"TO BE REMOVED FOR USE BY THE OCCUPANT."
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
Designer Microsilk
InsTallaTIOn, OPeraTIOn, anD MaInTenanCe
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the Bill of lading.
InsPeCTIOn
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
If the carton shows sign of damage, inspect the product
before accepting and describe the problem on the Bill of
Lading.
NOTe: Transportation and insurance from Jason's
factory are the buyer's responsibility.
Damage sustained in transit is the responsibility of the
carrier. If damage is discovered,
Owner's reCOrD
Dealer:
Date Purchased:
Date Installed:
Installer:
Jason International, Inc. • 501.771.4477
Owner's Manual
- airMasseur Baths
TM
the carrier must be immediately notified in writing with a
request for a representative to inspect the unit. Failure of
the carrier to respond should be reported to the seller and
carrier. Always file a freight claim promptly.
The installer is responsible for insuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer. ALL
WARRANTY CLAIMS ON ACRYLIC SURFACE DAMAGE
MUST BE MADE PRIOR TO INSTALLATION. Inspect
plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage keep the bath in the
carton until ready for installation.
Page 1 of 18
PlaCe serIal nuMBer CarD wITh
PrODuCT COnfIguraTIOn In ThIs BOx
Customer Service : 800.255.5766
Copyright © 2011 Jason International.
49-1012-800
Date 03/11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JASON Hydrotherapy Designer MicroSilk AirMasseur BY630
Summary of Contents for JASON Hydrotherapy Designer MicroSilk AirMasseur BY630
- Page 1 “TO BE REMOVED FOR USE BY THE OCCUPANT.” Jason International, Inc. 49-1012-800 8328 MacArthur Drive Date 03/11 North Little Rock, AR 72118 www.jasoninternational.com Owner’s Manual Designer Microsilk - airMasseur Baths InsTallaTIOn, OPeraTIOn, anD MaInTenanCe If the carton shows sign of damage, inspect the carrier must be immediately notified in writing with a request for a representative to inspect the unit.
-
Page 2: Installation Instructions
instALLAtiOn instRuctiOns EquipmEnt AccEss Jason offers an optional removable lateral skirt for all rect- angular baths. The skirts are available in matching acrylic In accordance with Building Codes, service access to all colors and provide convenient access to bath equipment therapy bath equipment, controls and electrical connections as well as an excellent finished appearance. -
Page 3: Installation
instALLAtiOn instRuctiOns (cont.) instALLAtiOn Jason offers a removable lateral skirt for most baths. each bath is provided with a cardboard bath well The skirts are available in matching acrylic colors and protector that should be kept in the unit during the provide convenient access to bath equipment as well installation and throughout the bathroom construction as an excellent finished appearance. - Page 4 instALLAtiOn instRuctiOns (cont.) mount should be attached firmly to the floor. Piping Mortar is required when the subfloor is not smooth and between the remote blower location and the bath can level; when additional sound insulation is desired; or when be insulated using a minimum of 1/2”...
- Page 5 instALLAtiOn instRuctiOns (cont.) CAUTION: Do not allow any dirt or debris to enter into Clamp the MicroSilk™ Suction Line to the MicroSilk™ the system plumbing or MicroSilk pump Assembly. Suction Barb using the clamp provided on the tubing. This could cause system blockage and equipment Assure the MicroSilk™...
- Page 6 instALLAtiOn instRuctiOns (cont.) ELEctRicAL specific code compliance prior to installation of the product. electrical power Supply: These instructions are written assuming 60Hz, 120v power supply. Special notations are also Standard/premier edition Control box (120v). included for 50Hz 240v pump, control equipment, and power MicroSilk generator unit is shipped separate from the bath.
- Page 7 instALLAtiOn instRuctiOns (cont.) feature. During installation, the control box bracket and controls must be positioned horizontally and located to permit access for inspection and servicing. The MicroSilk pump’s power cord will need to be plugged into the control box. Connect the pump’s male J+J plug to the female J+J plug of the control box’s load line.
