OnCell G3100 Series User's Manual
Edition 10.0, January 2018
www.moxa.com/product
© 2018 Moxa Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OnCell G3110 and is the answer not in the manual?

Questions and answers

Related Manuals for Moxa Technologies OnCell G3110

Summary of Contents for Moxa Technologies OnCell G3110

  • Page 1 OnCell G3100 Series User’s Manual Edition 10.0, January 2018 www.moxa.com/product © 2018 Moxa Inc. All rights reserved.
  • Page 2 OnCell G3100 Series User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice © 2018 Moxa Inc. All rights reserved. Trademarks The MOXA logo is a registered trademark of Moxa Inc.

  • Page 3: Table Of Contents

    Table of Contents Introduction ............................1-1 Overview ............................1-2 Package Checklist ..........................1-2 Product Features ..........................1-3 Product Specifications ......................... 1-3 DoC (Declaration of Conformity) ......................1-5 Federal Communication Commission Interference Statement ............1-5 OnCell G3100 Series Supporting Information .................. 1-5 FCC Radiation Exposure Statement ....................
  • Page 4 Common Settings ........................6-11 GuaranLink Check Settings ......................6-12 Cellular Network Settings ......................... 7-1 GSM GPRS Settings (For OnCell G3110 and G3150) ................7-2 Cellular Setting (OnCell G3110-HSPA and OnCell G3150-HSPA) ..............7-2 GSM or GSM (CSD) Operation Mode ....................7-3 GPRS or GPRS/EDGE/UMTS/HSPA Operation Mode ................
  • Page 5 Host Table ..........................13-4 System Log Settings ........................13-5 Virtual Server Settings ....................... 13-6 Auto Warning Settings ........................13-7 Event Settings .......................... 13-7 Serial Event Settings ......................... 13-8 E-mail Alert ..........................13-9 SNMP Trap ..........................13-9 SMS Alert ..........................13-10 Customized SMS ........................
  • Page 6 RFC2217 ............................B-1 Dynamic Domain Name Server ......................C-1 Overview ............................C-1 Configuration ............................. C-2 Well-Known Port Numbers ........................ D-1 Auto IP Report Protocol ........................E-1 GSM Alphabet ............................ F-1 Default Settings ..........................G-1...

  • Page 7: Introduction

    Introduction The OnCell G3100 series of cellular IP gateways have many exceptional features. Cellular IP gateways give you an easy way to connect your serial and Ethernet devices to cellular mobile networks. Different models of the OnCell G3100 series differ from their supported cellular standard and serial interface type. For example, OnCell G3110 is a GRPS IP gateway with RS-232 serial interface while OnCell G3150-HSPA is a HSPA IP gateway with RS-232/422/485 serial interface.

  • Page 8: Overview

    ANT-CQB-AHSM-00-3m: Omni 0dBi/10cm, magnetic SMA antenna, 3 m ANT-CQB-AHSM-03-3m: Omni 3dBi/25cm, magnetic SMA antenna, 3 m ANT-CQB-AHSM-05-3m: Omni 5dBi/37cm, magnetic SMA antenna, 3 m • -Five-band GSM/GPRS/EDGE/HSPA antennas for OnCell G3110/G3150-HSPA series (impedance = 50 ohms): ANT-WCDMA-AHSM-04-2.5m: Omni directional, 4dBi/11cm, magnetic SMA antenna, 2.5 m...

  • Page 9: Product Features

    For Ethernet to Cellular, refer chapter 9 for details. For Virtual Modem Mode, refer chapter 10 for details. OnCell Central Ethernet Device Virtual Modem Mode Manager <-> Cellular IP Gateway OnCell G3110 Rev 1.2 – –  OnCell G3150 Rev 1.2 – – ...
  • Page 10 OnCell G3100 Series Introduction OnCell OnCell G3110/G3150 G3110/G3150-HSPA Tx Power 1 watt GSM1800/1900, 1 watt GSM1800, 2 watt EGSM850/900 2 watt GSM900, 0.25 watt UMTS/HSPA, 0.5 watt EDGE900, 0.4 watt EDGE1800 GPRS Multi-slot class GPRS Mobile Class B Station Class EDGE Multi-slot class EDGE Mobile...

  • Page 11: Doc (Declaration Of Conformity)

    OnCell G3100 Series Introduction OnCell OnCell G3110/G3150 G3110/G3150-HSPA Windows Drivers Windows 95/98/ME, Windows NT, Windows 2000/XP/2003/Vista/Server 2008, Windows XP/2003/Vista/Server 2008 x64 Edition Fixed TTY Drivers SCO Unix, SCO OpenServer 5, SCO OpenServer 6, UnixWare 7, SVR4.2, QNX 4.25, QNX 6, Solaris 10, FreeBSD 5, FreeBSD 6 Real TTY Drivers Linux kernels 2.2.x, 2.4.x, 2.6.x Physical Characteristics...

  • Page 12: Fcc Radiation Exposure Statement

    OnCell G3100 Series Introduction FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator & your body.

  • Page 13: Getting Started

    Getting Started This chapter covers the hardware installation of the OnCell G3100. Software installation is covered in the next chapter. The following topics are covered in this chapter:  Panel Layout  Connecting the Hardware  Wiring Requirements  SIM Card Installation ...

  • Page 14: Panel Layout

    OnCell G3100 Series Getting Started Panel Layout Front View OnCell OnCell G3110/G3150 G3110-HSPA/ G3150-HSPA Top View Bottom Views For RS-232 models For RS-232/422/485 models...

  • Page 15: Connecting The Hardware

    OnCell G3100 Series Getting Started Rear View Side Views Connecting the Hardware This section describes how to connect the OnCell G3100 cellular IP gateway to a host PC or serial/Ethernet devices for first time testing purposes. We cover topics such as: Wiring Requirements, SIM Installation, DIN-Rail Mounting, Connecting the Power, Connecting to a Serial Device, Connecting to an Ethernet Device, Adjustable Pull High/Low Resistors for the RS-485 Port, and LED Indicators.

  • Page 16: Wiring Requirements

    OnCell G3100 Series Getting Started Wiring Requirements ATTENTION Safety First! Be sure to disconnect the power cord before installing and/or wiring your device. The OnCell G3100 should be secured at one location. Wiring Caution! Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum current allowable for each wire size.

  • Page 17: Connecting The Power

    OnCell G3100 Series Getting Started ATTENTION If the IP gateway is in GSM/GPRS mode, SIGNAL LEDs will not be illuminated if the phone number or APN is incorrect. Check the GSM LED if the SIM card is installed correctly. The GSM LEDs on the front panel provide a convenient way of checking if the SIM card is installed properly. If the antenna is installed and the network is operating normally, then at least one of the three SIGNAL LEDs should be illuminated at all times.

  • Page 18: Connecting To The Network

    The Ethernet LED flashes when Ethernet packets are being transmitted or received. Connecting to a Serial Device The OnCell G3110/G3110-HSPA supports one RS-232 port that connects through a DB9 male connector on the bottom panel. The OnCell G3150/G3110-HSPA supports one RS-232 port that connects through a DB9 male connector on the bottom panel, and one RS-422/RS-485-4w/RS-485-2w that connects through a 5-pin terminal block on the bottom panel.
  • Page 19 OnCell G3100 Series Getting Started • To set the termination resistor to 150 KΩ, make sure both of the assigned DIP switches are in the OFF position. This is the default setting. • To set the termination resistor to 1 KΩ, make sure both of the assigned DIP switches are in the ON position.

