MULTIQUIP WT5C Operation Manual page 22

FILLING THE WATER TANK (FIRE HYDRANT)
1. Remove the water tank cap.
2. Attach hydrant adapter to fire hydrant if necessary.
3. Attach fire hydrant discharge hose between the 2" steel
water tank pipe QD port and the fire hydrant.
4. Make sure there are no bends or sharp kinks in the
hose between the fire hydrant and water tank fill port.
WATER TANK
PAGE 22 — WT5C/WTE5C/WT5CSG WATER TRAILER • OPERATION MANUAL — REV. #4 (03/14/17)
2" DIA.
STEEL PIPE
CAP
2" QD MALE
COUPLER
FIRE HYDRANT
DISCHARGE HOSE
(MQ P/N HDFNST)
Figure 18. Fire Hydrant Connection
5. Slowly open the hydrant valve. Water tank should
begin to fill.
6. Fill the water tank to the desired level and close the
fire hydrant valve.
7. Remove fire hydrant discharge hose and allow the hose
to drain. Remove the hydrant adapter.
NOTICE
Prior to engine start, the pump MUST BE primed. This
is accomplished by removing the Pump Fill Cap and
filling the Pump Casing with water and then re-securing
the fill cap.
OPERATION
WATER TANK
FILL PORT
