5. INSTALLATION

IMPORTANT: Before installation and usage, read all the
The manufacturer declines all responsibility in the event of the installer failing to
observe all the accident prevention regulations in force, which are necessary for
normal use and the regular operation of the electric system.

5.1. ELECTRICAL CONNECTION

YOUR COOKER HOOD IS INTENDED FOR FITTED AND
PERMANENT INSTALLATION.
⚫ The power cable must be connected to the terminals marked L (live) and N
(neutral) in the hood and fixed with a cable clamp.
⚫ The cooker hood's power cable must be fitted upstream from the electrical
connection, using an omni-polar switch with a contact distance of at least 3mm.

5.2. BEFORE BEGINNING INSTALLATION

⚫ Check that the product purchased is of suitable size for the chosen
installation area.
⚫ Carry out all necessary masonry work prior to the fitting of the cooker hood.
⚫ Ensure that all electrical connections are carried out by a suitably qualified
person.
⚫ Before commencing installation of the cooker hood the grease filter should
be removed.
instructions and make sure that the voltage (V) and the
frequency (Hz) indicated on the rating plate are exactly the
same as the voltage and frequency in your home. The rating
plate can be found behind the grease filters.
10