  • Page 20: Led Indicators

    OnCell G3100 Series Getting Started LED Indicators The LED indicators on the front panel of the OnCell series are described in the following table. LED Name LED Color LED Function Green DC Power is active. Power is off, or power error condition exists. Green The serial port is transmitting data.

  • Page 21: Reset Button

    OnCell G3100 Series Getting Started Reset Button Press the Rest button continuously for 5 sec to load factory defaults: Use a pointed object, such as a straightened paper clip or toothpick, to press the reset button. This will cause the Ready LED to blink on and off. The factory defaults will be loaded once the Ready LED stops blinking (default IP: 192.168.127.254).

  • Page 22: Initial Ip Address Configuration

    Initial IP Address Configuration When setting up the OnCell G3100 for the first time, the first thing you should do is configure its IP address. This chapter introduces the different methods that can be used. Please refer to Chapter 14: System Management Settings, for more details about network settings.

  • Page 23: Static And Dynamic Ip Addresses

    OnCell G3100 Series Initial IP Address Configuration Static and Dynamic IP Addresses Determine whether your OnCell G3100 needs to use a static IP address or dynamic IP address (either DHCP or BOOTP application). • If your OnCell G3100 is used in a static IP environment, you must assign a specific IP address using one of the tools described in this chapter.

  • Page 24: Telnet Console

    OnCell G3100 Series Initial IP Address Configuration ATTENTION In order to use the ARP setup method, both your computer and the OnCell G3100 must be connected to the same LAN. You may use an Ethernet cable to connect the OnCell G3100 directly to your computer’s Ethernet card.
  • Page 25 OnCell G3100 Series Initial IP Address Configuration 1. From the Windows desktop, select Start  Run, and then type the following content in the Run window: telnet 192.168.127.254 If your IP address is different from the default setting, use your IP address instead. Click OK. 2.
  • Page 26 OnCell G3100 Series Initial IP Address Configuration 5. Press B or use the arrow keys to select Basic, and then press ENTER. 6. Use the arrow keys to move the cursor to IP address. Use the DELETE, BACKSPACE, or SPACE keys to erase the current IP address, and then type in the new IP address and press ENTER.
  • Page 27 OnCell G3100 Series Initial IP Address Configuration 9. Press A or use the arrow keys to select Save and then press ENTER. Press ENTER again to confirm the save command. 10. Press R or use the arrow keys to select Restart and then press ENTER. 11.

  • Page 28: Serial Console

    OnCell G3100 Series Initial IP Address Configuration Serial Console The OnCell G3100 supports configuration through the serial console, which is the same as the Telnet console but accessed through the RS-232 console port rather than over the network. Once you have entered the serial console, the configuration options and instructions are the same as if you were using the Telnet console.
  • Page 29 OnCell G3100 Series Initial IP Address Configuration 7. If the OnCell G3100 has been set up for password protection, you will be prompted to enter the password. After you enter the password, or if password protection was not enabled, you will be prompted to select the terminal mode.

  • Page 30: Introducing Serial Port Operation Modes

    Introducing Serial Port Operation Modes In this chapter, we describe the various operation modes of the OnCell G3100. The OnCell G3100 modes are grouped by type of application, such as Device Control. The options include an operation mode that relies on a driver installed on the host computer, and operation modes that rely on TCP/IP socket programming concepts.

  • Page 31: Overview

    OnCell G3100 Series Introducing Serial Port Operation Modes Overview The OnCell G3100 IP gateway can cellular network-enable a serial device. OnCell G3100 IP gateway device is assigned an IP address by your service provider (your “cellular ISP”). In addition, the OnCell G3100 IP gateway can cellular network-enable Ethernet devices on the local Ethernet –...

  • Page 32: Types Of Real Com Connection

    OnCell G3100 Series Introducing Serial Port Operation Modes In Real COM mode, the bundled drivers are able to establish a transparent connection between a host and a serial device by mapping the serial port on the OnCell G3100 to a local COM/TTY port on the host computer. Real COM mode supports up to 2 simultaneous connections that enable 2 hosts to simultaneously collect data from the same serial device.

  • Page 33: Reverse Real Com And Secure Reverse Real Com Modes

    OnCell G3100 Series Introducing Serial Port Operation Modes Domain name with DDNS If your cellular service provider offers a public IP address after you connect to the cellular network, you can also access the OnCell G3100 using the domain name. To do this, you will need to register with a DDNS service provider and then enable the DDNS function in the OnCell G3100.

  • Page 34: Rfc 2217 Mode

    OnCell G3100 Series Introducing Serial Port Operation Modes Reverse Real COM to PC’s domain name With Reverse Real COM mode, you can connect to a PC host using the PC’s IP address. You can also connect to your PC host with the PC’s domain name, if you have one. Please refer to Appendix C for more information. RFC 2217 Mode RFC-2217 mode is similar to Real COM mode in that a driver is used to establish a transparent connection between a host computer and a serial device by mapping the serial port on the OnCell G3100 to a local COM...

  • Page 35: Types Of Tcp Server Connection

    OnCell G3100 Series Introducing Serial Port Operation Modes Types of TCP Server Connection Fixed Public IP for the OnCell If your cellular service provider offers a fixed public IP address after you connect to the cellular network, you can access the OnCell G3100 from a host PC using either a private IP or public IP. Using Auto IP report If your cellular service provider offers a dynamic public IP address after you connect to the cellular network, you can access the OnCell G3100 from a host PC using a fixed public IP.

  • Page 36: Tcp Client And Secure Tcp Client Modes

    OnCell G3100 Series Introducing Serial Port Operation Modes TCP Client and Secure TCP Client Modes In TCP Client mode, the OnCell G3100 can actively establish a TCP connection to a pre-defined host computer when serial data arrives. After the data has been transferred, the OnCell G3100 can automatically disconnect from the host computer by using the Inactivity time settings.

  • Page 37: Udp Mode

    OnCell G3100 Series Introducing Serial Port Operation Modes UDP Mode Compared to TCP communication, UDP is faster and more efficient. In UDP mode, you can unicast to one host or multicast to multiple hosts and the serial device can receive data from one or multiple host computers. These traits make UDP mode especially well-suited for message display applications.

  • Page 38: Ethernet Modem Mode

    OnCell G3100 Series Introducing Serial Port Operation Modes Ethernet Modem Mode Ethernet Modem mode is designed for use with legacy operating systems, such as MS-DOS, that do not support TCP/IP networks. By connecting a properly configured OnCell G3100 serial port to the MS-DOS computer’s serial port, it is possible to use legacy software to transmit data over the cellular network, even if the software was originally designed to transmit data through a modem.

  • Page 39: Introducing Oncell Central Manager And Ethernet Operation Modes

    Introducing OnCell Central Manager and Ethernet Operation Modes In this chapter, we introduce OnCell Central Management Software for host and device sites in the private IP domain. We also describe the Ethernet operation modes of the OnCell G3100. The OnCell G3100 not only connects serial devices to cellular networks, but Ethernet devices as well.

  • Page 40: Oncell Central Management Software

    OnCell G3100 Series Introducing OnCell Central Manager and Ethernet Operation Modes OnCell Central Management Software In the cellular world, most service providers only offer private IP addresses to mobile devices due to the limited availability of public addresses. Mobile devices configured with a private IP address can access resources on the Internet, but the mobile devices cannot be managed or accessed directly from the Internet since the private IP address is hidden.

