- Page 1 Series Programmable DC Power Supplies G7.5kW in 1U 0-1500V, 0-375A PARALLEL KIT INSTRUCTION MANUAL The manual covers kit options: G7.5kW/P-2U: 20-40V G7.5kW/P-2U: 60-1500V...
- Page 2 This page is intentionally left blank.
- Page 3 General The Parallel kit is supplied separately from the power supply packing according to the order. The usage of the parallel kit is according to the customer's needs. Advanced Parallel For parallel connection, refer to the advanced parallel chapter in the Series user manual.
- Page 4 Image Component Quantity Busbars Connector Plate 2U M3 x 4C Flat Head Screw, Nickel Plated Paralleling Cable (G/P) 1.4.1.2 Installation Steps 1. Attach the connection plate and the front connection plate to each side of the power supplies using twelve Pan Head screws and twelve Rip-Lock washers M5 as illustrated in Figure 1. Connection Plate 2U (x2) Front Connection Plate 2U (x2) Rip-Lock Washer M5, BN 84530 (x12)
- Page 5 2. Attach the busbars connector plate to each of the two terminals using eight flat head screws as illustrated in Figure 2. Busbars Connector Plate 2U (x2) M3 x 4C Flat Head Screw (x8) Tightening torque: 4.7-5.7 Lbf-inch (0.53-0.64Nm) Figure 2: Two G7.5kW 20-40V Units — Busbars Connector Plate 2U Assembly 3.
- Page 6 4. Important Note: The assembly of the Advanced Parallel System must be carried out with the power supplies disconnected from the grid (i.e., disconnected from the AC source). Once all the paralleling cables are connected, reconnect all power supplies to the grid (connect to the AC source), turn on the power (power switch ON), and initiate the acknowledgment process.
- Page 7 1.4.2 G7.5kW/P-2U: 60-1500V — Assembly Instructions for two 60V-1500V units in Parallel 1.4.2.1 Components List Image Component Quantity 10-32 x 0.3125 Pan Head Screw, Stainless Steel Rip-Lock Washer M5, BN 84530, Spring Steel Connection Plate 2U Front Connection Plate 2U Busbars Connector Plate 2U M3 x 4C Flat Head Screw, Nickel Plated Paralleling Cable (G/P)
- Page 8 1.4.2.2 Installation Steps Attach the connection plate and the front connection plate on each side of the power supplies using twelve Pan Head screws and twelve Rip-Lock washer M5 as illustrated in Figure 4. Connection Plate 2U (x2) Front Connection Plate 2U (x2) Rip-Lock Washer M5, BN 84530 (x12) 10-32 x 0.3125 Pan Head Screw (x12) Tightening torque: 25.4-31.7 Lbf-inch (2.87-3.58Nm).
- Page 9 2. Attach the busbars connector plate on each of the two terminals using four flat head screws as illustrated in Figure 5. Busbars Connector Plate 2U (X2) M3 x 4C Flat Head Screw (x4) Tightening torque: 4.7-5.7 Lbf-inch (0.53-0.64Nm) Figure 5: Two G7.5kW 60-1500V Units — Busbars Connector Plate 2U Assembly Connect the paralleling cable (G/P) from the J7 (Master) connector of the upper power supply unit to the J6 (Slave) connector of the lower power supply unit, as illustrated in Figure 6.
- Page 10 Important Note: The assembly of the Advanced Parallel System must be carried out with the power supplies disconnected from the grid (i.e., disconnected from the AC source). Once all the paralleling cables are connected, reconnect all power supplies to the grid (connect to the AC source), turn on the power (power switch ON), and initiate the acknowledgment process.
- Page 11 This page is intentionally left blank.
- Page 12 This page is intentionally left blank.
