- Page 1 LMT SOLID AXLE 4WD MONSTER TRUCK ROLLER, NO ELECTRONICS INCLUDED INSTRUCTION MANUAL BEDIENUNGSANLEITUNG MANUEL D’UTILISATION MANUALE DI ISTRUZIONI Before operating this vehicle, please read all printed materials thoroughly. Horizon Hobby is not responsible for inadvertent errors in this manual.
-
Page 2: Table Of Contents
This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. -
Page 3: Box Contents
BOX CONTENTS INCLUDED REQUIRED COMPONENTS RECOMMENDED COMPONENTS - PART NUMBER 2+ Channel Radio Control System Spektrum DX5C DSMR 5CH TX Only, SR315 Receiver SPM5115, SPMSR315 High Torque Steering Servo Spektrum S6280 SPMSS6280 Spektrum Firma 130 Amp Smart ESC SPMXSE1130 Losi LMT Solid Axle ®... -
Page 4: Install The Receiver
INSTALL THE RECEIVER INSTALL THE WHEELS Install your receiver with double sided tape or hook and loop material. Use the included hardware to mount the wheels to the vehicle. Insert the servo and ESC connectors in the appropriate ports on the receiver. CONTROL DIRECTION TEST Connect the steering drag link to the servo saver (not connected to the servo yet). -
Page 5: Vehicle Maintenance
VEHICLE MAINTENANCE The following items require semi-frequent maintenance. Always clean screw threads and apply removeable thread locking compound when threading machine screws into metal parts. SHOCK DISASSEMBLY/CLEANING Remove the shocks and service as needed. Replace worn parts. LOS243014 Pull the spring up and away from the lower cup. Slide the lower spring cup up and off LOS243012 of the shaft. -
Page 6: Differentials
DIFFERENTIALS Differential Light Weight Oil Heavier Weight Oil Front Increases off-power steering. Oil that is too thin will make diff action inconsistent Increases off-power stability and on-power steering Has less forward drive and can unload the drivetrain easier under Has more acceleration and increases on-power steering, but acceleration, which can be good on rough and slick tracks Center decreases off-power steering. - Page 7 REAR DIFFERENTIAL To remove the rear differential, start by removing the upper 4-link mount bolt. Remove the Sway Bar Links and Shocks from the Axle. Remove the lower 4-link bars from the axle housing. Rear Differential Fluid : 100,000 The axle housing is now free. Remove the third member and pinion gear from the axle mount.
-
Page 8: Chassis
CHASSIS LOS241035 LOS244007 TLR235007 TLR5933 LOS241033 LOS241040 TLR5964 LOS243013 LOS241032 TLR5909 LOS241033 TLR5910 LOS241034 LOS242032 LOS241033 LOS244007 LOS242045 TLR5964 LOS241052 LOS242054 TLR5904 TLR5910 TLR5909 LOS241032 TLR255009 LOS244009 LOS242044 TLR5963 LOSA6940 TLR5904 LOS242032 LOS244007 LOS241050 LOS241052 LOS241044 TLR5905 TLR5904 TLR5905 LOS241052 LOS235025 LOS243013 TLR5905... -
Page 9: Center Differential
CENTER DIFFERENTIAL To remove the center differential from the vehicle, remove the two screws in the center cover to expose the center differential. Remove the four screws holding the diff support blocks, and remove the diff support Center Differential Fluid : 500,000 blocks. -
Page 10: Replacement Parts
REPLACEMENT PARTS English LOS235002 Cap Head Screws M2.5x10mm(10) LOS235012 Set Screws M4x4mm Cup Point(10) LOS235015 Locknut Flanged M5 Serrated (10) LOS235024 Button Head Screws M3x25mm (10) LOS235025 Button Head Screws M3x30mm (10) LOS236001 3.2mm x 7mmx .5mm Washer(10) LOS240016 Body Buttons,Top&Bottom(10):LMT LOS241028 Safety Seat Set: LMT LOS241030... -
Page 11: Recommended Parts
REPLACEMENT PARTS English LOS43032 Foam Tire Insert, MT (2): LMT LOS43033 MT Wheel, Silver (2): LMT LOS43034 MountedMonsterTruckTires,L/R:LMT LOSA6940 6x12x4mm Sealed Ball Bearing (4) LOSA6948 8x14x4 Flanged Rubber Seal BB (4) LOSA6955 5x13x4mm HD Cltch Bearings(2):8B/8T TLR235005 Flat Head Screws, M3 x 18mm (10) TLR235007 Flat Head Screw M2.5 x 10mm (10 TLR235015... -
Page 12: Optional Parts
OPTIONAL PARTS Part # English LOS241027 Cage Set, Complete, Green: LMT LOS241037 Servo Saver Set, 25T, Complete: LMT LOS241039 Side Cage and Lower Bar, Green: LMT LOS241041 Top and Upper Cage Bars, Green: LMT LOS241043 Rear Cage and Hoop Bars, Green: LMT LOS241046 Cage Set Complete, Blue: LMT LOS241047... -
Page 13: Troubleshooting Guide
What this Warranty Covers Purchaser’s Remedy Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon “Product”) will be free from defects in materials and workmanship for a period of 2 years from will, at its option, either (i) service, or (ii) replace, any Product determined by Horizon to be the date of purchase. -
Page 14: Warranty And Service Contact Information
Horizon Technischer Service service@horizonhobby.eu Hanskampring 9 European Union +49 (0) 4121 2655 100 D 22885 Barsbüttel, Germany Sales: Horizon Hobby GmbH COMPLIANCE INFORMATION FOR THE EUROPEAN UNION EU Manufacturer of Record: Horizon Hobby, LLC 2904 Research Road Champaign, IL 61822 USA... - Page 15 WWW.LOSI.COM ©2020 Horizon Hobby, LLC. Losi, Firma, IC5, DSMR, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. Created 08/20 62155 LOS04022...
