- Page 1 Combined retractable tie-down and occupant restraints User Manual Instructions for fitting and use...
- Page 2 If you have any questions about your equipment, please contact us. Once again, thank you for placing your confidence in our products! Safe vehicle adaptation solutions For your safety BraunAbility products are designed and tested according to current directives and standards.
- Page 3 Combined retractable tie-down and occupant restraints Safety information Limitation of use General guidance Before installing and using the combined retractable tie-down and occupant restraints Fit and use 10-25 Fitting & using the combined retractable tie-down and occupant restraints Quattro with Retractable Occupant Restraint - Rail floor Quattro Express with Retractable Occupant Restraint - Rail floor Quattro with Retractable Occupant Restraint - Floor anchor Quattro Express with Retractable Occupant Restraint - Floor anchor...
-
Page 4: Safety Information
Combined retractable tie-down and occupant restraints Safety information Limitation of use The development of BraunAbility wheelchair restraints is a continuous process. Applications are added on a regular basis. For more details contact BraunAbility or look on the BraunAbility website. - Page 5 Combined retractable tie-down and occupant restraints Combined retractable tie-down and occupant restraints DI-RQEMK DK-SQPH DI-RQMH STK-SQMT WK-SQEMH...
-
Page 6: General Guidance
Combined retractable tie-down and occupant restraints General guidance • Wheelchair Accessories that have not been approved by the Wheelchair Manufacturer must be removed from the wheelchair and secured in the vehicle during transport to reduce the potential for injury. Refer to ‘Instructions For Use in Transport’ provided with the wheelchair or contact wheelchair manufacturer for further guidance. - Page 7 • The equipment has been tested in a configuration similar to that recommended by BraunAbility and any deviation from the recommendations here is the responsibility of the installer/user.
- Page 8 Combined retractable tie-down and occupant restraints Before installing and using the combined retractable tie-downs with occupant restraints • Ensure that the wheelchair is correctly maintained and that the settings of any adjustable parts are made according to ‘Instructions for Use in Transport’. •...
- Page 9 Combined retractable tie-down and occupant restraints • Wheelchair users, their carers and family are advised to check vehicle specifications to ensure that sufficient floor space is available to accommodate the wheelchair and tie-down system. These distances are based upon the desire to maintain clear zones for potential head excursions of occupants provided with both upper and lower torso restraints.
- Page 10 Combined retractable tie-down and occupant restraints Fit and use Fitting and using combined retractable tie-down and occupant restraint Rail floor - Quattro with retractable occupant restraints - Wheelchair tie-down Removing the wheelchair 1. The rail will have been installed in the vehicle in accordance with our own and tie-down the vehicle converter’s instruction.
- Page 11 Combined retractable tie-down and occupant restraints Figure 3 Figure 1 Figure 2 Double inertia Figure 6 Figure 5 Figure 4...
- Page 12 Combined retractable tie-down and occupant restraints Fit and use Fitting and using combined retractable tie-down and occupant restraint Rail floor - Quattro with retractable occupant restraint - 3 Point configuration Removing the occupant restraint Position the 3 point fixing into the cant rail, (Fig 8), so that it is vertically above the inertia reel casing (Fig 4) fixed onto the floor fixing.
- Page 13 Combined retractable tie-down and occupant restraints Figure 9 Figure 10 Figure 8 Stalk Figure 7 Double inertia Figure 4...
- Page 14 Combined retractable tie-down and occupant restraints Fit and use Fitting and using combined retractable tie-down and occupant restraint Rail floor - Quattro with retractable occupant restraint - 2 Point configuration Removing the occupant restraint Ensure the Comfort Clip (Fig 11A) is released and unfasten the tongue from the grey webbing buckle.
- Page 15 Combined retractable tie-down and occupant restraints Figure 12 Figure 7 Stalk Double inertia Figure 4 Figure 11...
- Page 16 Combined retractable tie-down and occupant restraints Fit and use Fitting and using combined retractable tie-down and occupant restraint Rail floor - Quattro Express with retractable occupant restraints - Wheelchair tie-down Removing wheelchair tie-down The rail will have been installed in the vehicle in accordance with their own and the First remove the occupant vehicle converter’s instruction.
- Page 17 Combined retractable tie-down and occupant restraints Figure 3 Figure 5 Figure 1 Figure 14 Double Figure 6 inertia Figure 13...
- Page 18 Combined retractable tie-down and occupant restraints Fit and use Fitting and using combined retractable tie-down and occupant restraint Floor anchor - Quattro with retractable occupant restraint - Wheelchair tie-down Removing the wheelchair tie-down The floor anchors will have been installed in the vehicle in accordance with our own and the vehicle converters instruction.
- Page 19 Combined retractable tie-down and occupant restraints Figure 16 Figure 6 Figure 5 Figure 2 Indent Double inertia Protrusion Figure 17 Figure 15...
- Page 20 Combined retractable tie-down and occupant restraints Fit and use Fitting and using combined webbing tie-down and occupant restraint Floor anchor - Quattro Express with Retractable occupant restraint - Wheelchair tie-down 1. The Solo anchors will have been installed in the vehicle in accordance with our own Removing occupant restraint and the vehicle converters instruction.
- Page 21 Combined retractable tie-down and occupant restraints Figure 14 Figure 16 Figure 6 Indent Figure 5 Double Protrusion inertia Figure 18 Figure 15...
- Page 22 Combined retractable tie-down and occupant restraints Fit and use Fitting and using combined retractable tie-down and occupant restraint Floor anchor - Quattro or Quattro Express with static occupant restraint Removing occupant restraint 1. The Solo anchors will have been installed in the vehicle in accordance with our own Disconnect the shoulder belt snap and the vehicle converters instruction.
- Page 23 Combined retractable tie-down and occupant restraints Figure 20 Figure 21 Figure 19 Figure 22 Figure 7 Figure 23...
- Page 24 Combined retractable tie-down and occupant restraints Fit and use Fitting and using combined retractable tie-down and occupant restraint Floor anchor - Quattro & Quattro Express with 3 point WAV retractable occupant restraint The floor anchors will have been installed in the vehicle, in accordance with our own and the vehicle converters instructions.
- Page 25 Combined retractable tie-down and occupant restraints Pillar loop Figure 25 Figure 26 Figure 24 cover 7/16" unf x 1.5 bolt Flat washer Drop link adjuster Fixed tongue Plastic 3 bar slide 15mm Running tongue stepped 7/16" unf x 1.5 bolt Weavy Flat washer washer...
-
Page 26: Warranty
BraunAbility products when • All webbing and components can be cleaned as necessary, but care used in conjunction with such should be taken to prevent contamination of the webbings with jointly tested systems. -
Page 27: Declaration Of Conformity
Accredited by URS as testing laboratory in accordance with ISO/IEC 17025:2005 Quality system certified in accordance with ISO 9001:2008 Illustrations, descriptions and specifications in the user manual are based on current product information. BraunAbility UK Ltd reserves the right to make alterations without previous notice. © 2019 BraunAbility UK Ltd... - Page 28 BraunAbility UK Ltd Unwin House Phone: +44 1935 827 740 The Horseshoe, Coat Road E-mail: info@braunability.eu Martock, Somerset, TA12 6EY www.braunability.eu...
