- Page 1 IRS 35 / 50 Assembly and operating instruction MADE IN GERMANY Druck Nr. 29343670en/ 27.12...
-
Page 2: Table Of Contents
English Table of Contents Important notice ......................3 Technical data ......................5 Assembly .......................6 Assembly example: ...................6 Assembly on the booth wall ................6 vertical assembly in the booth corners ..............6 Minimum distances ...................6 Service Address: .....................7 Guarantee .......................7 Handling procedures for return shipments (RMA) - Details for all returns ! ....8... -
Page 3: Important Notice
English Important notice There is a fi re risk if assembled incorrect- ly. Please read these assembly instruc- Dear Customer, tions carefully. Take special note of the measurement details and the following You have purchased a high quality technical notes. system which will provide you with many ye- ars of enjoyable using. - Page 4 • The assembly of the infrared emitter in Although breakage is unlikely if it the booth must be carried out in such a is used properly, if the ceramic way to assure even all-round emission emitter should break, replace it with a for the sauna frequenter.
-
Page 5: Technical Data
Technical data For assembly, the connection cables should be fed through blank tubes or protected from Voltage: 230 V 50 Hz damage in other appropriate ways. Power input: 350 / 500 W To improve the handling of the installation Height: 900 mm from IR emitter in the cabins is the plug un- Width: 184 mm mounted... -
Page 6: Assembly
Assembly Assembly on the booth wall wood protected grid The emitter should be assembled in such a wood border perhaps way as to ensure that the body of the fre- quenter radiates over as large an area as possible. 6 cm Assembly in the four corners of the infrared Fig. -
Page 7: Service Address
Service Address: Outside of Germany please contact your EOS Saunatechnik GmbH specialist dealer in case of warranty claims. Adolf-Weiß-Straße 43 Direct warranty processing with our service 35759 Driedorf-Mademühlen, Germany department is in this case not possible. -
Page 8: Handling Procedures For Return Shipments (Rma) - Details For All Returns
Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an exeption, please follow the procedures specifi ed below.This enabling us to ensure a quick and smooth handling of the return shipment.