  • Page 41: Oncell Central Ethernet Device Connection

    OnCell G3100 Series Introducing OnCell Central Manager and Ethernet Operation Modes OnCell Central Ethernet Device Connection If your device is Ethernet interface, and your cellular service provider assigns you a private IP address after you connect to the cellular network, service forwarding allows you to access the OnCell G3100 via an OnCell Central Server from any host PC using either a private IP or public IP address.

  • Page 42: Virtual Modem Mode

    OnCell G3100 Series Introducing OnCell Central Manager and Ethernet Operation Modes Virtual Modem Mode Note: This function is only supported by the OnCell G3100 HW Rev. 2.0 and Rev. 3.0. Please refer to the Specifications section of Chapter 1 (page 1-3) for more information. Virtual Modem mode is designed for AT command operating system devices.

  • Page 43: Using The Web Console

    Using the Web Console The web console is the most user-friendly method available to configure the OnCell G3100. With a standard web browser, you have easy and intuitive access to all settings and options. In this chapter, we introduce the web console and go through the basic configuration options.

  • Page 44: Using Your Web Browser

    OnCell G3100 Series Using the Web Console Using Your Web Browser Browser Cookie Settings Verify that cookies are enabled for your browser. If the cookies are disabled, you will not be able to use the web console. (Cookies are only used for password transmission.) 1.

  • Page 45: Trusted Site Settings

    OnCell G3100 Series Using the Web Console Trusted Site Settings Windows 2003 users may need to add the OnCell G3100’s IP address to their browser’s list of trusted sites. 1. If you see the following window while attempting to view the web console, click on Add to modify the list of trusted sites.

  • Page 46: Opening The Web Console

    OnCell G3100 Series Using the Web Console After adding the OnCell G3100’s IP address as a trusted site, you should be able to view the web console by entering the OnCell G3100’s IP address in your browser’s address bar. Opening the Web Console Open your web browser and enter 192.168.127.254 in the website address line.

  • Page 47: Web Console Navigation

    OnCell G3100 Series Using the Web Console The OnCell G3100’s web console will appear. ATTENTION In the Overview page you will find general information about the device such as firmware version, IP address and signal RSSI. In particular, the RSSI value displayed here can be mapped to the dBm value specific to the cellular module used for the OnCell: RSSI RSSI...

  • Page 48: Basic Settings

    OnCell G3100 Series Using the Web Console Basic Settings The Basic Settings screen can be accessed from the navigation panel. Server Settings Device name: This is an optional free text field for your own use; it does not affect the operation of the OnCell G3100, and can be used to help differentiate one OnCell G3100 server from another.

  • Page 49: Network Settings

    OnCell G3100 Series Using the Web Console Time server: The OnCell G3100 uses SNTP (RFC-1769) for auto time calibration. You may enter a time server IP address or domain name in this optional field. Once the OnCell G3100 is configured with the correct time server address, it will request time information from the time server every 10 minutes.
  • Page 50 OnCell G3100 Series Using the Web Console NOTE You must assign a valid IP address to your OnCell G3100 before it will work in your network environment. Your network system administrator should provide you with a unique IP address and related settings for your network.

  • Page 51: Dns Settings

    OnCell G3100 Series Using the Web Console DNS relay (default=Enable): If you enable DNS relay, your computers will use the router as a DNS server. If you disable DNS relay, transfer the DNS server information from your ISP to your computers. Start IP address: Enter the starting IP addresses for the DHCP server's IP assignment.

  • Page 52: Auto Ip Report Settings

    OnCell G3100 Series Using the Web Console Gratuitous ARP: In some applications, you may need the OnCell G3100 to send broadcast packets to update the ARP table on the server. If you enable this function and set the send period, the OnCell G3100 will periodically send broadcast packets at the specified time interval.

  • Page 53: Guaranlink Settings

    OnCell G3100 Series Using the Web Console GuaranLink Settings Overview Connection failures of wireless connections can be caused by a number of different factors, including loss of cellular signal, interference, or termination by the operator for unknown reasons. Typically, cellular routers will not be alerted when a connection is terminated due to inactivity.

  • Page 54: Guaranlink Check Settings

    OnCell G3100 Series Using the Web Console GuaranLink Check Settings ISP initial connection check (default=Disable): This function ensures that the OnCell can establish a connection with an ISP after it reboots. Cellular connection alive check (default=Disable): Some ISPs may disable the connection if no data is transmitted in a specific period of time.

  • Page 55: Cellular Network Settings

    SMS. The configuration options discussed here are also available from the Telnet and serial consoles. The following topics are covered in this chapter:  GSM GPRS Settings (For OnCell G3110 and G3150)  Cellular Setting (OnCell G3110-HSPA and OnCell G3150-HSPA) ...

  • Page 56: Gsm Gprs Settings (For Oncell G3110 And G3150)

    OnCell G3100 Series Cellular Network Settings GSM GPRS Settings (For OnCell G3110 and G3150) From the left navigation panel, click Network Settings  GSM GPRS Settings to configure the GSM/GPRS/SMS Settings. The various configuration items are described below: Type: The OnCell G3100 supports 3 types of operation modes. You may choose from GSM, GPRS, and SMS.

  • Page 57: Gsm Or Gsm (Csd) Operation Mode

    OnCell G3100 Series Cellular Network Settings SIM PIN: This is a pin code that locks the SIM card until you enter the correct code. Use the pin to protect your account. The default code is set by the Service Provider. Note that a cell phone must be used to change the PIN. Selecting the Radio Band: Although GSM-900 and GSM-1800 are used in most parts of the world, operators in United States, Canada, and many other countries in the Americas use GSM-800, GSM-850, GSM-1900, AWS 1700, or GSM-2100.

  • Page 58: Gprs Or Gprs/Edge/Umts/Hspa Operation Mode

    OnCell G3100 Series Cellular Network Settings Option Description Local Verify the ID against the OnCell G3100 password. The user name for the OnCell G3100 is fixed to “admin.” None Authentication is not required. Phone number: Use this field to configure the number used to dial out. Initial string: Use this field to configure the initial string that the IP gateway will use to establish the connection.

  • Page 59: Sms Operation Mode

    OnCell G3100 Series Cellular Network Settings PPP Config: This option allows the user to manually configure PPP authentication methods. Some cellular providers may require users specify the dial-up number or PPP authentication method. ATD: This is the number that the OnCell uses to dial onto the data network. Different countries may require different dial-up numbers (default: *99***1#).

  • Page 60: Virtual Modem Operation Mode

    OnCell G3100 Series Cellular Network Settings Virtual Modem Operation mode Virtual Modem mode (only available for OnCell G3110/G3150) is designed for AT command operating system devices. For more details, please refer to Chapter 5 for an introduction and Chapter 10 for configuration settings.

  • Page 61: Configuring Serial Port Operation Modes

    Configuring Serial Port Operation Modes In this chapter, we explain how to configure the individual serial port modes. The following topics are covered in this chapter:  Port Setting Basics  Device Control Applications  Real COM Mode  Reverse Real COM Mode ...

