- Page 1 Adam Equipment AGB Bench Scale Software rev: V 1.00 & above...
- Page 2 Easy Reference: Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place: ...
-
Page 3: Table Of Contents
CONTENTS P.N. 3.11.6.6.14276, Rev A1, February 2019 INTRODUCTION ........................... 1 SPECIFICATIONS ..........................2 INSTALLATION ............................. 4 LOCATING THE SCALE ........................4 LIST OF ACCESSORIES ........................4 KEY DESCRIPTIONS ..........................5 ... -
Page 4: Introduction
INTRODUCTION The AGB bench platform scale includes a durable stainless steel base, approvals, and AE403 indicator ideal for general warehouse applications. These scales provide the user with the electronics necessary to build an accurate, fast, versatile weighing system. ... -
Page 5: Specifications
SPECIFICATIONS AGB Standard Models AGB 8 AGB 16 AGB 35 AGB 70 Maximum capacity 8000g 16kg 35kg 70kg Readability 0.1g 0.2g 0.5g Resolution 0.1g 0.2g 0.5g Repeatability 0.1g 0.2g 0.5g Linearity 0.2g 0.4g AGB US Models (standard) AGB 16a AGB 35a AGB 65a AGB 175a... - Page 6 AGB Trade Approved Models AGB 6M AGB 15M AGB 30M AGB 60M Maximum capacity 6000g 15kg 30kg 60kg Readability Resolution Repeatability Linearity Pan size 300 x 400mm Operating temperature 0C-40C Power Supply 6V 4.5Ah Rechargeable battery And AC/DC 12V 800mA power adapter; Battery life 90 hours typical.
-
Page 7: Installation
INSTALLATION LOCATING THE SCALE The scale should not be placed in a location that will reduce the accuracy. Avoid extremes of temperature. Do not place in direct sunlight or near air conditioning vents. Avoid unsuitable tables or surfaces. ... -
Page 8: Key Descriptions
KEY DESCRIPTIONS Sets the zero point for all subsequent weighing. The display shows zero. [Tare/↵] Tares the scale. Stores the weight currently on the scale as tare value, subtracts the tare value from the gross weight and shows the results. A secondary function, is of “Enter”... -
Page 9: Displays
DISPLAYS The LCD display will show a value and a unit to the right of the digits. In addition the LED’s above the display will show when a weight is below or above check- weighing limits. Other symbols will show when a weight has been tared (NET) the scale is at zero and stable, if a value has been stored in memory or when the animal weighing function has been enabled. -
Page 10: Taring
TARING Zero the scale by pressing the [0/Esc] key if necessary. The “ZERO” indicator will be ON. 0 Place a container on the platform, a value for its weight will be displayed. Press the [Tare/↵] key to tare the scale. The weight that was displayed is stored as the tare value and that value is subtracted from the display, leaving zero on the display. -
Page 11: Weighing A Sample
WEIGHING A SAMPLE To determine the weight of a sample, first tare the empty container if it is to be used and then place the sample in the container. The display will show the net weight of the sample and the units of weight currently in use. -
Page 12: Check-Weighing
The display will now show a flashing unit which can be increased or decreased using the ⭡ or ⭣ directional keys. Once you have set the desired sample size, press the [Tare/↵] key. From here you will return to the main piece counting display which will show the number of pieces assigned to the weight on the scale. -
Page 13: Relay Outputs And Checkweighing
For checkweighing in parts counting mode, use the directional buttons ⭡ or ⭣, scroll through to the parts counting mode, “Count” will be shown on the display. Press [Tare/↵] to confirm and follow the same process as outlined above. 6.7.1 Relay outputs and checkweighing The relay outputs are open collector drivers to control an external relay. -
Page 14: Accumulated Total
NOTE: Weight must be more than 20 scale divisions for check weighing to operate. Below 20 scale divisions the LED’s will not light and the beeper will not be on. The Check-weighing function can be set up during Weighing or Parts Counting by entering values as Low or/and High Limits keyed in by the user. -
Page 15: Percent Weighing
To clear the memory (set the value to zero) press the [Power/ST] key during the time the totals are being displayed, “Clear” will flash on the display for 2-3 seconds and then return to the usual weighing display. PERCENT WEIGHING The scale can be set to perform percent weighing. -
Page 16: Animal (Dynamic) Weighing
6.10 ANIMAL (D ) WEIGHING YNAMIC The scale can be set to animal (dynamic) weighing for weighing any items that are unstable or may move. The scale will use a special filter to minimise the effects of any movement while the moving animal or unstable samples are on the scale. -
Page 17: Animal 2 (Dynamic 2) Weighing
To weigh a second subject press the [0/Esc] key and the display will show “LOAD” and the function will be ready for a new measurement, if necessary to zero the display, press the [0/Esc] key again, and then place the next animal on the scale The scale will detect the new weight and hold it as before. -
