Flash Patterns XTP4DS Multi Color (Continued):
For patterns that meet SAE J595 Class1 requirements for Red, Blue, Amber, and White, see S in chart!
For patterns that meet California Title 13 Class B requirements for Red, Blue, and Amber, see C in chart!
For patterns that meet ECE R65 Class 2 Cat X (day & night) requirements for Red, Blue, Amber see E2 in chart!
FLASH PATTERN
RED WIRE
LED Primary Color
UP 1&3, DN 5&7
Modulation Flash Color
8 65
1&3&5&7 only
Modulation Flash Up-Dn
9 66
1&3 Alt 5&7 only
Modulation Flash Rt-Lt
10 67
1&5 Alt 3&7
Modulation Flash CCW
11 68
1&3&5&7 only
Modulation Flash CW
12 69
1&3&5&7 only
Steady Burn 1&3&5&7
13 70
only

Troubleshooting:

The XTP series light head has been thoroughly factory tested. If any of the the device functions fail, please check the following:
1. Be sure the power source is activated, then check all connections both positive and ground at the light head (to assure no open or shorted
circuits).
2. Permanently connecting the Blue programming wire to ground will disable the light head, no matter what the programmed flash pattern.
3. If the Dim function does not operate, verify the Blue wire is connect to positive.
4. If the sync function is not being used and the light head is functioning erratically, verify the Yellow wire is not connected to positive.
Replacement Parts and Accesories:
Description
Bezel Black Plastic CZXTP4DSBZL
Bezel Chrome Plastic XTP4DSCHMBZ
FLASH PATTERN
WHITE WIRE
LED Secondary Color
UP 2&4, DN 6&8
Modulation Flash Color
no
2&4&6&8 only
Modulation Flash Up-Dn
no
2&4 Alt 6&8 only
Modulation Flash Rt-Lt
no
2&6 Alt 4&8
Modulation Flash CCW
no
2&4&6&8 only
Modulation Flash CW
no
2&4&6&8 only
Steady Burn 2&4&6&8
no
only
XTP4DS
no
no
no
no
no
no
