- Page 1 Rear View camera svstem for Chevrolet Express Vans Product Manual Installation Instructions Rear View Camera Systems Model # RVS-770913 r-, REAR VIEW L_JSAf-ETY Rear View Systems, Inc_" 2017 A Safe Fleet Brand...
- Page 2 What’s in the Box? • 1 Color MT9V139 Weatherproof Backup Camera with Infrareds • 1 DIGITAL 7" TFT LCD Color Rear View Monitor with Universal Mount • 1 3 Channel Multiplexer Control Unit • 1 33’ Extension Cable for Camera •...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................4 Safety Information ..................5-7 Before Beginning Installation..............8 Installation Guide..................9 Wiring Camera & Monitor..............10-11 Installation Diagram .................12 Installing the Monitor ................13 Monitor Operation ................... Splicing......................Positioning....................Multiplexer ....................17 Monitor Dimensions..................18 Monitor Specifications................19 Camera Dimensions...................20 Camera Specifications ................21 Troubleshooting..................22... -
Page 4: Introduction
TV viewer or screen located for- ward of the back of the driver’s seat or in any location that is vis- ible, directly or indirectly, to the driver while operating the vehicle. REAR VIEW SAFETY... -
Page 5: Safety Information
Safety Information Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applica- ble local traffic and motor vehicle regulations as it pertains to this product. -
Page 6: Installation
Dropping the unit may cause is detected, disconnect the possible mechanical failure. system immediately. • Where the power cable may touch a metal case, cover the cable with a friction tape. A short circuit or disconnected wire may cause a fire. REAR VIEW SAFETY... - Page 7 Safety Information IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. Reverse With Confidence ™...
- Page 8 Install split grommets where applicable. Step 3: Once all cables and wiring have been properly routed, perform a system function test by temporarily connecting the system. If the system seems to not be operating properly see troubleshooting (page 22). REAR VIEW SAFETY...
-
Page 9: Installation Guide
Installation Guide Camera 1. Attach camera bracket close to rear marker lights, centered on vehicle. 2. Attach camera to bracket using screws provided and adjust the angle. Cable 1. Be sure to position the cable properly. The aviation camera cable uses aircraft grade connectors which means the camera cable can be exposed to all weather elements, do not run the cable over sharp edges, do not kink the cable and keep away from HOT and rotating parts. -
Page 10: Wiring Camera & Monitor
Camera: Drill a 20mm (0.8in) drain battery. Therefore it is diameter hole into vehicle recommended to connect body near the camera and power to an ignition switched bracket. Insert camera cable into accessory power source. vehicle (be careful not to kink REAR VIEW SAFETY... - Page 11 Wiring Camera & Monitor • Audio works on two ports of consumption is 10 to 30 Volts. multiplexer and positive triggers • When installing all THREE (3) must be triggered for audio to cameras, use all three ports and operate. These are port labeled connect all positive triggers to “backup”...
-
Page 12: Installation Diagram
Installation Diagram Figure 1.1 Figure 1.2 Figure 1.3 REAR VIEW SAFETY... -
Page 13: Installing The Monitor
Installing the Monitor 33ft Extension Cable Monitor Optional Video Out Camera Available -3 Amp Fuse 1. DC12V-24V (red) 2. Ground (black) 3. Port #3 (blue) 4. Port #2 (white) 5. Port #1 (yellow) Camera Reverse With Confidence ™... -
Page 14: Monitor Operation
• Grid Position: Adjust position of distance grid lines • Auto Power: On: Monitor will automatically turn on when powered. Off: Monitor will only turn on when triggered. Auto: Monitor will follow previous state. • Reset: Reset settings to factory default REAR VIEW SAFETY... -
Page 15: Splicing
Splicing 1. Red - Power (+) 2. Yellow - Video 3. Green - Mirror / Normal Imaging 4. White - Audio 5. Black - Ground (-) Reverse With Confidence ™... -
Page 16: Positioning
Positioning REAR VIEW SAFETY... -
Page 17: Multiplexer
Multiplexer Port #1 Port #2 Port #3 or DVD Backup Reverse With Confidence ™... -
Page 18: Monitor Dimensions
Monitor Dimensions REAR VIEW SAFETY... -
Page 19: Monitor Specifications
Monitor Specifications TFT LCD Digital Monitor Screen Size 7” Dot Resolution 800 x 3 (RGB) x 480 Display Format 16:9 Display Brightness 400cd/m Viewing Angle U:50/D:60 L/R:70 Video Input 3 channel Video Source 1Vp-p, 75 Power Supply DC 12V-24V (+/-10%) Power Consumption -10°C - +65°... -
Page 20: Camera Dimensions
Camera Dimensions REAR VIEW SAFETY... -
Page 21: Camera Specifications
Camera Specifications MTV9V139 Sensor Picture Elements 307,200 pixels Gamma Correction r=0.45 to 1.0 Image Sensor 480TV lines, PAL: 720H x 576V NTSC: 720H x 480V Lens 2.1mm View Angle 130° Sync System Internal Synchronization Night Vision Usable Illumination 0.3 Lux Power Source DC 12V-24V (+/-10%) S/N Ratio... -
Page 22: Troubleshooting
Verify Blue trigger is receiving monitor power • Verify camera is connected to cable Audio on Camera Verify chosen camera has audio Confirm that the Blue audio • • Verify volume setting trigger is connected to 12v+ • REAR VIEW SAFETY...
