  • Page 1 F-14 Tomcat Twin 40mm EDF Scan the QR code and select the Manuals and Support quick links from the product page for the most up-to-date manual information. Scannen Sie den QR-Code und wählen Sie auf der Produktseite die Quicklinks Handbücher und Unterstützung, um die aktuellsten Informationen zu Handbücher. Scannez le code QR et sélectionnez les liens rapides Manuals and Support sur la page du produit pour obtenir les informations les plus récentes sur le manuel.
  • Page 2 This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance.
  • Page 3: Table Of Contents

    Box Contents Quick Start Information Set up your transmitter Transmitter Setup using the transmitter setup chart High Rate Low Rate p = 20mm p = 13mm Aileron Dual Rates q = 20mm q = 13mm p = 15mm p = 10mm Elevator q = 15mm q = 10mm...
  • Page 4: Transmitter Setup

    Transmitter Setup IMPORTANT: Transmitter features, functions and settings not listed in the NX Series Transmitter Setup transmitter setup table should remain at the default settings. These transmitter 1. Power ON your transmitter, click on scroll wheel, roll to System Setup and tables show the basic steps needed to complete setup.
  • Page 5: Battery Installation And Esc Arming

    Battery Installation and ESC Arming Battery Selection A 4S 2200mAh LiPo battery is required. The Spektrum 2200mAh 14.8V 4S 30C LiPo battery (SPMX22004S30) is recommended. Refer to the Optional Parts List for other recommended batteries. If using a battery other than those listed, the battery should be within the range of capacity, dimensions and weight of the Spektrum Li-Po battery packs to fit in the fuselage.
  • Page 6: Safe ® Select Technology

    SAFE Select Technology ® When SAFE Select is activated, bank and pitch limitations keep you from over- CAUTION: Keep all body parts clear of the rotor, intake and exhaust tube controlling the aircraft. Additionally, by releasing the controls in the event you lose and keep the aircraft securely restrained in case of accidental throttle orientation, SAFE Select will keep the activation.
  • Page 7: As3X Control Response Test

    AS3X Control Response Test This test ensures that the AS3X control system is functioning properly. Assemble Aircraft movement AS3X Reaction the aircraft and bind your transmitter to the receiver before performing this test. 1. Raise the throttle to any setting above 25%, then lower the throttle to activate AS3X technology.
  • Page 8: Dual Rates And Control Throws

    Dual Rates and Control Throws Program your transmitter to set the rates and control throws based on your Low Rate High Rate experience level. These values have been tested and are a good starting point to Aileron 13mm 20mm achieve a successful first flight. Elevator 10mm 15mm...
  • Page 9: Hand Launching

    Hand Launching Hand Launching NOTICE: Hand Launching in AS3X mode is not recommended as it may result in a crash. Always hand launch in SAFE mode. • We recommend flying without landing gear when hand launching. • Always hand launch in SAFE mode, into the wind with wings forward (not swept), at 100% power, in high rates.
  • Page 10: Flying Tips And Repairs

    Flying Tips and Repairs Consult local laws and ordinances before choosing a flying location. The E-flite until after touchdown; if you are holding rudder input at touchdown the aircraft will F-14 Tomcat is relatively small and is capable of high speeds, making it capable transition suddenly from no rudder response in the air to a sensitive nosewheel at of covering ground quickly.
  • Page 11: Post Flight

    Post Flight 1. Disconnect the flight battery from the ESC (required for safety and battery life). 5. Repair or replace all damaged parts. 2. Power OFF the transmitter. 6. Store the flight battery apart from the aircraft and monitor the battery charge. 3.
  • Page 12: Replacing A Wing

    Replacing a Wing To replace the wing(s): 1. Remove the bottom fuselage cover from the bottom of the aircraft. 2. Use a magnetized screwdriver to remove the four screws from the bottom of the aircraft that hold the top fuselage cover. 3.
  • Page 13: Power System Installation And Service

    Power System Installation and Service CAUTION: Always disconnect the flight battery before performing motor service. The recommended power system components are given in the Specifications table at the beginning of this manual. 1. Use a fresh hobby knife to cut along the glue seam for the lower rear fan ducting to reveal the ducted fan unit.
  • Page 14: Flight Controller Wiring

    Flight Controller Wiring All the functions of this aircraft are handled in the flight controller. If you need to remove the flight controller it needs to be reinstalled in the same orientation as originally mounted. The servo connectors should be at the rear of the receiver, facing down.
  • Page 15: Troubleshooting Guide

    Troubleshooting Guide Problem Possible Cause Solution Throttle not at idle and/or throttle trim too high Reset controls with throttle stick and throttle trim at lowest setting Aircraft will not Throttle servo travel is lower than 100% Make sure throttle servo travel is 100% or greater respond to throttle but responds to Throttle channel is reversed...
  • Page 16: Replacement Parts

    Replacement Parts Optional Items Part # Description Part # Description EFL01451 Fuselage: F-14 Tomcat 40mm Twin SPMX224S30 14.8V 2200mAh 4S 30C Smart LiPo G2: IC3 EFL01452 Wing Set: F-14 Tomcat 40mm Twin EFLA250 Park Flyer Tool Assortment, 5 pc EFL01453 Taileron Set: F-14 40mm Twin SPMXBC100 Smart Battery Checker and Servo Driver...
  • Page 17: Limited Warranty

    (iii) modification of or to any part Support Inquiry, or call the toll free telephone number referenced in the Warranty and of the Product, (iv) attempted service by anyone other than a Horizon Hobby authorized Service Contact Information section to speak with a Product Support representative.
  • Page 18: Fcc Information

    EU Manufacturer of Record: EU Compliance Statement: F-14 Tomcat Twin 40mm EDF (EFL01450) Horizon Hobby, LLC Hereby, Horizon Hobby, LLC declares that the device is in compliance 2904 Research Road with the following: EU Radio Equipment Directive 2014/53/EU; RoHS 2 Champaign, IL 61822 USA Directive 2011/65/EU;...
  • Page 19 © 2021 Horizon Hobby, LLC. E-flite, AS3X, DSM, DSM2, DSMX, Bind-N-Fly, BNF, the Bind-N-Fly logo, SAFE, the SAFE logo, ModelMatch, EC3, IC3, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. All other trademarks, service marks and logos are property of their respective owners.
