1. Important Safety Information
Products manufactured by Redring Xpelair Group are safe and without risk
provided they are installed, used and maintained in good working order in
accordance with our instructions and recommendations.
FOR THE USER:
DO NOT operate the unit if the handset or shower hose becomes
damaged.
DO NOT restrict fl ow out of shower by placing shower handset in
direct contact with your body or other object.
WARNING: the outlet of the shower acts as a vent and must not
be connected to anything other than the fl exible shower hose and
handset supplied or approved by the manufacturer.
DO NOT operate the shower if water ceases to fl ow during use
or if water has entered inside the unit because of an incorrectly
fi tted cover.
DO NOT place items such as soap, shampoo or other such
bottles on top of the unit as liquid could leak through the joint
between the cover and back plate and damage the sealing
rubber.
The shower spray head MUST be cleaned regularly to
remove scale and debris. The frequency of the cleaning will
vary according to the local water quality. If the water outlet
temperature becomes hot and you are unable to obtain cooler
water, immediately check the shower handset for blockage. See
section 4 for cleaning instructions.
In order to avoid damage to your shower, the electrical isolation
switch must be turned off between uses.
Under no circumstances must any shower head that is not
approved by the manufacturer be used with this product. Fit only
shower heads recommended by the manufacturer and never fi t
any additional device to restrict the water outlet fl ow.
The outlet must not be connected to any tap or fi tting other than
those specifi ed.
14

7. Product Positioning Guide

Shower unit can be mounted
either side of riser rail.
25mm minimum
Outline of bath or
shower tray
Height of shower handset
and shower to suit user's
requirements
Hose retaining ring
Spillover level
Spillover level
