"TO BE REMOVED FOR USE BY THE OCCUPANT."
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
ma635P Designer airmasseur
INStallatION, OPERatION, aND maINtENaNCE
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the bill of lading.
INSPECtION
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
If the carton shows sign of damage, inspect the product
before accepting and describe the problem on the Bill of
Lading.
NOTe: Transportation and insurance from Jason's
factory are the buyer's responsibility.
Damage sustained in transit is the responsibility of
the carrier. If damage is discovered, the carrier must
be immediately notified in writing with a request for a
representative to inspect the unit. Failure of the carrier
to respond should be reported to the seller and carrier.
Always file a freight claim promptly.
The installer is responsible for insuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
OWNER'S RECORD
Dealer:
Date Purchased:
Date Installed:
Installer:
Jason International, Inc. • 501.771.4477
OWNER'S maNual
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer. ALL
WARRANTY CLAIMS ON ACRYLIC SURFACE DAMAGE
MUST BE MADE PRIOR TO INSTALLATION. Inspect
plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage keep the bath in the
carton until ready for installation.
EQuPmENt aCCESS
In accordance with Building Codes, service access
to all therapy bath equipment, controls and electrical
connections must be provided during installation (see
Table 1 - Specifications for minimum access size).
Insufficient access will hinder repair and maintenance.
Warranty Service
Page 1 of 16
baths
®
PlaCE SERIal NumbER CaRD WIth
PRODuCt CONfIguRatION IN thIS bOx
Customer Service : 800.255.5766
Copyright © 2011 Jason International.
49-1012-201
Date
04/11
