) UP7604 BOTTOM SIDE FRAME 53"...
  • Page 23 LABEL-WARRANTY COMMERCIAL BNH2927 FACILITY SIGN BE ALERT! THE FITNESS EQUIPMENT... BNH3002 TUFFSTUFF LOGO ALUMINUM SMALL BNH2463 TUFFSTUFF SER# ALUMINUM PLATE .5" X 1.8" X .02" BNH1988 LABEL WARNING ANCHOR BOLT PROXL BNH3016 LABEL WARNING ATTENTION USERS PROXL BNH3019 LABEL WARNING MAXIMUM WEIGHT LOAD PROXL...

  • Page 24: Commercial Warranty

    Six (6) Months: Upholstery, Cables, Finish and Rubber Grips. The obligation of TuffStuff under this warranty is limited to repairing or replacing warranted defective parts as TuffStuff may elect, at TuffStuff’s facility in Chino, California without charge to the purchaser. Purchaser is responsible for installation of repaired or replaced parts, and all transportation and insurance costs on returned or replaced equipment to and from TuffStuff’s facility in Chino.