  • Page 62: Port Setting Basics

    OnCell G3100 Series Configuring Serial Port Operation Modes Port Setting Basics To configure the operation mode and settings for a port, expand Serial Port Settings in the navigation panel, and then expand the port that you would like to configure. Individual port settings are grouped into three categories in the navigation panel: Operation Modes, Communication Parameters, and Data Buffering/Log.
  • Page 63 OnCell G3100 Series Configuring Serial Port Operation Modes TCP alive check time (default=7 min): This field specifies how long the OnCell G3100 will wait for a response to “keep alive” packets before closing the TCP connection. The OnCell G3100 checks connection status by sending periodic “keep alive”...
  • Page 64 OnCell G3100 Series Configuring Serial Port Operation Modes Packet length (default=0): The Packet length setting refers to the maximum amount of data that is allowed to accumulate in the serial port buffer before sending. At the default of 0 for packet length, no maximum amount is specified and data in the buffer will be sent as specified by the delimiter settings or when the buffer is full.

  • Page 65: Reverse Real Com Mode

    OnCell G3100 Series Configuring Serial Port Operation Modes Reverse Real COM Mode TCP alive check time (default=7 min): This field specifies how long the OnCell G3100 will wait for a response to “keep alive” packets before closing the TCP connection. The OnCell G3100 checks the connection status by sending periodic “keep alive”...
  • Page 66 OnCell G3100 Series Configuring Serial Port Operation Modes Destination address 1 through 2 (default=None): Specifying an IP address allows the OnCell G3100 to connect actively to the remote host. At least one destination must be provided. TCP port (default=60950): This is the TCP port number assignment for the remote host/server. It is the port number that the OnCell G3100’s serial port uses to establish connections with a remote host/server.

  • Page 67: Rfc2217 Mode

    OnCell G3100 Series Configuring Serial Port Operation Modes • Strip Delimiter: Data in the buffer is first stripped of the delimiter before being transmitted. Force transmit (default=0 ms): This parameter defines how large a gap in serial communication the OnCell G3100 will allow before packing the serial data in its internal buffer for network transmission.
  • Page 68 OnCell G3100 Series Configuring Serial Port Operation Modes Packet length (default=0): The Packet length setting refers to the maximum amount of data that is allowed to accumulate in the serial port buffer before sending. At the default of 0 for packet length, no maximum amount is specified and data in the buffer will be sent as specified by the delimiter settings or when the buffer is full.

  • Page 69: Socket Applications

    OnCell G3100 Series Configuring Serial Port Operation Modes Socket Applications TCP Server Mode TCP alive check time (default=7 min): This field specifies how long the OnCell G3100 will wait for a response to “keep alive” packets before closing the TCP connection. The OnCell G3100 checks connection status by sending periodic “keep alive”...
  • Page 70 OnCell G3100 Series Configuring Serial Port Operation Modes Max connection (default=1): This field is used if you need to receive data from different hosts simultaneously. When set to 1, only a single host may open the TCP connection to the serial port. When set to 2, the specified number of hosts may open this port at the same time.

  • Page 71: Tcp Client Mode

    OnCell G3100 Series Configuring Serial Port Operation Modes As data is received through the serial port, it is stored by the OnCell G3100 in the internal buffer. The OnCell G3100 transmits data stored in the buffer via TCP/IP, but only when the internal buffer is full or as specified by the force transmit time.
  • Page 72 OnCell G3100 Series Configuring Serial Port Operation Modes TCP alive check time (default=7 min): This field specifies how long the OnCell G3100 will wait for a response to “keep alive” packets before closing the TCP connection. The OnCell G3100 checks connection status by sending periodic “keep alive”...
  • Page 73 OnCell G3100 Series Configuring Serial Port Operation Modes Designated local port 1 through 4 (default=5010 through 5013): Use these fields to specify the designated local ports. Connection control (default=Startup/None): This setting determines the parameters under which a TCP connection is established or disconnected. The different options are given in the following table. In general, both the Connect condition and Disconnect conditions are given.

  • Page 74: Udp Mode

    OnCell G3100 Series Configuring Serial Port Operation Modes The optimal force transmit time depends on your application, but it must be at least larger than one character interval within the specified baudrate. For example, assume that the serial port is set to 1200 bps, 8 data bits, 1 stop bit, and no parity.

  • Page 75: Ethernet Modem Mode

    OnCell G3100 Series Configuring Serial Port Operation Modes Delimiter 1 and Delimiter 2 (default=None): When Delimiter 1 is enabled, the serial port will clear the buffer and send the data to the Ethernet port when a specific character, entered in hex format, is received. A second delimiter character may be enabled and specified in the Delimiter 2 field, so that both characters act as the delimiter to indicate when data should be sent.
  • Page 76 OnCell G3100 Series Configuring Serial Port Operation Modes The OnCell G3100 accepts the AT command ATD <IP address:TCP port> (for example, ATD 192.168.127.1:4001) from the serial port and then requests a TCP connection from the remote Ethernet Modem or PC. Here IP address is the IP address of the remote Ethernet modem or PC, and TCP port is the TCP port number of the remote Ethernet modem or PC.
  • Page 77 OnCell G3100 Series Configuring Serial Port Operation Modes Disconnection request from remote site After the TCP connection has been shut down by the remote Ethernet modem or PC, the OnCell G3100 will send the NO CARRIER signal via the serial port and then return to command mode. AT Commands The OnCell G3100 supports the following common AT commands as used with a typical modem: AT command...

  • Page 78: Sms Tunnel Mode

    OnCell G3100 Series Configuring Serial Port Operation Modes S Registers S Register Description & default value Remarks Ring to auto-answer (default=0) Ring counter (always=0) no action applied Escape code character (default=43 ASCII “+”) Return character (default=13 ASCII) Line feed character (default=10 ASCII) Backspace character (default= 8 ASCII) Wait time for dial tone (always=2, unit=sec) no action applied...
  • Page 79 OnCell G3100 Series Configuring Serial Port Operation Modes SMS IN enable (default=Disable): To allow forwarding incoming short message to the OnCell G3100’s serial port as data. Auth type (default=none): To allow Caller ID Authentication Caller ID (1 through 4): Phone number should be specified. SMS OUT enable (default=Disable): To allow data received from the attached serial devices to be transmitted as short messages.

  • Page 80: Disabled Mode

    OnCell G3100 Series Configuring Serial Port Operation Modes As data is received through the serial port, it is stored by the OnCell G3100 in the internal buffer. The OnCell G3100 transmits data stored in the buffer via SMS, but only when the internal buffer is full or as specified by the force transmit time.

  • Page 81: Configuring The Cellular-Enabling Ethernet Device

    Configuring the Cellular-Enabling Ethernet Device In this chapter, we explain how to configure the Cellular-enabling Ethernet device. The following topics are covered in this chapter:  Host to OnCell via Cellular  OnCell to Host via Cellular...

  • Page 82: Host To Oncell Via Cellular

    OnCell G3100 Series Configuring the Cellular-Enabling Ethernet Device Host to OnCell via Cellular Go to System Management  Misc. Network Settings  Virtual Server Settings (default=Disable): This function allows remote users to access the Host or FTP services via a public IP address, and automatically redirects them to local servers in the LAN (Local Area Network).

  • Page 83: Oncell To Host Via Cellular

    OnCell G3100 Series Configuring the Cellular-Enabling Ethernet Device OnCell to Host via Cellular This section explains the configuration for when the Ethernet device acts as the Client. In order for the Ethernet device to send data to the host, it must set the OnCell as a gateway. This function will automatically detect the OnCell’s IP address by DHCP enable (default=enable).

