TECHNICAL SPECIFICATIONS AND MAIN WATER BLOCK PARTS

M4 x 27 DIN7984 SCREW
TOP PLATE
(PLEXI / ACETAL)
O-RING
176 x 2
JET
PLATE
M4/M2,5 x 6,6 STANDOFF
TERMINAL (PLEXI / ACETAL)
O-RING 15x1
M4 x 8 DIN7984 SCREW
STANDOUT
EK BADGE
(BLACK / WHITE)
LED
D-RGB STRIP
M4/M2,5 x 2,5
STANDOFF - LONG
COLDPLATE (COPPER / NICKEL)
M4/M2,5 x 2,5 STANDOFF - SHORT
Technical Specification:
- Dimensions (LxHxW): 293 x 154 x 16.4 mm
- D-RGB (Addressable RGB) Cable - Length: 500 mm
- D-RGB LED Count: 12
- D-RGB Connector: Standard 3-Pin (+5V, Data, Blocked, Ground)
- 6 -