-
Page 8: Water Testing
instALLAtiOn instRuctiOns (cont.) cLEAning wAtER tEsting Remove all loose debris. Construction plaster or Before finishing the installation, it is recommended that the excess grout can be removed with the use of a wood bath be water tested and the plumbing tested for leaks. (edge) trowel. - Page 9 micROsiLk -AiRmAssEuR cOntROL bOx cOnnEctiOns stAnDARD EDitiOn micROsiLk -AiRmAssEuR Jason’s Standard Edition MicroSIlk-AirMasseur system stAnDARD EDitiOn micROsiLk-AiRmAssEuR features the best in luxury bathing for the leisure bath industry. To assure that your bath functions properly, the MicroSilk pARts List and blower control boxes must be properly connected. MicroSilk Pump Unit MicroSilk Control Box Blower...
- Page 10 cOntROL bOx cOnnEctiOns (cont.) Figure 11 pREmiER EDitiOn micROsiLk- AiRmAssEuR pARts List MicroSilk Pump Unit MicroSilk Control Box Blower Blower Control Box Control Box Stand Water Level/Vacuum Sensor Keypad Keypad Cable LED Light Assembly LED Light Cable Ozone Sanitation Unit NOTe: This diagram (Figure 11) also applies to 50 hz, 240v equipment, controls, and power supply systems.
- Page 11 OpERAting instRuctiOn, FEAtuREs, AnD cOntROLs intRODuctiOn flow and pressure sensors to ensure proper pump operation; and a 20-minute timer. This manual contains all of the information needed for the proper installation and operation of your Jason MicroSilk- signature touchpad AirMasseur bath. The bath has been designed to give you years A main control touchpad mounted on the bath deck features a of relaxing trouble-free service, provided the unit is maintained LCD readout which alternately indicates the water temperature...
- Page 12 OpERAting instRuctiOns, FEAtuREs, AnD cOntROLs (cont.) NOTe: If the unit fails to operate, check the breaker panel Never operate the system without the pre-filter, internal to insure that the circuit breaker is on. Check the GFCI by filter screen and suction cover installed. testing and resetting it.
- Page 13 stAnDARD AnD pREmiER EDitiOn micROsiLk -AiRmAssEuR tOuchpAD Figure 13 blower On/Off, modes blower speeds microsilk On/Off LED Light blower speeds icon The Jason Standard and Premier Edition MicroSilk- AirMasseur touchpad is used to access all of the functions The Blower Speeds icon is used to increase or de- of the MicroSilk and blower controls.
-
Page 14: Customized Settings
signAtuRE EDitiOn micROsiLk -AiRmAssEuR tOuchpAD blower On/Off, modes blower speeds microsilk On/Off LED Light Off or On. Hold the key for more than two (2) seconds to The Jason Signature Edition MicroSilk-AirMasseur digital change modes. The Light icon should remain lit as long as touchpad is used to access all the functions of the two (2) the bath is connected to a power supply. -
Page 15: User Maintenance Instructions
usER mAintEnAncE instRuctiOns humiDity AiR hEAtER AnD AiR tEmpERAtuRE The air heater incorporated into the air blower is designed WARNING: AvOID hIGh hUMIDITy levelS IN yOUR to preheat the incoming air to body temperature, not to heat hOMe. MOlD, MIlDeW, FUNGI AND bACTeRIA WhICh the bath water. -
Page 16: Troubleshooting Guide
tROubLE shOOting guiDE If you believe the unit to be within the warranty period, you must contact Jason Customer Service: 1-800-255-5766 with the bath’s Product and Serial numbers before work is started. All warranty repairs must be authorized by Jason before work is started. FOR SERVICE, ALWAYS CONTACT YOUR DEALER OR AUTHORIZED SERVICE CENTER WARNING: Always turn off power at the main electrical service panel when servicing the bath. -
Page 17: Warranty
warranTY Jason International, Inc. (Jason), warrants its baths to be free from defects in workmanship and materials as provided in the enclosed warranty statement and warranty validation card. The pre-addressed warranty registration card MusT be filled out by the purchaser within thirty (30) days from purchase and mailed to Jason Inter- national, Inc., in order for limited warranty to become effective. - Page 18 Jason InternatIonal, Inc. 8328 MacArthur Drive • North Little Rock • Arkansas • 72118 www.jasoninternational.com Jason International, Inc. • 501.771.4477 Customer Service : 800.255.5766 Page 18 of 18 Copyright © 2011 Jason International.