  • Page 84: Configuring Virtual Modem Mode

    Configuring Virtual Modem Mode In this chapter, we explain how to configure Virtual Modem Mode for running AT command operating system devices. This operation mode is available for CSD, SMS and GPRS cellular services. Before starting configuration, you will need to select the appropriate cellular service because different cellular services have different software installation methods.

  • Page 85: Oncell G3100 Web Settings

    OnCell G3100 Series Configuring Virtual Modem Mode OnCell G3100 Web Settings From the left navigation panel, click Network Settings  GSM GPRS Settings to enable Virtual Modem Settings. The configuration items are described below: Installing Windows Driver Manager Windows Driver Manager should be installed for all cellular connections. 1.
  • Page 86 OnCell G3100 Series Configuring Virtual Modem Mode 3. Click Next to install program files to the default directory, or click Browse to select an alternate location. 4. The Setup window will display a summary of the installation options. Click Install to begin the installation. 10-3...
  • Page 87 OnCell G3100 Series Configuring Virtual Modem Mode 5. The setup window will report the progress of the installation. To change the installation settings, click Back and navigate to the previous screen. On Windows XP, the installer will display a message that the software has not passed Windows Logo testing, as shown below.

  • Page 88: Using Windows Driver Manager

    OnCell G3100 Series Configuring Virtual Modem Mode Using Windows Driver Manager After you install Windows Driver Manager, you can set up the OnCell G3100’s serial ports as remote COM ports for your PC host. Make sure that the serial port(s) on your OnCell G3100 are set to Real COM mode when mapping COM ports with Windows Driver Manager.

  • Page 89: Using Pcomm For Data Transmission

    OnCell G3100 Series Configuring Virtual Modem Mode 3. COM ports and their mappings will appear in blue until they are activated. Activating the COM ports saves the information in the host system registry and makes the COM port available for use. The host computer will not have the ability to use the COM port until the COM ports are activated.

  • Page 90: Csd Via At Command

    OnCell G3100 Series Configuring Virtual Modem Mode 3. The Property window opens automatically. Select the Communication Parameter tab, and then select the appropriate COM port for the connection (COM8 in this example). Configure the parameters for 115200, 8, N, 1 (115200 for Baudrate, 8 for Data Bits, None for Parity, and 1 for Stop Bits). CSD via AT command Caller dialing out Use ATD to Dial...

  • Page 91: Sms Via At Command

    OnCell G3100 Series Configuring Virtual Modem Mode Receiver answering a dial-in Answer w/ ATA SMS via AT command Example of a user sending a message Set 7-bits ASCII Send my message to “Phone No.” Enter SMS text and Press Ctrl+Z here to Send Receiver getting a message You’ve Got Mail! Show Me!

  • Page 92: Gprs Via At Command

    OnCell G3100 Series Configuring Virtual Modem Mode GPRS via AT command You can connect to the Internet (GPRS) via AT command. There are two commands you need to know: APN: AT+CGDCONT=1,”IP”,”<APN>” Dial: ATD*99***1# GPRS via Windows Dial-up Network 1. Go to Start  Settings  Control Panel  Phone and Modem Options. 2.
  • Page 93 OnCell G3100 Series Configuring Virtual Modem Mode 3. Checkmark the box for Don’t detect my modem; I will select it from a list. Click Next to continue. 4. When the Add Hardware Wizard page appears, select Have Disk. 5. Browse the Windows Driver Manager folder and select the vmodem_v1.0.2.inf file. Click OK to continue. 10-10...
  • Page 94 OnCell G3100 Series Configuring Virtual Modem Mode 6. The OnCell G3100 Modem (GPRS) model has been added to the list. Select it and then click Next. 7. Click on Selected ports. This COM port needs to be the COM port number mapped by Windows Driver Manager (not necessarily COM 1).
  • Page 95 OnCell G3100 Series Configuring Virtual Modem Mode 8. A setup window will pop up for hardware installation. To change the installation settings, click Back and navigate to the previous screen. In Windows XP, Setup will display the following message indicating that the software has not passed Windows Logo testing.
  • Page 96 OnCell G3100 Series Configuring Virtual Modem Mode 10. The Phone and Modem Options page will show up. Select and double click on the modem attached to the COM port (not necessarily COM 1) mapped by Window Driver Manager. 11. Click on the Advanced tab. Under Extra initialization commands, enter AT+CGDCONT=1, “IP”, “INTERNET”...
  • Page 97 OnCell G3100 Series Configuring Virtual Modem Mode 12. Click OK to close the page. The COM port number will be whichever one was mapped by Windows Driver Manager. 13. Go to Start  Settings  Network Connections  Create a new connection. 10-14...
  • Page 98 OnCell G3100 Series Configuring Virtual Modem Mode 14. Click on Next. 15. Select Connect to the Internet, and then click Next. 10-15...
  • Page 99 OnCell G3100 Series Configuring Virtual Modem Mode 16. Select Set up my connection manually, and then click Next. 17. Create your own ISP name. 10-16...
  • Page 100 OnCell G3100 Series Configuring Virtual Modem Mode 18. You must enter *99***1# as a phone number, and click Next. 19. Type the Internet Account Information. The information must match ISP Settings. Click Next to continue. 20. Click Finish to complete the new connection. 10-17...
  • Page 101 OnCell G3100 Series Configuring Virtual Modem Mode 21. Click Dial to connect to a cellular network. 10-18...

  • Page 102: Understanding And Configuring A Vpn

    Understanding and Configuring a VPN In this chapter, we explain how to configure a VPN with the OnCell 5000 web console. The following topics are covered in this chapter:  What Are VPNs?  OnCell VPN Specifications  OnCell VPN Web Console Settings ...

  • Page 103: What Are Vpns

    OnCell G3100 Series Understanding and Configuring a VPN What Are VPNs? Computers that are part of a VPN use a second, “virtual” IP address to connect to the Internet. Instead of running across a single private network, some of the links between nodes that are part of a VPN use open network connections or virtual circuits on a larger network, such as the Internet.

  • Page 104: Oncell Vpn Web Console Settings

    OnCell G3100 Series Understanding and Configuring a VPN OnCell VPN Web Console Settings From the left navigation panel, click Network Advanced Network Settings  VPN to configure the OnCell VPN Settings. The configuration items are shown below: Manual Key/ESP Configuration VPN tunnel (default = Disable): Enable or disable the VPN tunnel function.

  • Page 105: Local Network

    OnCell G3100 Series Understanding and Configuring a VPN Local Network Local subnet IP: Enter the local OnCell LAN subnet IP. Local subnet netmask: Enter the local OnCell LAN subnet netmask. Incoming Security Settings SPI: This sets the VPN manual key incoming SPI between 257 and 4294967295. Encryption mode: Select the incoming encryption mode.

  • Page 106: Isakmp/Psk

    OnCell G3100 Series Understanding and Configuring a VPN ISAKMP/PSK Configuration VPN tunnel (default = Disable): Enable or disable the VPN tunnel function. VPN tunnel mode: The type of VPN tunnel policy to be used; either manual key IPsec or ISAKMP with Pre-shared Keys (PSK).

  • Page 107: Isakmp (Key Management)

    OnCell G3100 Series Understanding and Configuring a VPN ISAKMP (Key Management) Pre-shared key (PSK): This sets the VPN ISAKMP Pre-Shared key settings. Perfect forward secrecy (PFS) (default = Disable): Enable or disable the Perfect Forward Secrecy. PFS is an additional security protocol. Local Identity Identity option: Select additional ID authentication requirements for the VPN using a specific IP Address, FQDN, or User FQDN settings.

