  • Page 1 Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
  • Page 2 This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance.

  • Page 3: Table Of Contents

    First Flight Preparation ..................4 Understanding the Primary Flight Controls............9 Flying Checklist ....................4 Pre-Flight Checklist ..................10 Charging Warnings ....................4 Flying the Blade 330 S Helicopter ..............10 Battery Charging ....................4 Gyro Gain Adjustment ..................10 Installing the DXe Transmitter Batteries (RTF) ............5 Tail Belt Tension .....................10 DXe Transmitter Control (RTF) ................5...

  • Page 4: First Flight Preparation

    First Flight Preparation Flying Checklist • Remove and inspect contents ❏ Always turn the transmitter on fi rst • Begin charging the fl ight battery ❏ Plug the fl ight battery into the lead from the ESC • Install the fl ight battery in the helicopter (once it has been fully charged) ❏...

  • Page 5: Installing The Dxe Transmitter Batteries (Rtf)

    Installing the DXe Transmitter Batteries (RTF) The LED indicator fl ashes and the transmitter beeps progressively faster as the battery voltage drops. Replace the transmitter batteries when the transmitter begins to beep. CAUTION: NEVER remove the transmitter batteries while the model is powered on.

  • Page 6: Smart Throttle (Bnf Only)

    DX6G2, DX6e, DX7G2, DX8G2, DX9, DX18, DX20, iX12, iX20 SYSTEM SETUP FUNCTION LIST Servo Setup Timer Model Type HELI Mode Count Down Chan Travel Reverse Chan Travel Reverse Swash Type Normal Time 4:00 100/100 Normal 100/100 Normal F-Mode Setup Start Throttle Out 100/100 Normal...

  • Page 7: Installing The Flight Battery

    Installing the Flight Battery 1. Lower the throttle. CAUTION: Always disconnect the Li-Po battery from the ESC power lead 2. Power on the transmitter. when not fl ying to avoid over-discharging the battery. Batteries discharged to a voltage lower than the lowest approved voltage may become 3.

  • Page 8: Control Tests

    Control Tests CAUTION: You must complete the Tail Rotor and Cyclic tests prior to every fl ight. Failure to complete the tests and ensuring the sensor corrects in the proper direction can cause the helicopter to crash, resulting in property damage and injury. Tail Rotor 1.

  • Page 9: Low Voltage Cutoff (Lvc)

    Electronic Speed Controller Governor Operation The Blade 330 S Electronic Speed Controller (ESC) utilizes a head speed governor The default throttle curve settings listed in the transmitter setup tables should be to maintain a constant head speed during fl...

  • Page 10: Pre-Flight Checklist

    Establish a low level hover. Deliberately lower the throttle until the from the helicopter when it is fl ying. helicopter lands. The Blade 330 S is intended to be fl own outdoors by experienced pilots When the helicopter is in stunt mode: Takeoff •...

  • Page 11: Post-Flight Inspections And Maintenance

    Shim Factory Reset If the process of tuning the Blade 330 S helicopter results in undesirable fl ight performance, you can reset the settings back to factory defaults by selecting the Factory Reset option in Forward Programming. 1. Enter the Function List 5.

  • Page 12: Advanced Tuning (Non-Forward Programming)

    Your Blade 330 S was setup at the factory and test fl own. The servo adjustment steps are usually only necessary in special circumstances, such as after a crash or Once the servo you wish to adjust is selected, move the cyclic stick left or right to if a servo or linkage is replaced.

  • Page 13: Troubleshooting Guide

    Troubleshooting Guide Problem Possible Cause Solution Low fl ight battery or transmitter battery voltage Fully charge or replace the fl ight battery and/or transmitter batteries receiver is not in bind mode Make sure the bind plug is connected to the receiver BND/DAT port Helicopter will not bind Power on the transmitter while holding the Trainer/Bind switch.

  • Page 14: Limited Warranty

    If this Product needs to be inspected or serviced and is compliant in the country you live and Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased use the Product in, please use the Horizon Online Service Request submission process found (the “Product”) will be free from defects in materials and workmanship at the date of...

  • Page 15: Warranty And Service Contact Information

    Blade 330 S RTF (BLH5900) Blade 330 S BNF Basic (BLH5950) Horizon Hobby, LLC  hereby declares that this product is in compliance with the es- Horizon Hobby, LLC  hereby declares that this product is in compliance with the es- sential requirements and other relevant provisions of the RED and EMC Directives.
  • Page 16 Exploded View / Explosionszeichnung / Vue Éclatée / Vista Esplosa...
  • Page 18 Parts List / Ersatzteile / Pièces de Rechange / Pezzi di Ricambio Part # English Deutsch Français Italiano Blade 450/300x/300CFX: Hauptzahn- B450/300X/300CFX - Couronne princi- Ingran. principale elicoidale 1 BLH1901 Helical Main Gear B450/300X/CFX rad schrägverz. pale hélicoïdale B450/300X/CFX Blade 450/300x/300CFX: Ritzel 10 Z B450/300X/300CFX - Pignon hélicoïdal 2 BLH1902 Helical Pinion 10T B450/300X/CFX...
  • Page 19 Part # English Deutsch Français Italiano Aluminum Motor Mount Set: B450 Aluminium-Motorbefestigungs-Set: Set de fi xations moteur en aluminium : Set montante del motore in allumino: 37 BLH1643 3D/X, B400 B450 3D/X, B400 B450 3D/X, B400 B450 3D/X, B400 Sangles crochet et boucle pour ruban Hook &...
  • Page 20 Optional Parts / Optionale Bauteile / Pièces Optionnelles / Pezzi Opzionali Part # English Deutsch Français Italiano Blade 450/300x/300CFX: Pignone elicoidale 11T BLH1903 Helical Pinion 11T B450/300X/CFX B450/300X/300CFX - Pignon hélicoïdal 11T Ritzel 11 Z schrägverz. B450/300X/CFX Blade 450/300x/300CFX: Pignone elicoidale 12T BLH1904 Helical Pinion 12T B450/300X/CFX B450/300X/300CFX - Pignon hélicoïdal 12T...
  • Page 21 Part # English Deutsch Français Italiano Aluminum 450 Flybarless Conversion Set: Aluminium-450 Flybarless- Set de conversion 450 Flybarless en alumi- Set conversione senza fl ybar 450 in BLH4399 B450 3D Umrüstungs-Set: B450 3D nium : B450 3D alluminio: B450 3D Tail Rotor Blade Set, Orange: B450 3D/X, Heckrotorblatt-Set, orange: B450 3D/X, Set de pales d'anticouple, Orange : B450 Set pale del rotore di coda, arancio-...
  • Page 22 ©2019 Horizon Hobby, LLC. Blade, the Blade logo, SAFE, The SAFE logo, DSM2, DSMX, BNF, the BNF logo, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
