- Page 1 2.1CH Soundbar with Built in Subwoofer Model: HS216FW USER MANUAL Before using the soundbar, please read this manual thoroughlyand retain it for future reference.
-
Page 2: Table Of Contents
Contents Important Safety Instructions DTS: X Operation Safety Neural:X / Virtual:X / DRC / Dialog Control Feature Warning OPTICAL / COAXIAL / HDMI Operation 16 What’s in the Box Setup Menu Identifying the Parts Main Unit Bluetooth Operation Remote Control Pair Bluetooth-enabled Devices Preparations Listen to Music from Bluetooth Device... -
Page 3: Important Safety Instructions
Important Safety Instructions third prong is provided for your safety. If the C AUTION provided plug does not fit into your outlet, RISK OF ELECTRIC SHOCK consult an electrician for replacement of the DO NOT OPEN obsolete outlet. 10 Protect the power cord from being walked on AVIS or pinched particularly at plugs, convenience RISQUE DE CHOC ÉLECTRIQUE... -
Page 4: Warning
Caution: For 5G Wi-Fi Device Use of controls or adjustments or performance The device for operation of procedures other than those described in the band 5150–5350 herein, may result in hazardous radiation MHz is only for indoor exposure or other unsafe operation. use to reduce the To reduce the risk of fire or electric shock, do not potential for harmful... - Page 5 Licensing Administrator, Inc. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Hisense is under license. Other trademarks and trade names are those of their respective owners. Supported input audio formats...
- Page 6 Supported HDMI video formats Color [HDMI Signal Resolution Frame rate 3D Color space depth Format] setting RGB 4:4:4 YCbCr 8 bit 4:4:4 50/59.94/60 Hz YCbCr 8/10/12 4:2:2 4096 x 2160p [enhanced format] YCbCr 10/12 3840 x 2160p 4:2:0 RGB 4:4:4 23.98/24/25/ 10/12 YCbCr...
-
Page 7: What's In The Box
What’s in the Box Remote Control / Main Unit User Manual AAA Batteries x 2 AC power Cord HDMI Cable Wall Bracket IR pass-through Cable • Power cord quantity and plug type vary by regions. • Images, illustrations and drawings shown on this User Manual are for reference only, actual product may vary in appearance. -
Page 8: Identifying The Parts
Identifying the Parts Main Unit O P T 10 11 12 13 14 1 Display Window 7 Screws Show the current status. Remove the screws then install the wall mounting screws into the back of the unit. 2 Remote Control Sensor Receive signal from the remote control. -
Page 9: Remote Control
Remote Control Switch the unit between ON and STANDBY mode. (SOURCE) Select the play function. Adjust the surround ON/OFF. 3 SURR (BT) Select the Bluetooth mode. Press and hold the (BT) button to activate the pairing function in Bluetooth mode or disconnect the existing paired Bluetooth device. -
Page 10: Placement And Mounting
Placement and Mounting Placement A If your TV is placed on a table, you can place the unit on the table directly in front of the TV stand, centered with the TV screen. B If your TV is attached to a wall, you can mount the unit on the wall directly below the TV screen. -
Page 11: Connections
Connections Connections Using HDMI to connect the soundbar, AV Dolby Atmos® equipment and TV: Dolby Atmos gives you amazing experience you Method 1: ARC (Audio Return Channel) have never before by overhead sound, and all the The ARC (Audio Return Channel) function allows richness, clarity, and power of Dolby sound. -
Page 12: Use The Optical Socket
Use the OPTICAL Socket Use the IR Socket Remove the protective cap of the OPTICAL If the Soundbar blocks the IR receiver of the socket, then connect an OPTICAL cable to the TV when placing directly in front of it, you TV’s OPTICAL OUT socket and the OPTICAL can connect the Soundbar and TV with the socket on the unit. -
Page 13: Connect To Wi-Fi (Wireless Operation)
Name at the end of the name list. Otherwise, it Connect to Wi-Fi (wireless follows the default name. 8 After connection, this product may perform operation) a software update. Upgrade to the latest software when it is your first time set up. The (For iOS and Android version) software upgrade may take several minutes. -
Page 14: Basic Operation
3 Launch the xxx Audio app powered by DTS Play-Fi. Follow the instructions in the app to connect this product to your Wi-Fi network. • After successful Wi-Fi connection, the Wi-Fi light indicator will stop pulsing and turn solid. Once you set up this product on your Wi-Fi network, you can control it from any smartphone or tablet on the same network. -
Page 15: Auto-Standby / Auto-Wake Feature
Auto-Standby / Auto-Wake Feature Adjust the Bass/Treble Level [Auto-Standby] Your soundbar has been • Press the TREBLE +/- buttons to increase or • programmed to enter Standby mode decrease the treble. automatically when no audio is detected for (treble+5 / treble–5) 15 minutes. -
Page 16: Dts: X Operation
3. Press the button or exit settings 10S. 4 Press the VOL +/– buttons to adjust the volume to your desired level. Tip: • Adjustment range: [00~200ms] Tip: • The audio delay setting is only valid for digital • The unit may not be able to decode all digital audio (eg HDMI IN, HDMI ARC, COAXIAL, audio formats from the input source. -
Page 17: Setup Menu
Setup Menu 1. During ON mode, press and hold the button for 3 seconds to open the menu. 2. Select the content with buttons. 3. Change the initial values for each of the settings with VOL +/- buttons. 4. Press the button to confirm your selection and exit the settings. -
Page 18: Bluetooth Operation
The display will show “BT PAIRING” USB Operation and you will hear "Pairing" from the unit. 3 Select “Hisense HS216FW” in the pairing list. After successful pairing, you will hear "Paired" from the unit, and the display panel shows “BT _ IN”. -
Page 19: Troubleshooting
To skip to the previous/next file, press the • Ensure the audio setting of the input source buttons on the remote control. (e.g. TV, game console, DVD player, etc.) is set to PCM or Dolby Digital mode while Tips: using digital (e.g. HDMI, OPTICAL, COAXIAL) •... -
Page 20: Specifications
Specifications HS216FW Model Name Power Supply AC100-240V~ 50/60Hz Power Consumption 30 W Standby Power < 0.5W USB port for playback 500mA USB Compatibility Hi-Speed USB (2.0) / FAT32 USB Playback support / file formats 32G (max) , WAV / WMA / MP3 / FLAC / DSD / ALAC... - Page 21 WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov. Réglement de la FCC (pour les clients américains) REMARQUE : FCC INFORMATION (for US customers) •...
- Page 22 HS216FW...
