Campbell Hausfeld CHN10210 Operating Instructions Manual

See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . 1
Unpacking . . . . . . . . . . . . . . . . . . . . . . 1
Safety Guidelines . . . . . . . . . . . . . . . . 1
Important Safety Information . . . . . . 1
Tool Components and
Specifications. . . . . . . . . . . . . . . . . . . . 2
Operating Instructions . . . . . . . . . . . . 4
Lubrication . . . . . . . . . . . . . . . . . . . . 4
Recommended Hookup. . . . . . . . . . 4
Operational Mode . . . . . . . . . . . . . . 5
Single Sequential Mode . . . . . . . . . 5
Operating a Sequential Trip Tool . . 5
Loading/Unloading The Tool. . . . . . 5
Adjusting the Nail Penetration . . . . 5
Adjusting the Direction
of the Exhaust . . . . . . . . . . . . . . . . . 5
User-Maintenance Instructions . . . . . 6
Clearing A Jam From The Tool . . . . 6
Technical Service . . . . . . . . . . . . . . . 6
Fastener And Replacement Parts . . 6
Tool Repair . . . . . . . . . . . . . . . . . . . . 6
Assembly Procedure For Seals . . . . . 6
Fastener and Interchange
Information . . . . . . . . . . . . . . . . . . . . . 6
Troubleshooting Chart . . . . . . . . . . . . 7
Warranty . . . . . . . . . . . . . . . . . . . . . . . 8
Description
This nailer is designed for decorative
trim, molding, window casings,
furniture trim and picture frame
assembly. Features include: no-mar tip,
adjustable exhaust, single sequential
trigger, quick clear nose, and an
adjustable depth of drive mechanism.
Campbell Hausfeld Nailers meet or exceed Industries' Standards as set forth by the American
National Standard Institute/International Staple, Nail and Tool Association in ANSI/ISANTA
SNT-101-2002.
© 2010 Campbell Hausfeld/Scott Fetzer
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service.
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
information, that if not followed, may
cause damage to equipment.
NOTE: Information that requires special
attention.
Important Safety Instructions
INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
should always be followed, including
the following:
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
2 inch Brad Nailer
Model CHN10202, CHN10210
Danger indicates
an imminently
Locate model and date code on
tool and record below:
Warning indicates
Model No.: _____________________
a potentially
Date Code: _____________________
Caution indicates
a potentially
CALIFORNIA PROPOSITION 65
Notice indicates
important
contain chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
When using tools, masonry. This dust often contains
basic precautions chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
CHN10202, CHN10210
Retain these numbers for
future reference.
This product or
its power cord may
IN276802AV 3/10
