Summary of Contents for Adam Equipment ADK 10
- Page 1 Adam Equipment ADK SERIES for USA (P.N. 2693, Revision F7, November 2005) @Adam Equipment Company 2005...
- Page 2 @Adam Equipment Company 2005...
-
Page 3: Table Of Contents
SIMPLE WEIGHING ....................9 WEIGHING-IN ......................9 WEIGHING-OUT ......................10 DEVIATION WEIGHING...................10 BELOW PAN WEIGHING ..................10 CARE AND MAINTENANCE..................11 RS-232C INTERFACE ....................12 RS-232C SPECIFICATIONS ..................12 DATA OUTPUT MODES...................12 COMPUTER INTERFACE ..................14 REPLACEMENT PARTS AND ACCESSORIES ............14 SERVICE INFORMATION ..................15 @Adam Equipment Company 2005... - Page 4 @Adam Equipment Company 2005...
-
Page 5: Introduction
Operating Temperature 5ºC to 30ºC / 41°F-86°F Pan Size 300 x 340 mm 11.8 x 13.4 inches Overall Size 314 x 460 x 164 mm. 12.4 x 18.1 x 6.5 inches Weight 18 Kg / 39.6 lb @Adam Equipment Company 2005... -
Page 6: Installation
Remove the balance from the carton carefully. It is recommended to keep the packaging materials for storing or transporting again, if necessary. In the carton you should find this balance together with: Pan support This instruction manual @Adam Equipment Company 2005... -
Page 7: Setting Up The Balance
• Remove the cover over the protection screw by loosening 2 screws. • Remove the protection screw, place in a safe place in case it is needed for shipping the balance again. Replace the cover. @Adam Equipment Company 2005... -
Page 8: Voltage Selection
• To weigh a magnetic material, a shield should be put on the pan to keep the magnetic material 3~5cm away from the pan or you can use the below pan weighing mode. @Adam Equipment Company 2005... -
Page 9: Calibration
Remove the mass from the pan gently. • Display will show “0.0”. The balance now comes into weighing mode. • Note: if “no CAL” is displayed during calibration, it means that the balance can't be calibrated. @Adam Equipment Company 2005... -
Page 10: Calibration Check
• It is calibrated if the correct weight is displayed. Remove the weight from the pan. • If the value displayed is more or less than ± 0.1g from the standard repeat the calibration procedure. @Adam Equipment Company 2005... -
Page 11: Weighing
Fill the sample into the container. The weight of the sample will be displayed as it fills the container. • Stop filling when the target weight is reached. • If required press the [Tare] key to cancel the total weight. • Repeat with the second material. @Adam Equipment Company 2005... -
Page 12: Weighing-Out
BELOW PAN WEIGHING If you intend to determine specific gravity or to weigh a sample immersed in a special liquid or atmosphere, you need below weighing. An optional weighing underhook is available for this purpose. PREPARATION @Adam Equipment Company 2005... -
Page 13: Care And Maintenance
Don't place a weight beyond the range of the balance on the pan. • Don't dissemble the balance without permission. • Do not expose your balance to extreme moisture or dust over long periods. • It is better to cover your balance after use. @Adam Equipment Company 2005... -
Page 14: Rs-232C Interface
ASCII Connector DB-25P Pin 1 Case Ground Pin 2 Data Output Pin 5 CTS, to RTS on PC or Printer Pin 6 DSR to DTR on PC or Printer Pin 7 Signal Ground DATA OUTPUT MODES @Adam Equipment Company 2005... - Page 15 When in Print key output mode, if the [Print] key is pressed for 4 seconds it will switch over to the Auto output mode. DATA FORMAT WS, +1234.5678 g <CR> <LF> WU, + 1222.5645 g<CR> <LF> WS = stable WU = unstable <CR> = carriage return <LF> = line feed @Adam Equipment Company 2005...
-
Page 16: Computer Interface
120 PRINT #2,X$ 130 GOTO 90 140 END REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your dealer or Adam Equipment. A partial list of such items is as follows- • • Main Power cord Printer, etc. -
Page 17: Service Information
Include any recent history of the unit. For example: -Has it been working since it’s delivered -Has it been in contact with water -Damaged from a fire -Electrical Storms in the area -Dropped on the floor, etc. @Adam Equipment Company 2005... -
Page 18: Warranty Information
WARRANTY INFORMATION Adam Equipment offers Limited Warranty (Parts and Labour) for the components failed due to defects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company. - Page 19 Shielded interconnect cables must be employed with this equipment to insure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Adam Equipment could void the user's authority to operate the equipment. @Adam Equipment Company 2005...
- Page 20 © Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
