Generac Power Systems MAGNUM Owner's Manual page 17

General Information
K
J
Figure 2-6. Diaphragm Vacuum Pump Components - Left Side (4 Inch Shown)
A. Diaphragm vacuum pump
B. Air discharge hose
C. Mechanical seal oil reservoir
D. Priming chamber
E. Suction spool
F. Volute
12
A
I
H
B
C
G
F
G. Run dry gland
H. Grease fittings
I. Frame
J. Shaft and Drive end shaft key
K. Belt and guard
Owner's Manual for Dry-Prime Diesel Trash Pumps
D
E
002334