  • Page 108: Vpn System Log Events And Error Codes

    OnCell G3100 Series Understanding and Configuring a VPN VPN system log events and error codes VPN system log Description VPN init. VPN tunnel initial VPN init. by packet VPN tunnel initial by packet driven VPN stop VPN tunnel stop VPN phase2 SA time out VPN tunnel phase 2 security association time out VPN time out VPN tunnel connect time out...

  • Page 109: Additional Serial Port Settings

    Additional Serial Port Settings In this chapter, we describe additional serial port settings for the OnCell G3100. The same configuration options are also available through the Telnet and serial consoles. The following topics are covered in this chapter:  Port Communication Parameters ...

  • Page 110: Port Communication Parameters

    OnCell G3100 Series Additional Serial Port Settings Port Communication Parameters Port alias: This optional field allows you to assign an alias to a port for easier identification. Serial Parameters ATTENTION The serial parameters for the each serial port on the OnCell G3100 should match the parameters used by the connected serial device.

  • Page 111: Port Data Buffering/Log

    OnCell G3100 Series Additional Serial Port Settings Port Data Buffering/Log The OnCell G3100 supports port buffering to prevent the loss of serial data when the Cellular or Ethernet connection is down. Port buffering can be used in Real COM, Secure Real COM, Reverse Real COM, Secure Reverse Real COM, RFC2217, TCP Server, Secure TCP Server, TCP Client, Secure TCP Client, and SMS Tunnel modes.

  • Page 112: System Management Settings

    System Management Settings In this chapter, we describe additional server settings on the OnCell G3100. The same configuration options are also available through the Telnet and serial console. The following topics are covered in this chapter:  Misc. Network Settings ...

  • Page 113: Misc. Network Settings

    OnCell G3100 Series System Management Settings Misc. Network Settings Accessible IP List The OnCell G3100 uses an IP address-based filtering method to control access to its serial ports. The Accessible IP list allows you restrict network access to the OnCell G3100. Access is controlled by IP address. When the accessible IP list is enabled, a host’s IP address must be listed in order to gain access to the OnCell G3100.

  • Page 114: Snmp Agent Settings

    OnCell G3100 Series System Management Settings SNMP Agent Settings SNMP: To enable the SNMP Agent function, select the Enable option, and enter a community name (e.g., public). Read community string (default=public): This is a text password mechanism that is used to weakly authenticate queries to agents of managed network devices.

  • Page 115: Ddns

    OnCell G3100 Series System Management Settings DDNS Please refer to Appendix C, Dynamic Domain Name Server, for information on setting up DDNS on your OnCell G3100. Host Table The Host Table can be used to simplify IP address entry in the OnCell G3100 console by assigning a Host Name to a Host IP Address.

  • Page 116: System Log Settings

    OnCell G3100 Series System Management Settings System Log Settings System Log Settings allows the administrator to customize which network events are logged by the OnCell G3100. Events are grouped into five categories, known as event groups, and the administrator selects which groups to log under Local Log.

  • Page 117: Virtual Server Settings

    OnCell G3100 Series System Management Settings Virtual Server Settings Virtual Server Settings (default=Disable): This function allows remote users to access the Host or FTP services via a public IP address, and automatically redirects them to local servers in the LAN (Local Area Network).

  • Page 118: Auto Warning Settings

    OnCell G3100 Series System Management Settings Auto Warning Settings Event Settings On the Event Settings page, you may configure how administrators are notified of certain system, network, configuration, power, Din, and cellular module events. Depending on the event, different options for automatic notification are available, as shown above.

  • Page 119: Serial Event Settings

    OnCell G3100 Series System Management Settings Cell. module fail: When the cellular module fails to function, the OnCell G3100 will attempt to send an e-mail, or trigger the digital output to inform users. Cell. close temperature range: When the temperature on the cellular module inside the OnCell G3100 is close to the upper or lower limit, the OnCell G3100 will attempt to send an e-mail, trigger the digital output, or send an SMS message to inform users.

  • Page 120: E-Mail Alert

    OnCell G3100 Series System Management Settings E-mail Alert The E-mail Alert settings determine how e-mail warnings are sent for system and serial port events. You may configure up to 4 e-mail addresses to receive automatic warnings. ATTENTION Consult your Network Administrator or ISP for the proper mail server settings. The Auto warning function may not work properly if it is not configured correctly.

  • Page 121: Sms Alert

    OnCell G3100 Series System Management Settings SMS Alert To phone number 1 to 4: This is the phone number to which the automatic warnings message will be sent. Encode format: SMS Data Format Text ASCII (7 bits) (default) 7 bits text format (160 bytes per packet) Customized SMS Customized SMS Settings: (default=Disable): Enable this function to allow customized SMS warnings and events to be sent to the phone numbers configured in the SMS Alert section.

  • Page 122: Remote Management

    OnCell G3100 Series System Management Settings Remote Management Remote SMS Control Remote SMS Control can be used when your OnCell devices are installed in locations that are not easy to access and where GPRS service is unstable. SMS service is one of the most reliable cellular services. Remote SMS control provides: 1) the ability to report the current status of the OnCell device to your SMS sender;...

  • Page 123: Manual Sms

    OnCell G3100 Series System Management Settings Manual SMS The manual SMS feature allows you to send text messages through the web console interface. Simply enter the SMS recipient’s phone number and the content of your message and click the “Send” button to send your text message.

  • Page 124: Maintenance

    OnCell G3100 Series System Management Settings Maintenance Console Settings On this screen, access to different OnCell G3100 configuration console options (HTTP, HTTPS, Telnet, SSH) from a LAN or WAN (through the cellular network) can be enabled or disabled. Please refer to Change Password later in this chapter for more information on passwords.

  • Page 125: Firmware Upgrade

    OnCell G3100 Series System Management Settings Firmware Upgrade The OnCell G3100’s firmware can be upgraded though the web console, serial console, or through OnCell Search Utility. If you have made any changes to your configuration, remember to save the configuration first before upgrading the firmware.

  • Page 126: Load Factory Defaults

    OnCell G3100 Series System Management Settings Load Factory Defaults This function will reset all of OnCell G3100’s settings to the factory default values. All previous settings including the console password will be lost. If you wish to keep the OnCell G3100 IP address, netmask, and other IP settings, make sure Keep IP settings is checked off before loading the factory defaults.

  • Page 127: Certificate

    OnCell G3100 Series System Management Settings Certificate Ethernet SSL Certificate Import SSL certificate is used to ensure the website you are accessing is the one you trust, and to encrypt the data transmitted between you and the website. The SSL certificate contains unique, authenticated information about the certificate owner.

  • Page 128: Serial Port Status

    OnCell G3100 Series System Management Settings Serial Port Status Go to Serial Port Status under Serial Status to view the current status of each serial port. Serial Port Status  Buffering monitors port buffering usage (bytes) of the serial port. A green dot indicates active, and a gray dot indicates inactive Serial Port Error Count Go to Serial Port Error Count under Serial Status to view the error count for each serial port.

  • Page 129: System Status

    OnCell G3100 Series System Management Settings System Status Serial Data Log Data logs for the serial port can be viewed in ASCII or HEX format. After selecting the serial port and format, you may click Select all to select the entire log if you wish to copy and paste the contents into a text file. System Log This option displays the system log.

