Extech Instruments EX210 User Manual page 12

Function Range
Resistance
200
2 k
20 k
200 k
2 M
20 M
Temperature IR -20 to 0 C
0 to 93 C
93 to 230 C
-5 to 32 F
32 to 200°F
200 to 446°F
Enclosure Double molded
Diode Test Test current of 0.9mA maximum, open circuit voltage 2.8V DC typical
Continuity Threshold 20 to 50 , test current <1.5mA
Input Impedance 10M VDC/VAC
AC Response True rms (EX210T only)
ACV Bandwidth 40Hz to 1000Hz
IR Spectral response 6 to 16µm
IR Emissivity 0.95 fixed
IR distance ratio 4:1
Laser pointer Class 2 laser < 1mW power; Wavelength is 630 to 670nm
Display 2,000 count backlit liquid crystal display
Overrange indication "OL" is displayed
Auto Power Off 15 minutes (approximately)
Polarity Automatic (no indication for positive); Minus (-) sign for negative
Measurement Rate 2 times per second, nominal
Battery One 9 volt (NEDA 1604) battery
Fuses mA, µA ranges; 200mA 250V ceramic fast blow
'A' range; 10A 600V ceramic fast blow
Operating Temperature 14ºF to 122ºF (-10ºC to 40ºC)
o
Storage Temperature 14 F to 140
Operating Humidity Max 80% up to 31ºC (87ºF) decreasing linearly to 50% at 40ºC (104ºF)
Storage Humidity <80%
Operating Altitude 7000 ft (2000m) maximum
Weight 9.17 oz. (260 g)
Size 5.8x2.9x1.6" (147x76x42 mm)
Safety This meter is intended for origin of installation use and protected, against
the users, by double insulation per IEC/EN 61010-1:2001 and IEC/EN
61010-031:2002 to Category III 600V; Pollution Degree 2.
Approvals CE
Resolution
0.1 (0.8% reading + 5 digits)
0.001 k
0.01 k (0.8% reading + 2 digits)
0.1 k
0.001 M
(2.5% reading + 8 digits)
0.01 M
0.1 C/ F
o o o
F (-10 C to 60 C)
12 EX210_EX210T-en-US_v1.5 9/15
Accuracy
4 C
(2.0%rdg or 2 C)
(3.0%rdg or 3 C)
8 F
(2.0%rdg or 4 F)
(3.0%rdg or 6 F)
