Bravo
Owner's Manual
Part Number
8800-999-4 AD
8800/8810

Advertisement

Table of Contents
loading

Related Manuals for CYBEX Bravo 8800

Summary of Contents for CYBEX Bravo 8800

  • Page 1 ® Bravo 8800/8810 Owner's Manual Part Number 8800-999-4 AD...
  • Page 3 International Offices AMERICAS United Kingdom North America Life Fitness UK LTD All Other EMEA Countries and Distributor Business EMEA* Cybex International Inc. Queen Adelaide Bijdorpplein 25-31 Columbia Centre III Ely, Cambs, CB7 4UB 2992 LB Barendrecht 9525 West Bryn Mawr Avenue Telephone: General Office (+44) 1353.666017...

  • Page 4: Table Of Contents

    Cybex International, Inc. DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.

  • Page 5: Safety Guidelines And Practices

    • Fasteners must have a minimum of 500 lbs. tensile capacity. Cybex recommends .3/8” grade 2 bolts or better. A minimum pull force of 220 lbs/100 kgs is required for each anchor position.

  • Page 6: User Safety Precautions

    • DO NOT pin weights on selectorized equipment in an elevated position or use the machine if found in this position • DO NOT increase weight resistance on equipment by any means other than those provided by Cybex. • DO NOT wear loose or dangling clothing or jewelry while using equipment. Stay clear of moving parts.

  • Page 7: Warnings And Cautions

    Warnings and Cautions Warning labels indicate a potentially hazardous situation that could result in serious injury or death if the precautions are not observed. Caution labels indicate a potentially hazardous situation that could result in serious injury or damage to machine if the precautions are not observed.

  • Page 8: Label Placement

    Label Placement The following diagram shows where each label is located. Item Description DE000001-X DE000005-X 8500-025-X 8800-442-X 1011940-0001 Page 8 of 27...

  • Page 9: Assembly

    Assembly Machine Specifications Total Weight and Size: 8800/8810 Bravo Dimensions/Weight 8800 At Use And At Rest 8810 At Use And At Rest L × W × H 45” L 54” W × 77” H 45” L 54” W × 87” H L ×...

  • Page 10: Verify Parts List Shown Below

    Temperature The unit is designed to function normally in an environment with an ambient temperature range of 50° F (10° C) to 104° F (40° C). The unit can be shipped and stored in an environment with an ambient temperature range of 32° F (0°...

  • Page 11: Tools Required

    Part Number Description Diagram Locknut .375-16, Nylon (Included HN704901 with 8810-101) Insert, Plastic 1.00 Dia-11G PN660200 (Included with 8810-101) Loctite #242 (Included with YA000201 8810-101) Tools Required • 9/16" Wrench • 7/32” Allen wrench • 3/4” Socket wrench • Hammer •...
  • Page 12 • Fasteners must have a minimum of 500 lbs. tensile capacity. Cybex recommends .3/8” grade 2 bolts or better. A minimum pull force of 220 lbs/100 kgs is required for each anchor position.
  • Page 13 7. Remove spiral pin securing cable end to top weight using a 3/16” pin punch and hammer. Item Description Qty. Spiral pin Cable Top weight connector 8. Remove guide rod caps. Guide rod cap contains a compression spring that will fly if grasp is not released slowly.
  • Page 14 12. Remove the four BHSCS securing one of the halves. Item Description Screw Locknut 13. Move machine to desired location. 14. Reattach the frame halves and securely tighten the four BHSCS. 15. Reattach Chin-Up Bar. Add Loctite #242 to each BHSCS and threaded holes. Tighten screws securely. Reattach insert plugs.
  • Page 15 Item Description Backing Front sheet Weight decals 2. Place decals front sheet in the correct position on weight plates. 3. Insert a guide pin through each hole of the decals front sheet. A guide pin can be anything that fits through the weight stack hole, such as a weight stack selector pin.
  • Page 16 • Fasteners must have a minimum of 500 lbs. tensile capacity. Cybex recommends .3/8” grade 2 bolts or better. A minimum pull force of 220 lbs/100 kgs is required for each anchor position.

  • Page 17: Exercise

    Exercise Intended Use The intended commercial use of this machine is to aid exercise and improve general physical fitness. Instructions TIP: Read and understand all instructions and warnings prior to using this machine in the Safety section of the Owner’s Manual. All adjustment points on the machine have yellow handles or knobs.
  • Page 18 Arm Extension Trunk Rotation Squat Hip Abduction Hip Adduction Hip Flexion Hip Extension Trunk Flexion Page 18 of 27...
  • Page 19 Trunk Extension Page 19 of 27...

  • Page 20: Maintenance

    Not inhale or swallow any cleaning product. Protect surrounding area/clothing from exposure. Use in well ventilated area. Follow all product manufacturer’s warnings. Cybex and its vendors cannot be held responsible for damage or injuries resulting from the use or misuse of cleaning products.

  • Page 21: Weekly Procedures

    Then Dampen a soft white cloth with rubbing alcohol. More Difficult Stains Gently rub stained area. (Alternative Method) Dampen a clean soft cloth in water and rinse area. Apply a light coat of furniture wax for 30 seconds. Restoring Luster Lightly rub area using a clean white cloth.
  • Page 22 The following conditions may indicate a worn cable: Condition of Cable Diagram A tear or crack in the cable sheath that exposes the cable A kink in the cable A curled sheath Necking - A stretched cable sheath Bars and Handles Inspect bars and handles for wear, paying particular attention to tab area connection points.

  • Page 23: Yearly Procedures

    • Hammer • 3/16” Pin punch Four types of cable tension adjustment are used on Cybex Strength Systems: Jam Nut Adjustment This type of adjustment uses a jam nut and a tension adjustment nut at the cable cam end as the primary adjustment.
  • Page 24 Item Description Qty. Roll pin Top weight connector Cam End Adjustment This type of adjustment uses an adjustment bolt on the pulley bracket. Loosen nut and rotate cam bolt to adjust cable. Item Description Qty. Cam bolt adjustment Page 24 of 27...

  • Page 25: Warranty

    Who Pays Transportation and Insurance For Service If the Product or any covered part must be returned to a service facility for repairs, We, Cybex, will pay all transportation and insurance charges for the first year. You are responsible for transportation and insurance charge after the first year.

  • Page 26: Effects Of State Laws

    Effects of State Laws This warranty gives you specific legal rights, and you may have other rights which vary from state to state and country by country. Warranty Coverage NOTE: There is no warranty coverage for labor on Strength Products. Item 10 Years 5 Years...
  • Page 27 Columbia Center III - 9525 West Bryn Mawr Ave, Rosemont, IL 60018 • 800-351-3737 • 847-288-3700 • FAX 800-216-8893 www.cybexintl.com...
