Altronix VertiLine Rack Mount Power Supplies provide sixteen (16) filtered and electronically regulated power
outputs in a space saving 1U EIA 19" rack mount chassis. The units are available with either 12VDC or 24VDC
power outputs. VertiLine Rack Mount Power Supplies are also available with eight (8) outputs.
Agency Listing:
• CE European Conformity.
Input:
• 220VAC 50/60Hz.
Output:
• Filtered and electronically regulated outputs.
VertiLine33DV, VertiLine33TDV:
• Sixteen (16) PTC protected 12VDC power outputs.
VertiLine63DV, VertiLine63TDV:
• Sixteen (16) PTC protected 24VDC power outputs.
Sixteen (16) Output Rack Mount Configuration Reference Chart:
Altronix
Model Number
VertiLine33DV
VertiLine33TDV
VertiLine63DV
VertilLine63TDV
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or mois-
ture. This installation should be made by qualified service personnel and should conform to
the National Electrical Code and all local codes.
- 2 -
Specifica tions:
Total Output
Output Current
Voltage (Power)
12VDC 8A
12VDC 16A
24VDC 8A
24VDC 16A
Overview:
Features:
• Sixteen (16) power LED indicators.
• Illuminated master power disconnect
circuit breaker with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Removable terminal blocks with locking
screw flange.
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19" rack mount chassis.
• Enclosure Dimensions (H x W x D approx.):
1.625" x 19.125" x 8.5"
(41.3mm x 486mm x 216mm).
Number
of Output
Outputs Protection
16
16
16
16
Current (max.
per output)
PTC 2.5A
PTC 2.5A
PTC 2.5A
PTC 2.5A
VertiLine33DV / 63DV Series Installation Guide
220VAC
50/60 Hz
Input Current
0.75A
1.5A
1.5A
3A
