DB Viewer

The Database Viewer displays and decodes all data mon-
itored by the display. This diagnostic tool allows viewing
data not normally displayed.
The list can be scrolled using buttons 1
closed by pressing button 5
NOTE: The Database Viewer is always in English
regardless of language selected.
Figure 3-45. DB Viewer Menu

Preferred Screen Store

The display automatically stores the current screen as the
preferred screen after a delay of approximately 15 sec-
onds. The display will use the last stored screen on the
next power up.
NOTE: Selecting Restore Defaults restores the Analog
Gauge Pages and default gauges.

Pop-Up Messages and Alerts

Service Required

Users can set up to 16 service timers in hours in the
Configuration menu (refer to
Required pop-up is displayed at power up when one or
more service timers has expired. Pressing any button
removes the pop-up. If no button is pressed, the pop-up
closes in approximately five seconds.
Figure 3-46. Pop-up Warnings of Service Required and

Data Communications Failure

Data Communications Failure
The Data Communications Failure pop-up icon flashes if
the display does not detect data. The warning disappears
and normal operation resumes once data is detected.
Owner's Manual for Dry-Prime Diesel Trash Pumps
and 2 and
.
Service Timers). The Service
NOTE: Incorrectly configuring the Engine Source
address will result in no data available for display.

Data Not Available

Gauges and the Db Viewer will display
data is not available. The display value returns to normal
when parameter data is received.

Adjusting Lighting and Contrast

Pressing button 5 when there is no menu bar opens the
lighting and contrast menu bar. The display has a number
of backlighting levels, allowing the display to be read in the
dark. The level is adjusted by pressing button 1 to
decrease, or button 2 to increase
Contrast is adjusted in the same manner using buttons 3
and 4 .
NOTE: The display adjusts the contrast with ambient
temperature. Manual contrast adjustments are only
necessary with extreme climate change.
Figure 3-47. Lighting And Contrast Menu
Exit menu by pressing button 5
contrast settings are retained after the unit is powered off.
NOTE: If the contrast has been adjusted poorly, the
factory setting is restored by pressing buttons 1 through 4
simultaneously. This action does not change other user-
configured settings.
Operation
if the desired
illumination.
. The lighting and