  • Page 130: Dout State

    OnCell G3100 Series System Management Settings Dout State Dout State refers to the relay output status, which can be configured to change upon the occurrence of certain system events through Auto Warning Settings under System Management. You may click Dout State under System Status to display a list of events that may cause a change to the Dout state.

  • Page 131: Network Status

    OnCell G3100 Series System Management Settings Network Status Network Connections Go to Network Connections under System Status to view network connection information. Network Statistics Go to Network Statistics under System Status to view network statistics. Routing Go to Routing under System Status to display the routing information. 13-20...

  • Page 132: Dhcp Client List

    OnCell G3100 Series System Management Settings Possible flags include: U: route is up D: route is down G: use gateway +: default gateway T: static route H: target is a host DHCP Client List The DHCP Client List shows all the clients that require and have successfully received IP assignments. Check the Refresh box to refresh the list.

  • Page 133: Save Configuration

    OnCell G3100 Series System Management Settings Save Configuration Go to Save Configuration and then click Save to save your submitted configuration changes to the OnCell G3100’s flash memory. The configuration changes will be effective when the OnCell G3100 is restarted. If you do not save your changes before restarting, they will be discarded.

  • Page 134: Software Installation/Configuration

    Software Installation/Configuration The following topics are covered in this chapter:  Overview  Windows Driver Manager  Installing Windows Driver Manager  Using Windows Driver Manager  OnCell Search Utility  Installing OnCell Search Utility  Configuring OnCell Search Utility ...

  • Page 135: Overview

    OnCell G3100 Series Software Installation/Configuration Overview To ensure that installation and configuration are easy and straightforward, download the following software and utilities from www.moxa.com: Windows Driver Manager (for COM mapping), OnCell Search Utility (to broadcast search for all OnCell G3100’s accessible over the network), the OnCell G3100 User’s Manual, and the OnCell firmware upgrade utility.
  • Page 136 OnCell G3100 Series Software Installation/Configuration Click Next to install program files to the default directory, or click Browse to select an alternate location. 3. Click Next to install the program’s shortcuts in the appropriate Start Menu folder. 4. Click Next to proceed with the installation. The installer then displays a summary of the installation options. 14-3...
  • Page 137 OnCell G3100 Series Software Installation/Configuration 5. Click Install to begin the installation. The setup window will report the progress of the installation. To change the installation settings, click Back and navigate to the previous screen. On Windows XP, the installer will display a message that the software has not passed Windows Logo testing. This is shown as follows: Click Continue Anyway to finish the installation.

  • Page 138: Using Windows Driver Manager

    OnCell G3100 Series Software Installation/Configuration Using Windows Driver Manager After you install Windows Driver Manager, you can set up the OnCell G3100’s serial ports as remote COM ports for your PC host. Make sure that the serial port(s) on your OnCell G3100 are set to Real COM mode when mapping COM ports with Windows Driver Manager.
  • Page 139 OnCell G3100 Series Software Installation/Configuration Alternatively, for Real COM mode, you can select Input Manually and then manually enter the OnCell G3100’s IP Type. To do this, select LAN type, followed by 1st Data Port, and 1st Command Port for the COM ports that will be mapped to.
  • Page 140 OnCell G3100 Series Software Installation/Configuration You can also select Enable Auto IP Report. Refer to the MAC address on the device label and type in the MAC address in the MAC address line to update the IP address for this mapping entry automatically whenever the IP address of the OnCell G3100 is changed.
  • Page 141 OnCell G3100 Series Software Installation/Configuration 5. When using Windows XP, a message is displayed during the activation of each port, indicating that the software has not passed Windows Logo certification. Click Continue Anyway to proceed. 6. Ports that have been activated will appear in black. 14-8...
  • Page 142 OnCell G3100 Series Software Installation/Configuration For Reverse Real COM mode, you can select Input Manually and then manually enter the LAN MAC address for OnCell G3100. Click OK to proceed to the next step. To re-configure the settings for a particular serial port on the OnCell G3100, select the row corresponding to the desired port, and then click the Setting icon.
  • Page 143 OnCell G3100 Series Software Installation/Configuration 7. On the Basic Setting page, use the COM Number drop-down list to select a COM number to be assigned to the OnCell G3100’s serial port that is being configured. Note that ports that are “in use” will be labeled accordingly.
  • Page 144 OnCell G3100 Series Software Installation/Configuration FIFO If FIFO is Disabled, the OnCell G3100 will transmit one byte each time the Tx FIFO becomes empty, and an Rx interrupt will be generated for each incoming byte. This will result in a faster response and lower throughput.
  • Page 145 OnCell G3100 Series Software Installation/Configuration 9. The Serial Parameters tab in the following figure show the default settings when the OnCell G3100 is powered on. However, the program can redefine the serial parameters to different values after the program opens the port with Win32 API. 10.

  • Page 146: Oncell Search Utility

    OnCell G3100 Series Software Installation/Configuration 11. To save the configuration to a text file, select Export from the COM Mapping menu. You will then be able to import this configuration file to another host and use the same COM Mapping settings in the other host. OnCell Search Utility Installing OnCell Search Utility 1.
  • Page 147 OnCell G3100 Series Software Installation/Configuration 3. Click Next to install program files to the default directory, or click Browse to select an alternate location. 4. Click Next to select additional tasks. 5. Click Next to proceed with the installation. The installer then displays a summary of the installation options. 14-14...

  • Page 148: Configuring Oncell Search Utility

    OnCell G3100 Series Software Installation/Configuration 6. Click Install to begin the installation. The setup window will report the progress of the installation. To change the installation settings, click Back and navigate to the previous screen. 7. Click Finish to complete the installation of OnCell Search Utility. Configuring OnCell Search Utility The Broadcast Search function is used to locate all OnCell G3100 servers that are connected to the same LAN as your computer.
  • Page 149 OnCell G3100 Series Software Installation/Configuration 2. When the search is complete, all OnCell G3100 servers that were located will be displayed in the OnCell Search Utility window. Click Locate to cause the selected device to beep. 14-16...
  • Page 150 OnCell G3100 Series Software Installation/Configuration To modify the configuration of the highlighted OnCell G3100, click on the Console icon to open the web console. This will take you to the web console, where you can make all configuration changes. Please refer to Chapter 6, Using the Web Console, for information on how to use the web console.

  • Page 151: Moxa Oncell Linux Real Tty Driver

    OnCell G3100 Series Software Installation/Configuration 4. To change the configuration of the IP Address Report, click on the Settings icon to open the IP Location Settings. The Local UDP listen Port number should match the web console Auto IP Report Settings’ port number.

  • Page 152: Hardware Setup

    OnCell G3100 Series Software Installation/Configuration Hardware Setup Before proceeding with the software installation, make sure you have completed the hardware installation. Note that the default IP address for the LAN interface of OnCell G3100 is 192.168.127.254. NOTE After installing the hardware, you must configure the operation mode of the serial port on your OnCell G3100 to Real COM mode.

  • Page 153: Removing Mapped Tty Ports

    OnCell G3100 Series Software Installation/Configuration Mapping tty ports manually To map tty ports manually, you may execute mxaddsvr and manually specify the data and command ports, as in the following example: # cd /usr/lib/oncell_realtty/driver # ./mxaddsvr 192.168.3.4 1 4001 966 In this example, one tty port will be added, with IP 192.168.3.4, with data port 4001 and command port 966.