Page 18: Hold/ Peak Function
be locked for 2 seconds. The display will show the “Hold” symbol while the display is locked. After the 2 seconds delay, the display will now show “UNLOAD”. Remove one of the animal or items, and press [Tare/↵] key to calculate the weight of the removed animal or item. -
Page 19: User Parameters
USER PARAMETERS Pressing the [Func/Set] key and holding for 2 seconds during normal operation allows the user to access the parameters for customising the scale. The parameters are split into 2 groups: Scale parameters (pressing [Func/Set] will access this automatically). -
Page 20: Rs-232 Parameters
Chk bp Checkweighing beeper settings Unit Enable or disable weighing units, will allow Grams disable all units, at least one has to be enabled. Parts counting lb:oz enabled/disabled N (Newtons) Auto-Z Auto zero settings Filter Filter setting to slow, normal Slower Faster or fast... -
Page 21: Print Settings
7.2.1 Print settings Parameter Description Options Default Values or setting [baud rate] Baud Rate 1200 9600 2400 4800 9600 19200 38400 57600 115200 [Language] Select Language EnGLis (English) EnGLis FrEnCH (French) GErmAn (German) SPAn (Spanish) Portug (Portuguese) Itail (Italian) [Accumulation] Enable or disable the Accumulation [Printing... -
Page 22: Pc Settings
Scale will perform the following, depending on the Accumulation and Print Settings: ACCUMULATION AC on AC Off SETTINGS PRINT SETTINGS Accumulate print Print automatically, AUto automatically Do not accumulate Accumulate and Print only Print when [Print/M+/Esc] key is when [Print/M+/Esc] key pressed, pressed. -
Page 23: Battery Operation
BATTERY OPERATION The scales can be operated from the battery if desired. The battery life can be up to 90 hours depending on the load cells used and how the backlight is used. When the battery needs charging a symbol on the display will show less bars in the battery symbol. - Page 24 1: Pin GND, Signal Ground 2: Pin RXD, Received Data 3: Pin TXD, Transmitted Data As viewed from the back of the indicator The scale can be set to print text in English, French, German, Spanish, Italian or Portuguese. See the RS-232 parameters section for details. DATA FORMAT - COMPLETE WEIGHT <cr><lf>...
- Page 25 DATA FORMAT – HOLD <cr><lf> <cr><lf> Date 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> Scale ID 123456 <cr><lf> User ID 234567 <cr><lf> <cr><lf> Hold Wt. 1.000 Kg <cr><lf> <cr><lf> <cr><lf> <cr><lf> <cr><lf> DATA FORMAT – PEAK HOLD <cr><lf> <cr><lf> Date 12/09/2006 <cr><lf>...
- Page 26 DATA FORMAT – PERCENT <cr><lf> <cr><lf> Date 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> Scale ID 123456 <cr><lf> User ID 234567 <cr><lf> <cr><lf> Net Wt. 1.500 Kg <cr><lf> Ref Wt. 1000kg Percent 150.00% <cr><lf> <cr><lf> <cr><lf> <cr><lf> DATA FORMAT – SIMPLE <cr><lf>...
-
Page 27: Input Commands Format
Description ENGLISH FRENCH GERMAN SPANISH ITALIAN PORTUGUESE Date Date Date Datum Fecha Data Data (dd/mm/yyyy) Time (hh:mm:ss) Time Heure Zeit Hora Hora Scale Scale ID Bal ID Waagen ID Bal ID ID Bilancia ID Bal. Identification Number User Identification User ID Util ID Nutzer ID... -
Page 28: Calibration
DESCRIPTION SUGGESTIONS CODES - -oL - - Over-range Remove weight from the scale. If the problem persists contact your dealer or Adam Equipment for assistance. Err 1 Time Setting Error Enter time using correct format and reasonable values. Format: hh:mm:ss... -
Page 29: Replacement Parts And Accessories
Remove the weight from the scale if overloaded. Make sure the pan is attached. Indicates the load cell or the electronics may be faulty. If the problem persists contact your dealer or Adam Equipment for assistance. Err 9 Check weigh limits Shown if the low limit is set higher than the current high limit. -
Page 30: Warranty Statement
This product may include a rechargeable battery that is designed to be removed and replaced by the user. Adam Equipment warrants that it will provide a replacement battery if the battery manifests a defect in materials or workmanship during the initial period of use of the product in which the battery is installed. - Page 31 WEEE 2012/19/EU This device may not be disposed of in domestic waste. This also applies to countries outside the EU, per their specific requirements. Disposal of batteries (if fitted) must conform to local laws and restrictions. Cet appareil ne peut être éliminé avec les déchets ménagers. L’élimination de la batterie doit être effectuée conformément aux lois et restrictions locales. Dieses Gerät nicht mit dem Hausmüll entsorgt. Dispositivo no puede ser desechado junto con los residuos domésticos Dispositivo non può essere smaltito nei rifiuti domestici. FCC / IC CLASS A DIGITAL DEVICE EMC VERIFICATION STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules and Canadian ICES‐003/NMB‐003 regulation. These limits are designed ...
- Page 32 © Copyright by Adam Equipment Co. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
