  • Page 1 VM-553 LCR IN-WALL SPEAKER O w n e r ’ s M a n u a l...
  • Page 2 THIS PAGE WAS LEFT BLANK ON PURPOSE...

  • Page 3: Speaker Placement

    The distance from the listening position to each speaker should be close to the distance that separates the two main speakers. The VM-553 has the unique ability to perform double-duty as both a center-channel speaker and as a main front left or right speaker for a surround sound system.
  • Page 4 Speaker Placement (continued) Pre-wiring the Speaker 1. Determine the location of the speakers. 2. Run speaker wire from the audio equipment location to the speaker location. Make sure you have plenty of wire at the speaker location to connect to the speaker, three feet is recommended.

  • Page 5: Painting The Speaker Grille

    Sound Contour Adjustment The VM-553 has two pivoting tweeters and a +3/0/-3 dB gain switch. To select a setting on the gain switch simply slide the switch up, down or position it to the middle to obtain the desired sound.

  • Page 6: Wiring Diagrams

    Wiring Diagrams VM-553 VM-553 VM-553 VM-553 VM-553 VM-553 VM-553 Back View VM-553 Back View Front Right Speaker Front Left Speaker Dual-channel Mode Wiring Diagram...
  • Page 7 Wiring Diagrams (continued) VM-553 VM-553 VM-553 VM-553 VM-553 VM-553 VM-553 VM-553 VM-553 VM-553 Back View VM-553 Back View VM-553 Back View Front Right Speaker Center Speaker Front Left Speaker Single-channel Mode Wiring Diagram...

  • Page 8: Break-In Period

    The result of break-in will be an increase in low frequency response, improved definition, and increased clarity and detail. Specifications Model: VM-553 Woofers: Three 5-1/4” (133mm) Aluminum Cone Tweeters: Dual 1” (25mm) Pivoting Aluminum Dome...

  • Page 9: Troubleshooting

    Warranty Your RBH Sound VM-553 LCR In-wall speaker is covered by a limited warranty against defects in materials and workmanship for a period of 25 (twenty-five) years from the original date of purchase. This warranty is provided by the authorized RBH Sound dealer where the speaker was purchased.