  • Page 154: Configuring The Unix Driver

    OnCell G3100 Series Software Installation/Configuration 3. Extract the source files from the tar file by executing the command: # tar xvf moxa_oncell_fixedtty.tar The following files will be extracted: README.TXT oncellttyd.c --- source code oncellttyd.cf --- an empty configuration file Makefile --- makefile VERSION.TXT --- fixed tty driver version...
  • Page 155 OnCell G3100 Series Software Installation/Configuration Adding an additional server 1. Modify the text file oncellttyd.cf to add an additional server. User may use vi or any text editor to modify the file. For more configuration information, look at the file oncellttyd.cf, which contains detailed descriptions of the various configuration parameters.

  • Page 156: Pinouts And Cable Wiring

    Pinouts and Cable Wiring The following topics are covered in this appendix:  Port Pinout Diagrams  RS-232 (male DB9) Pinouts  4W/2W RS-485/RS-422 (Terminal Block) Pinouts  Power Input and Relay Output Pinouts  Cable Wiring Diagrams  Serial Cables ...

  • Page 157: Port Pinout Diagrams

    OnCell G3100 Series Pinouts and Cable Wiring Port Pinout Diagrams RS-232 (male DB9) Pinouts RS-232 4W/2W RS-485/RS-422 (Terminal Block) Pinouts RS-422/RS-485 (4W) RS-485 (2W) TxD+(B) – TxD-(A) – RxD+(B) Data+(B) RxD-(A) Data-(A) Power Input and Relay Output Pinouts Name Function DC Power Input 1 DC Power Input 1 DC Power Input 2...

  • Page 158: Cable Wiring Diagrams

    OnCell G3100 Series Pinouts and Cable Wiring Cable Wiring Diagrams Serial Cables Female DB9 to Male DB9 Female DB9 to Male DB25...

  • Page 159: Pin Assignments For Db9 And Db25 Connectors

    OnCell G3100 Series Pinouts and Cable Wiring Pin Assignments for DB9 and DB25 Connectors Pin Assignments for DB9 Male and Female Connectors DB9 Male Connector DB9 Female Connector Pin Assignments for DB25 Male and Female Connectors DB25 Male Connector DB25 Female Connector...

  • Page 160: Rfc2217

    RFC2217 This appendix explains how to set up the environment to use RFC-2217 mode. RFC2217 defines general COM port control options based on the Telnet protocol and is used to allow the mapping of virtual COM ports to network ports. Any third party driver that supports RFC-2217 can be used to implement the virtual COM port on the OnCell G3100.

  • Page 161: Dynamic Domain Name Server

    Dynamic Domain Name Server This appendix explains how to use the OnCell G3100 with DDNS. When the OnCell G3100 receive its IP address from a DHCP (Dynamic Host Configuration Protocol) server, remote servers will be unable to access it using a fixed IP address.

  • Page 162: Configuration

    OnCell G3100 Series Dynamic Domain Name Server The above screenshot shows how DHCP can be set up to update the DNS. Currently, the OnCell G3100 supports DNS service as provided by DynDNS. For detailed information on this option, visit https://www.dyndns.com. Configuration DDNS (default=Disable): Use this field to enable or disable DDNS.

  • Page 163: Well-Known Port Numbers

    Well-Known Port Numbers In this appendix, we provide a list of well-known port numbers that may cause network problems if you set the OnCell G3100 to one of these ports. Refer to RFC 1700 for well-known port numbers or to the following introduction from the IANA: The port numbers are divided into three ranges: the Well Known Ports, the Registered Ports, and the Dynamic and/or Private Ports.
  • Page 164 OnCell G3100 Series Well Known Port Numbers UDP Socket Application Service Reserved Management Utility Echo Discard Active Users (systat) Daytime Any private printer server Resource Location Protocol Host name server (names server) Whois (nickname) Login Host Protocol (login) Domain Name Server (domain) Trivial Transfer Protocol (TETP) Gopher Protocol Finger Protocol...

  • Page 165: Auto Ip Report Protocol

    Auto IP Report Protocol OnCell Series provides several ways to configure Ethernet IP addresses. One of them is DHCP Client. When you set up the OnCell to use DHCP Client to configure Ethernet IP addresses, it will automatically send a DHCP request over the Ethernet to find the DHCP Server.
  • Page 166 OnCell G3100 Series Auto IP Report Protocol ID Value Description Length Note Signal Level Unsigned char RSSI Unsigned char AP ID & Hardware ID Mapping Table AP ID Hardware ID Product 0x80003501 0x3512 G3110 0x80003501 0x3552 G3150 0x80003610 0x3521 G3110-HSPA 0x80003610 0x3561 G3150-HSPA...
  • Page 167 GSM Alphabet Standard SMS can contain 160 characters. However, the characters typed must be part of the so-called 7-bit default alphabet as specified by GSM 3.38. As shown in the table below, this alphabet contains all ASCII characters and some accented characters. For example, u umlaut (ü) and e with grave (è) are in this set.
  • Page 168 OnCell G3100 Series GSM Alphabet Character Name Character ISO-8859-1 DEC 0x1B28 27 40 LEFT CURLY BRACKET 0x1B29 27 41 RIGHT CURLY BRACKET 0x1B2F 27 47 REVERSE SOLIDUS (BACKSLASH) 0x1B3C 27 60 LEFT SQUARE BRACKET 0x1B3D 27 61 TILDE 0x1B3E 27 62 RIGHT SQUARE BRACKET 0x1B40 27 64...
  • Page 169 OnCell G3100 Series GSM Alphabet Character Name Character ISO-8859-1 DEC 0x48 LATIN CAPITAL LETTER H 0x49 LATIN CAPITAL LETTER I 0x4A LATIN CAPITAL LETTER J 0x4B LATIN CAPITAL LETTER K 0x4C LATIN CAPITAL LETTER L 0x4D LATIN CAPITAL LETTER M 0x4E LATIN CAPITAL LETTER N 0x4F...

  • Page 170: Gsm Alphabet

    OnCell G3100 Series GSM Alphabet Character Name Character ISO-8859-1 DEC 0x7C LATIN SMALL LETTER O WITH DIAERESIS Ö 0x7D LATIN SMALL LETTER N WITH TILDE Ñ 0x7E LATIN SMALL LETTER U WITH DIAERESIS ü 0x7F LATIN SMALL LETTER A WITH GRAVE à...

  • Page 171: Default Settings

    Default Settings OnCell G3100 and OnCell Central Default Settings Setting Name Default Name Web Console Login Username Admin Password moxa Network Settings IP configuration Static IP address 192.168.127.254 Network 255.255.255.0 WINS function Enable LAN speed Auto GSM/GPRS Settings Type SIM PIN <blank>...
  • Page 172 OnCell G3100 Series Default Settings Designated Port 7010 to 7320 TCP alive Check Time Max connection Ignore jammed IP Disable Allow driver control Disable Secure Disable Connection goes down RTS/DTR always high Packet length Delimiter process Do Nothing Force transmit TCP Server Mode TCP port 4001...
  • Page 173 OnCell G3100 Series Default Settings Reset button Always Enable Virtual Server Settings Virtual Server Disable OnCell Central Server Server Disable Management information port 63201 Management configuration port 63202 Telnet port 63203 OP mode data port 1 63211 OP mode cmd port 1 63251 Service Forwarding Service forwarding...

This manual is also suitable for:

Oncell g3150Oncell g3110-hspaOncell g3150-hspa

Table of Contents
