3. Connect three paralleling cables from top unit M connector to bottom unit S connector as

illustrated in Figure 6.

1.4.3

G/P-4U-150-600V - Assembly Instructions for four 150V-600V units in Parallel

1.4.3.1 Components List

Figure 6: Four 60V‐100V Units Paralleling Cable Connection


10‐32 x 5/16 Pan Head Screw, Stainless Steel

Helical Spring‐Lock Washer, No. 10, Stainless Steel

Plain Washer, No. 10, Stainless Steel

Connection Plate 4U

Paralleling Cable

Component

Quantity
