Maintenance; Troubleshooting - Code 3 Shield SHL10 Series Installation & Operation Manual

Maintenance:

The Shield™ LED Mini-Bar is designed to be weather proof and maintenance free under normal operating con-
ditions. Refer to the guide below for help with troubleshooting. Should the unit be diagnosed as malfunctioning,
the unit should be removed from service and replaced with a new unit.
WARNING!
Problem
Mini-Bar does not light
Flash Pattern does not change
LED module housings may become hot with extended use. Allow modules to cool completely
before attempting to remove.

TROUBLESHOOTINg

Probable Cause
a. No power to unit
b. Power input wire reversed
c. Damaged or shorted cabling
d. Defective Mini-Bar
a. Not pressing Pattern Change
Switch (Mag Mount)
b. Not applying Power to Pattern
Change Wire (Perm Mount)
5
Remedy
a. Check wire for loose connection
b. Reverse power wires
c. Check cables for damage
d. Contact Service Dept.
a. Use Pattern Change Switch
b. Apply Power to Pattern Change
Wire
