7
PREVENTATIVE & CORRECTIVE MAINTENANCE

7.1 CHANGING THE BATTERY

If the red signal lamp
(12/1) is lit continuously,
the battery must be
charged (see chapter
Continuous red light
5.2).
Open bow spring and remove discharged
battery. Insert charged battery and lock with bow
spring.
When changing the battery, the
new battery must only be inserted
after approx. five seconds to
ensure that the electronic system can reset to
the initial position. If the battery change is too
rapid, the red signal lamp lights up and the unit
remains blocked.
7.2 ADJUSTING WELDING TIME
The welding time can be infinitely adjusted with a
screwdriver (no 1), depending on strap quality
and dimension.
By turning the screw carefully clockwise, the
welding time will be longer, by turning
counterclockwise it will be shorter.
If straps are poorly welded, there is the risk that
the seal will tear. We advise you to
regularly check the strap seals.
1. Poorly welded seal (not welded over
the complete surface), welding time too short.
2. Good seal (the complete surface is cleanly
welded without excess material being forced
out sideways)
3. Poorly welded seal (excess material is
forced out sideways), welding time too long.
The welding time for PET straps is
longer than for PP straps.
Fig 12
Fig 13
Fig 14
10
