DENSITY DETERMINATION KIT
for AEA and AEP
BALANCES
OPERATOR'S MANUAL
© ADAM EQUIPMENT CO. LTD.
pn.
Rev. A, May 2002
© Adam Equipment Company 2000

Advertisement

loading
Need help?

Need help?

Do you have a question about the AEA Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Adam Equipment AEA Series

  • Page 1 Adam Equipment DENSITY DETERMINATION KIT for AEA and AEP BALANCES OPERATOR’S MANUAL © ADAM EQUIPMENT CO. LTD. Rev. A, May 2002 © Adam Equipment Company 2000...
  • Page 2 © Adam Equipment Company 2000...
  • Page 3 The Density Kit allows users of the AEA series of analytical balances and the AEP Top loading balances to determine the density of solids and liquids directly using the internal program of the balance. 1. FEATURES ♦ Easy to use - all the activities are described by a message on the display for user.
  • Page 4 Glass Float of known volume, with string hook Thermometer Base to support beaker Beaker Hanger to replace pan on balance Sample pan Clamp for thermometer Additional weights to match pan weight (only in the AEA kit) © Adam Equipment Company 2000...
  • Page 5: Installation

    • Insert the thermometer into the liquid. • Hang the sample support on the hanger if it is to be used. Tare the balance. You are now ready to begin using the density program built into the balance. © Adam Equipment Company 2000...
  • Page 6: Density Measurement

    The balance is capable of measuring the density of either a solid or a liquid. The balance can be used with the Adam Equipment Density Determination Kit as described below or by using the weigh below abilities of the balance.
  • Page 7 Select the option M6 01 to choose Solid Density, Select the liquid to be used, set the temperature for the water or alcohol, or set the density for another liquid. With F enter submenu M6 Density (setting parameters) Enter parameter Name will flash M6 01 Procedure Change procedure name Save choice © Adam Equipment Company 2000...
  • Page 8 The display will guide you through the steps of weighing the sample in air and then weighing it in the liquid. 1. Put the sample on the small test pan above the liquid. 2. After the result is stable (the unit of mass is on) press © Adam Equipment Company 2000...
  • Page 9 4. After the result is stable (the unit of mass is on) press You will see results of the density measurement and other messages. W1 – sample mass in the air, W2 – sample mass in the liquid, D – Density of liquid . © Adam Equipment Company 2000...
  • Page 10 Before proceeding with the density test enter the volume of the float into memory. Enter mode menu Set the cursor next to M6 Density Enter the submenu for M6 Density Enter parameter The Name will flash 01 Procedure Change procedure name to Liquid Density Save choice © Adam Equipment Company 2000...
  • Page 11 Measurement of liquid density compares the weight of the glass float when measured in the air and in the liquid. If necessary install the density determination kit onto the balance as described in the instruction for the Density Determination Kit. © Adam Equipment Company 2000...
  • Page 12 M6 04 Run With F enter mode Density Enter the Density mode immediately regardless of the cursor position. 1. Enter Density Mode 2. Weigh the float in the air and when result are stable press Enter © Adam Equipment Company 2000...
  • Page 13 On the display you will see the computed value of density for the liquid. You will also see additional information: W1 – float mass in the air, W2 – float mass in the liquid V – volume of the float © Adam Equipment Company 2000...
  • Page 14 Each time the PRINT/ENTER is pressed it will increase the number of items stored by one. PROCEDURE Enter Density Mode submenu Set the cursor next to the Statistics parameter. M3 for Liquid Density or M5 for Solid Density Enter 03 Statistic parameter © Adam Equipment Company 2000...
  • Page 15 Enter parameter 01 Statistic Start to buzz Change parameter description to ON Save this setting Stop to buzz Come back to the density mode submenu and continue doing the density test as described above. Enter the Density mode © Adam Equipment Company 2000...
  • Page 16 After collecting some data the results can be viewed and printed. Enter the Density mode submenu Set the cursor next to 03 Statistics Enter the 03 Statistic submenu Set the cursor next to 02 Results Enter to view the results of the statistics © Adam Equipment Company 2000...
  • Page 17 SDV : 0.00 g/cm3 RDV : 0.00 Return to the statistic submenu for the density mode Return to the Density mode. To return to normal weighing press the Mode key then select the weighing mode, M0. © Adam Equipment Company 2000...
  • Page 18 It may be necessary to use an anti-static cleaner on the float. • Wash the beaker before filling it with any liquid. • Place the samples on the weighing pans carefully to avoid shocks to the balance. © Adam Equipment Company 2000...
  • Page 19 (p) and air density (d) at the temperature and pressure measured using other instruments. The values for water density at various temperatures can be found in most chemistry or physics reference texts. A partial list is given below. © Adam Equipment Company 2000...
  • Page 20 0.99996 0.99994 0.99990 0.99985 0.99978 0.99970 0.99961 0.99949 0.99938 0.99924 0.99910 0.99894 0.99877 0.99860 0.99841 0.99820 0.99799 0.99777 0.99754 0.99730 0.99704 0.99678 0.99651 0.99623 0.99594 0.99565 0.99534 0.99503 0.99470 0.99437 0.99403 0.99368 0.99333 0.99297 0.99259 © Adam Equipment Company 2000...
  • Page 21 © Adam Equipment Company 2000...
  • Page 22 © Adam Equipment Company 2000...
  • Page 23 © Adam Equipment Company 2000...
  • Page 24 No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
