Remove the inspection cover. Remove and discard
6.
gasket.
Remove
the
thumbscrew
7.
crankshaft.
Remove the four 1/4 in. capscrews from the O.D.E.
8.
bearing cover.
Remove the bearing cover and O-ring. Discard the
9.
O-ring.
Bend back the lock washer tabs and remove the
10.
bearing locknut; use 'C' spanner SKF REF HN5 or
equivalent.
Remove the lock washer.
11.
Remove the four 1/4 in. capscrews from the drive
12.
end bearing cover.
Remove the drive end bearing cover complete with
13.
lip seal.
Remove the O-ring and discard.
14.
Carefully pull the shaft from the housing, complete
15.
with drive end bearing.
Remove
the
connecting
16.
assembly and inspect the bushings.
Use a bearing puller to remove the bearing from
17.
the shaft.
Installation
On a new shaft, with a zero lead ground lip seal
1.
surface, no speed-sleeve is required. On an old
shaft, when surface condition dictates, or on a new
shaft with a turned surface, install a speed-sleeve
0.06-0.12 in. (1.52-3.0 mm) past the outside drive
end shoulder. Refer to
Carefully slide the opposite drive end of the shaft
2.
and bearing assembly into the drive end of the
housing through the con-rod bushing and engage
the shaft end in the ODE bearing.
Fit the lock washer, engaging locating tab in the
3.
shaft groove.
Fit the bearing locknut and tighten with 'C' spanner;
4.
bend lock washer tab into groove.
install the appropriate total thickness of shims to
5.
leave 0.007 in. to 0.010 in. (.177-.254mm)
clearance between the ODE bearing and installed
cover.
Fit the ODE bearing cover and new O-ring; secure
6.
with four 1/4 in. capscrews. Tighten to 10 ft-lbs
(13.5 Nm).
Fit the drive end bearing cover complete with lip
7.
seal and new O-ring. Secure with four 1/4 in.
capscrews. Tighten to 10 ft-lbs (13.5 Nm).
If the actuator shaft has been disassembled from
8.
connecting rod, assemble with the bushing fulcrum
pin and snap rings before continuing.
Owner's Manual for Dry-Prime Diesel Trash Pumps
dippers
from
the
rod
actuator
shaft
Figure
4-6.
Carefully lower the pedestal, complete with seal O-
9.
ring and linear bearing, over the actuator shaft.
(Assembly tool [P/N: 52655] is available to assist
with reassembly of the pedestal without damage to
the lip seals. Contact Generac Technical Service.)
Secure the pedestal with the top flat relief properly
10.
oriented to clear the inlet nozzle.
Fit
the
actuator
11.
components. Refer to
Removal and
Installation.
Fill the bearing housing with 10W-30 oil. Fill so
12.
static oil level is at the center of the sight glass. Do
not overfill.
Crankshaft Lip Seal Removal and
Installation
Remove the 1/2 in NPT drain plug from the bearing
1.
housing. Drain and discard oil.
Remove the four 1/4 in. capscrews from the drive
2.
end bearing cover.
Remove the drive end bearing cover complete with
3.
lip seal.
Remove and discard the O-ring.
4.
Pull the lip seal from the cover and discard.
5.
Clean and lubricate the lip seal cavity. Press in the
6.
lip seal fully against the shoulder (lip nearest the
bearing).
Inspect the speed-sleeve; replace if required.
7.
Lubricate the shaft sealing surface.
8.
Fit the new O-ring on the bearing cover and slide
9.
the assembly over the shaft. Align the screw holes.
Secure the cover to the bearing housing with four
10.
1/4 in. capscrews. Tighten to 10 ft-lbs (13.5 Nm).
Fill the bearing housing with 10W-30 oil to where
11.
the static oil level is below the center of the sight
glass. Do not overfill.
Roller Bearing Removal and
Installation
Follow
procedures
in
Installation
and
Crankshaft Lip Seal Removal and
Installation.
Connecting Rod/Drive Rod Assembly
It is recommended that these items be purchased pre-
assembled with bearing finish machined and reamed. For
removal, refer to
Crankshaft Removal and Installation
and
Crankshaft Lip Seal Removal and
Maintenance
neck
seal
and
remaining
Actuator Neck Seal
Crankshaft
Removal
Installation.
and
57
