Code 3 XTP Series Installation And Operation Instructions Manual page 4

Flash Patterns XTP4DS Multi Color (Continued):
For patterns that meet SAE J595 Class1 requirements for Red, Blue, Amber, and White, see S in chart!
For patterns that meet California Title 13 Class B requirements for Red, Blue, and Amber, see C in chart!
For patterns that meet ECE R65 Class 2 Cat X (day & night) requirements for Red, Blue, Amber see E2 in chart!
FLASH PATTERN
RED WIRE
LED Primary Color
UP 1&3, DN 5&7
Single 375FPM Ph1
11
Color 1&3&5&7 only
Single 375FPM Ph2
12
Color 1&3&5&7 only
Single 375FPM Alt
13
1&3&5&7 with 2&4&6&8
Single 375FPM Up-Dn
14
1&3 Alt 5&7 only
Single 375FPM Up-Dn
2 15
1&3 Alt 6&8 only
Single 375FPM Rt-Lt
16
1&5 Alt 3&7
Single 375FPM Diago-
17
nal 1&7 Alt 3&5
Single 375FPM CCW
18
1&3&5&7 only
Single 375FPM CW
19
1&3&5&7 only
Dbl 75FPM Ph1 Color
20
1&3&5&7 only
Dbl 75FPM Ph2 Color
21
1&3&5&7 only
Dbl 75FPM Alt
22
1&3&5&7 with 2&4&6&8
Dbl 75FPM Up-Dn 1&3
23
Alt 5&7 only
3 Dbl 75FPM Up-Dn 1&3
24
Alt 6&8 only
Dbl 75FPM Rt-Lt 1&5
25
Alt 3&7
Dbl 75FPM Diagonal
26
1&7 Alt 3&5
Dbl 75FPM CCW
27
1&3&5&7 only
Dbl 75FPM CW
28
1&3&5&7 only
Dbl 120FPM Ph1 Color
29
1&3&5&7 only
Dbl 120FPM Ph2 Color
30
1&3&5&7 only
Dbl 120FPM Alt
31
1&3&5&7 with 2&4&6&8
Dbl 120FPM Up-Dn
32
1&3 Alt 5&7 only
4 Dbl 120PM Up-Dn 1&3
33
Alt 6&8 only
Dbl 120FPM Rt-Lt 1&5
34
Alt 3&7
Dbl 120FPM Diagonal
35
1&7 Alt 3&5
Dbl 120FPM CCW
36
1&3&5&7 only
Dbl 120FPM CW
37
1&3&5&7 only
FLASH PATTERN
WHITE WIRE
LED Secondary Color
UP 2&4, DN 6&8
Single 375FPM Ph1
yes
Color 2&4&6&8 only
Single 35FPM Ph2 Color
yes
2&4&6&8 only
Single 375FPM Alt
yes
2&4&6&8 with 1&3&5&7
Single 375FPM Up-Dn
yes
2&4 Alt 6&8 only
Single 375FPM Up-Dn
yes
5&7 Alt 2&4 only
Single 375FPM Rt-Lt 2&6
yes
Alt 4&8
Single 375FPM Diagonal
yes
2&8 Alt 4&6
Single 375FPM CCW
no
2&4&6&8 only
Single 375FPM CW
no
2&4&6&8 only
Dbl 75FPM Ph1 Color
yes SC
2&4&6&8 only
Dbl 75FPM Ph2 Color
yes SC
2&4&6&8 only
Dbl 75FPM Alt 2&4&6&8
yes SC
with 1&3&5&7
Dbl 75FPM Up-Dn 2&4
yes S
Alt 6&8 only
Dbl 75FPM Up-Dn 5&7
yes S
Alt 2&4 only
Dbl 75FPM Rt-Lt 2&6
yes S
Alt 4&8
Dbl 75FPM Diagonal
yes S
2&8 Alt 4&6
Dbl 75FPM CCW
no
2&4&6&8 only
Dbl 75FPM CW
no
2&4&6&8 only
Dbl 120FPM Ph1 Color
yes
SE2
2&4&6&8 only
Dbl 120FPM Ph2 Color
yes
SE2
2&4&6&8 only
Dbl 120FPM Alt
yes S
2&4&6&8 with 1&3&5&7
Dbl 120FPM Up-Dn 2&4
yes S
Alt 6&8 only
Dbl 120FPM Up-Dn 5&7
yes S
Alt 2&4 only
Dbl 120FPM Rt-Lt 2&6
yes S
Alt 4&8
Dbl 120FPM Diagonal
yes S
2&8 Alt 4&6
Dbl 120FPM CCW
no
2&4&6&8 only
Dbl 120FPM CW
no
2&4&6&8 only
Single 375FPM Rt-Lt 1&5
yes 10
Alt 4&8
Single 375FPM Rt-Lt 3&7
yes 11
Alt 2&6
Single 375FPM Diagonal
yes 12
1&7 Alt 4&6
Single 375FPM Diagonal
yes 13
3&5 Alt 2&8
Single 375FPM CCW
yes 2 14
1&3&5&7 Alt 2&4&6&8
Single 375FPM CCW
yes 15
2&4&6&8 Alt 1&3&5&7
Single 375FPM CW
yes 16
1&3&5&7 Alt 2&4&6&8
Single 375FPM CW
no 17
2&4&6&8 Alt 1&3&5&7
no
Dbl 75FPM Rt-Lt 1&5 Alt
yes SC 18
4&8
Dbl 75FPM Rt-Lt 3&7 Alt
yes SC 19
2&6
Dbl 75FPM Diagonal 1&7
yes SC 20
Alt 4&6
Dbl 75FPM Diagonal 3&5
yes S 21
Alt 2&8
3 Dbl 75FPM CCW 1&3&5&7
yes S 22
Alt 2&4&6&8
Dbl 75FPM CCW 2&4&6&8
yes S 23
Alt 1&3&5&7
Dbl 75FPM CW 1&3&5&7
yes S 24
Alt 2&4&6&8
Dbl 75FPM CW 2&4&6&8
no 25
Alt 1&3&5&7
no
Dbl 120FPM Rt-Lt 1&5 Alt
yes 26
SE2
4&8
Dbl 120FPM Rt-Lt 3&7 Alt
yes 27
SE2
2&6
Dbl 120FPM Diagonal 1&7
yes S 28
Alt 4&6
Dbl 120FPM Diagonal 3&5
yes S 29
Alt 2&8
4 Dbl 120FPM CCW 1&3&5&7
yes S 30
Alt 2&4&6&8
Dbl 120FPM CCW 2&4&6&8
yes S 31
Alt 1&3&5&7
Dbl 120FPM CW 1&3&5&7
yes S 32
Alt 2&4&6&8
Dbl 120FPM CW 2&4&6&8
no 33
Alt 1&3&5&7
no
FLASH PATTERN
RED & WHITE WIRE (to-
gether)
LED Primary Color
UP 1&3, DN 5&7
LED Secondary Color
UP 2&4, DN 6&8
yes
yes
yes
yes
no
no
no
no
yes S
yes S
yes S
yes S
no
no
no
no
yes S
yes S
yes S
yes S
no
no
no
no
no
