- Page 1 Installation and Setup Guide 020-102791-02 Velvet LED Display System CorePlus Series (Internal Power)
- Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.
-
Page 3: Table Of Contents
Adjusting the initial picture coordinates........27 Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 4 Environmental........... . 36 Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 5: Product Overview
Notice. If not avoided, the following could result in property damage. • Always wear clean, lint-free gloves when handling the product. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 6: Power Precautions
Warning! If not avoided, the following could result in death or serious injury. • After the replacement of the power supply, hi-pot and ground/earth bond tests must be performed. Only Christie qualified technicians who are familiar with the necessary precautions can perform these tests. •... -
Page 7: Product Documentation
Indicates the ratio between the area covered by pixels and the area not covered by pixels. Product documentation For installation, setup, and user information, see the product documentation available on the Christie Digital Systems USA Inc. website. Read all instructions before using or servicing this product. -
Page 8: Required Tools
LED module removal tool (P/N: 003-006540-XX) • Mounting block template (P/N: 003-006560-XX and 003-006563-XX) • Screws appropriate for the mounting surface. These screws are not provided by Christie. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. -
Page 9: Typical Led Solution
Video matrix switch and splicing video processor E600 LED Display Controller Control computer LED display Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 10: Cable And Controller Layout And Design
The video source connections between the cabinets are represented by the blue line. The power connections between the cabinets are represented by the red line. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 11: Controller Limitations
48 x 24 LED040-CP-I 4.0 mm 16 x 8 32 x 16 64 x 32 Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 12: E500 Controller Interface And Ports
• 12 bit—YCbCr 4:2:2 1080P Supports 3G-SDI progressive input in standard format SDI Loop Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 13: E600 Controller Interface And Ports
Menu dial for interacting with the menu Back button for exiting from the current operation or option in the menu Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 14 Power supply port: AC 100-240V~ 50/60hz Power switch HDMI 8 bit, 10 bit, and 12 bit support Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 15: Fe600 Controller Extender Interface And Ports
Learn about the interface and physical ports on the E600 controller. Front Status display Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 16 Power supply port: AC 100-240V~ 50/60hz Power switch Power supply port: AC 100-240V~ 50/60hz Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 17: Installation And Setup
Configure the E600 controller (on page 30). The controller can be configured at any time. Before connecting the controller to the wall, Christie recommends updating the firmware and configuring the controller. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. -
Page 18: Installing An Led From The Rear
Warning! If not avoided, the following could result in death or serious injury. • External support for a display wall must be designed and implemented by a Christie qualified installer and must comply with local area regulations and safety standards. - Page 19 1. If the tiles are being mounted on an external support structure, ensure the external support structure is anchored to the wall and/or to the floor. The design and anchoring of the LED display structure is not the responsibility of Christie Digital Systems USA Inc. Contact a Christie representative for structure design options.
-
Page 20: Mounting The Tiles
Warning! If not avoided, the following could result in death or serious injury. • External support for a display wall must be designed and implemented by a Christie qualified installer and must comply with local area regulations and safety standards. -
Page 21: Adjusting The Spacing Between Tiles
Related information Mounting the tiles (on page 20) Reinstalling the LED modules (on page 24) Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 22: Connecting The Data Source Cables
7. Connect an Ethernet cable from the first tile in the array to the controller. Related information Cable and controller layout and design (on page 10) Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 23: Connecting The Power Cables
On the rear of the controller, turn the power switch to On. b) On the front of the controller, press the Power button. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 24: Powering Off The Array
The FE600 fiber optic extender can only be used with the E600 controller. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 25 5. Plug the fiber extender power cables into a wall socket. 6. Power on all the components in the tile configuration. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 26: Configuring The E500 Controller
1. On the Christie website, navigate to the E500 product page. 2. Switch to the Downloads tab and click Software Downloads. 3. Download and unzip the Christie LED Control Unit E500 Software zip file. 4. Double-click the Christie Controller Software Setup <version>.exe file, and follow the on-screen instructions and install the E500 controller software. -
Page 27: Adjusting The Initial Picture Coordinates
2. Select Configure Screen and click Next. 3. Switch to the Screen Connection tab. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 28: Setting The Input Resolution
Login with the password admin. 5. In the blank area beside the Monitoring icon, right-click and type 666888. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 29 9. To verify the upgrade was successful, in the top left corner of the controller display verify the version number displayed is 1.0.5.9. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 30: Configuring The E600 Controller
1. On the Christie website, navigate to the E600 product page. 2. Switch to the Downloads tab and click Software Downloads. 3. Download and unzip the Christie LED Control Unit E600 Software zip file. 4. Double-click the Christie Controller Software Setup <version>.exe file, and follow the on-screen instructions and install the E600 controller software. -
Page 31: Testing The Communication Between The Controller And Tiles
E identifies the end of the daisy chain. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 32: Setting The Input Resolution
1. Download the firmware file to a computer that will be connected to the controller for the upgrade, or to a USB key. 2. Unzip the downloaded firmware file. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... - Page 33 9. To verify the upgrade was successful, in the top left corner of the controller display verify the version number displayed is 1.0.5.9. Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©...
-
Page 34: Maintaining The Led Panels
Do not use the following products when cleaning the panels: • Compressed air cans • Liquids • Abrasive cloths Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 35: Regulatory
IEC 61000-4-4/EN61000-4-4 • IEC 61000-4-5/EN61000-4-5 • IEC 61000-4-6/EN61000-4-6 • IEC 61000-4-8/EN61000-4-8 • IEC 61000-4-11/EN61000-4-11 Velvet LED Display System Installation and Setup Guide–CorePlus Series (Internal Power) 020-102791-02 Rev. 1 (06-2018) Copyright 2018 Christie Digital Systems USA, Inc. All rights reserved. ©... -
Page 36: Environmental
