- Page 1 Installation and Setup Guide 020-102423-01 Velvet LED Display System CorePlus Series (Remote Power)
- Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.
-
Page 3: Table Of Contents
Resetting the breakers..........27 Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 4 Environmental........... . 41 Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 5: Product Overview
Notice. If not avoided, the following could result in property damage. • Always wear clean, lint-free gloves when handling the product. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 6: Power Precautions
Warning! If not avoided, the following could result in death or serious injury. • After the replacement of the power supply, hi-pot and ground/earth bond tests must be performed. Only Christie qualified technicians who are familiar with the necessary precautions can perform these tests. •... -
Page 7: Remote Power Supply Rack Shelf Safety Warnings
A technical supplier specification related to the pixel size, and denotes the size of the surface-mounted diode (SMD) itself. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 8: Product Documentation
Indicates the ratio between the area covered by pixels and the area not covered by pixels. Product documentation For installation, setup, and user information, see the product documentation available on the Christie Digital Systems USA Inc. website. Read all instructions before using or servicing this product. -
Page 9: Typical Led Solution
Remote Power Supply Rack Shelf module, you must purchase a power cord of an adequate length. Christie recommends one of the pre-terminated power cables offered as Christie accessories, or that you create a custom cable using the Christie Main Power Cable Spool (P/N 154-122106-XX), Connector Kit (P/N 154-125109-XX), and Molex Crimping Tool (P/N 154-124108-XX). -
Page 10: Cable And Controller Layout And Design
The video source connections between the cabinets are represented by the blue line. The power connections between the cabinets are represented by the red line. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 11 Connecting the data source cables (on page 23) Connecting the power cables (on page 24) Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 12: Controller Limitations
USB interface for communication with a computer Input selector LCD screen Menu dial for interacting with the menu Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 13 DB9 COM, USB, RJ45 (with SNMP support), USB cascading, and baud rate 115200 bps Power Power switch Power supply port: AC 100-240V~ 50/60hz Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 14: E600 Controller Interface And Ports
RJ45 (Qty. 16) 16-channel Gigabit Ethernet interface, with each channel supporting up to 1G bandwidth Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 15 RGB444 YCbCr444 YCbCr422 YCbCr420 10 bit RGB444 YCbCr444 YCbCr422 YCbCr420 12 bit RGB444 YCbCr444 Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 16: Fe600 Controller Extender Interface And Ports
1G bandwidth Total loading capacity: 8.8 million pixels Low latency is not supported Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 17 Power supply port: AC 100-240V~ 50/60hz Power switch Power supply port: AC 100-240V~ 50/60hz Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 18: Installation And Setup
Configure the E500 controller (on page 31). • Configure the E600 controller (on page 35). Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 19: Installing An Led From The Rear
Warning! If not avoided, the following could result in death or serious injury. • External support for a display wall must be designed and implemented by a Christie qualified installer and must comply with local area regulations and safety standards. - Page 20 1. If the tiles are being mounted on an external support structure, ensure the external support structure is anchored to the wall and/or to the floor. The design and anchoring of the LED display structure is not the responsibility of Christie Digital Systems USA Inc. Contact a Christie representative for structure design options.
-
Page 21: Mounting The Tiles
Warning! If not avoided, the following could result in death or serious injury. • External support for a display wall must be designed and implemented by a Christie qualified installer and must comply with local area regulations and safety standards. -
Page 22: Adjusting The Spacing Between Tiles
4. To test the spacing between tiles, replace the LED modules. Related information Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 23: Connecting The Data Source Cables
7. Connect an Ethernet cable from the first tile in the array to the controller. Related information Cable and controller layout and design (on page 10) Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 24: Connecting The Power Cables
Related information Adjusting the spacing between tiles (on page 22) Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 25: Installing And Configuring The Remote Power Supply Rack Shelf
Remote Power Supply Rack Shelf module, you must purchase a power cord of an adequate length. Christie recommends one of the pre-terminated power cables offered as Christie accessories, or that you create a custom cable using the Christie Main Power Cable Spool (P/N 154-122106-XX), Connector Kit (P/N 154-125109-XX), and Molex Crimping Tool (P/N 154-124108-XX). -
Page 26: Logging In To The Remote Power Supply Rack Shelf Web Interface
The Remote Power Supply Rack Shelf beeps three times, the IP address is reset to 10.10.10.201, and DHCP is disabled. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 27: Changing The Time On The Remote Power Supply Rack Shelf
Remote Power Supply Rack Shelf. 1. Connect the main power cable to the Remote Power Supply Rack Shelf. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 28: Connecting To Video Sources
Remote Power Supply Rack Shelf module, you must purchase a power cord of an adequate length. Christie recommends one of the pre-terminated power cables offered as Christie accessories, or that you create a custom cable using the Christie Main Power Cable Spool (P/N 154-122106-XX), Connector Kit (P/N 154-125109-XX), and Molex Crimping Tool (P/N 154-124108-XX). -
Page 29: Powering On The Array
Turn off each component in the array in the order below. 1. Turn off the controller. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 30 2. Wait for 3-5 minutes after powering off the controller. 3. Turn off each rectifier in the Remote Power Supply Rack Shelf. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 31: Configuring The E500 Controller
1. On the Christie website, navigate to the E500 product page. 2. Switch to the Downloads tab and click Software Downloads. 3. Download and unzip the Christie LED Control Unit E500 Software zip file. 4. Double-click the Christie Controller Software Setup <version>.exe file, and follow the on-screen instructions and install the E500 controller software. -
Page 32: Adjusting The Initial Picture Coordinates
2. Select Configure Screen and click Next. 3. Switch to the Screen Connection tab. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 33: Setting The Input Resolution
Login with the password admin. 5. In the blank area beside the Monitoring icon, right-click and type 666888. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 34 9. To verify the upgrade was successful, in the top left corner of the controller display verify the version number displayed is 1.0.5.9. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 35: Configuring The E600 Controller
1. On the Christie website, navigate to the E600 product page. 2. Switch to the Downloads tab and click Software Downloads. 3. Download and unzip the Christie LED Control Unit E600 Software zip file. 4. Double-click the Christie Controller Software Setup <version>.exe file, and follow the on-screen instructions and install the E600 controller software. -
Page 36: Testing The Communication Between The Controller And Tiles
E identifies the end of the daisy chain. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 37: Setting The Input Resolution
3. Connect an HDMI or Ethernet cable between the computer running the controller software and the controller. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 38 9. To verify the upgrade was successful, in the top left corner of the controller display verify the version number displayed is 1.0.5.9. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 39: Maintaining The Led Panels
Do not use the following products when cleaning the panels: • Compressed air cans • Liquids • Abrasive cloths Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 40: Regulatory
IEC 61000-4-4/EN61000-4-4 • IEC 61000-4-5/EN61000-4-5 • IEC 61000-4-6/EN61000-4-6 • IEC 61000-4-8/EN61000-4-8 • IEC 61000-4-11/EN61000-4-11 Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 41: Environmental
EU Directive (2012/19/EU) on waste and electrical and electronic equipment (WEEE) and the applicable official amendment(s). Velvet LED Display System Installation and Setup Guide–CorePlus Series (Remote Power) 020-102423-01 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 42 Corporate offi ces Worldwide offi ces Christie Digital Systems USA, Inc. Australia Germany Republic of South Africa United Kingdom Cypress ph: +61 (0) 7 3624 4888 ph: +49 2161 664540 ph: +27 (0)11 510 0094 ph: +44 (0) 118 977 8000...
