NOTICE
It is the Purchaser's/Owner's obligation:
1. To disclose and post all Rules & Regulations, Danger, Warning and Caution
labels affi xed on the machine to their customers/users.
2. Equipment to be installed by Tuff Stuff Authorized Dealer or a service
company approved by Tuff Stuff .
3. Provide trained personnel, supervision and correct usage of the equipment.
4. Provide scheduled inspection, maintenance & repairs and must be performed
by Tuff Stuff Authorized Dealer or a service company approved by Tuff Stuff .
5. Must use only genuine Tuff Stuff replacement parts.
6.
Machine must be anchored to a solid and level surface.
OWNER'S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
BY TUFFSTUFF FITNESS
CG-7511
Back Extension
CG-7511_Rev0
Revision Date 10-30-2012
Advertisement
Table of Contents
Related Manuals for TuffStuff CG-7511
Summary of Contents for TuffStuff CG-7511
- Page 1 Maintenance & Assembly Instructions IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE NOTICE It is the Purchaser’s/Owner’s obligation: BY TUFFSTUFF FITNESS 1. To disclose and post all Rules & Regulations, Danger, Warning and Caution CG-7511 labels affi xed on the machine to their customers/users.
-
Page 2: Table Of Contents
Should additional information be required, or should situations arise that are not covered by this manual, the matter should be directed to Customer Service at Tuff Stuff Fitness Equipment Inc. in Chino, California. CG-7511 Back Extension... -
Page 3: Overhead Specifications
Overhead Specifi cations BY TUFFSTUFF FITNESS L 57” X W 33” X H 59” CG-7511 Back Extension... -
Page 4: Danger, Warning, & Caution Labels Information
Carefully read ALL Danger, Warning & Caution labels posted on the machine CG-7511 Back Extension... - Page 5 Carefully read ALL Danger, Warning & Caution labels posted on the machine CG-7511 Back Extension...
- Page 6 Carefully read ALL Danger, Warning & Caution labels posted on the machine CG-7511 Back Extension...
- Page 7 .net service promptly. DO NOT ATTEMPT to use or fix any piece of equipment that is not functioning properly. ASTM F1749-96 TUFFSTUFF FITNESS EQUIPMENT INC. CHINO, CA 91710 CG-7511 Back Extension...
-
Page 8: Anchoring Unit
ANCHORING UNIT BY TUFFSTUFF FITNESS Holes on shoe plates are provided for anchoring the unit to the fl oor. (See anchoring hole locations below) 7/16” DIAMETER HOLE CG-7511 Back Extension... -
Page 9: Important Safety Instructions
CAUTION: indicates a hazardous situation which, if not avoided, could injury or death. result in minor or moderate injury. CG-7511 Back Extension... -
Page 10: Registration, Service & Assembly
Registration, Service & Assembly BY TUFFSTUFF FITNESS Thank you for purchasing the CALGYM CG-7511 Back Extension. This machine is part of the Tuff Stuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly. -
Page 11: Inspection/Maintenance
Professional Service Company approved by Tuff Stuff . Keep a service log of all maintenance and repair activities. Extra copies can be downloaded from our website. INSPECTION / MAINTENANCE RECORDS DATE REPLACEMENT REPAIRS INSPECTED BY WARRANTY REPAIRS DATE REPLACEMENT REPAIRS INSPECTED BY CG-7511 Back Extension... -
Page 12: Cable Inspection
A BREAK ON THE CABLE CABLE END SLIPPING OUT IMPORTANT NOTE: DAMAGED OR WORNED CABLE (AS SHOWN ABOVE) MAY DAMAGE THE PULLEY(S). YOU MUST INSPECT THE PULLEYS AT THIS TIME FOR WEAR AND TEAR. REPLACE IF NEEDED. CG-7511 Back Extension... -
Page 13: Step 1
Step 1 BY TUFFSTUFF FITNESS WARNING IT IS RECOMENDED TO HAVE ANOTHER PERSON ASSIST YOU WITH THE INSTALLATION ON THIS UNIT. FULLY FASTEN CG-7511 Back Extension... -
Page 14: Step
Step 2 BY TUFFSTUFF FITNESS FULLY FASTEN CG-7511 Back Extension... -
Page 15: Step 3
Step 3 BY TUFFSTUFF FITNESS FULLY FASTEN CG-7511 Back Extension... -
Page 16: Step 4 Cable Routing
Step 4 Cable Routing BY TUFFSTUFF FITNESS CG-7511 Back Extension... -
Page 17: Step 5
Step 5 BY TUFFSTUFF FITNESS CG-7511 Back Extension... -
Page 18: Step
Important Safety Instructions Step 6 BY TUFFSTUFF FITNESS CG-7511 Back Extension... -
Page 19: Basic Exercise Guide
It is the responsibility of the fl oor personnel to instruct users on proper operation of the equipment and review the exercise label as shown below. The intended use of this equipment is for Back Extension exercise only. CG-7511 Back Extension... -
Page 20: Parts List
LABEL CG 7500 SERIES SERIAL # BNH2978 BNH2924 BNH2979 LABEL IMPORTANT ADJUST CABLE TENSION HERE LABEL CALGYM BY TUFFSTUFF FITNESS BNH2925 LABEL IMPORTANT FOR SMOOTH PERFORMANCE... LABEL TUFFSTUFF FITNESS BNH2933 LABEL WEIGHT RESIST 4/C ON 10M LEXAN 9 1/2 X 25 3/8 BNH2195... -
Page 21: Exploded View
Exploded View BY TUFFSTUFF FITNESS CG-7511 Back Extension... -
Page 22: Notes
Notes BY TUFFSTUFF FITNESS CG-7511 Back Extension... -
Page 23: Extra Copy (Inspection/Maintenance)
Professional Service Company approved by Tuff Stuff . Keep a service log of all maintenance and repair activities. Extra copies can be downloaded from our website. INSPECTION / MAINTENANCE RECORDS DATE REPLACEMENT REPAIRS INSPECTED BY WARRANTY REPAIRS DATE REPLACEMENT REPAIRS INSPECTED BY CG-7511 Back Extension... -
Page 24: Warranty
Tuff Stuff ’s facility in Chino. THE FOREGOING SHALL CONSTITUTE THE SOLE REMEDY OF THE PURCHASER AND THE SOLE LIABILITY OF TUFFSTUFF WITH REGARD TO WARRANTY. NO IMPLIED STATUTORY WARRANTY OR IMPLIED STATUTORY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL APPLY.
