Altronix HubWayLD8CDS Passive UTP Transceiver Hub w/Integral Camera Power transmits UTP video,
RS422/RS485 data and power over a single CAT-5 or higher structured cable. Unit provides 8 camera channels
in a space saving 1U EIA 19" rack mount chassis which may be rack, wall or shelf mounted. Video transmission
range is up to 3000 ft. max. per channel. Units are compatible with AC and/or DC fixed or PTZ cameras when
utilizing Altronix HubWayAv, HubWayAv2, HubWayDv or HubWayDvi Video Balun/Combiners. In addition,
the unit features individually selectable 24VAC or 28VAC, PTC protected outputs with surge suppression. An
optional HubSat4D Passive UTP Transceiver Hub with Integral Camera Power unit can be used as an acces-
sory module to transmit video from up to 4 cameras over a single CAT-5 or higher structured cable back to the
HubWayLD8CDS. In addition, the HubSat4D units provide power to these cameras locally to eliminate the pos-
sibility of voltage drop associated with long cable runs.
Agency Listings:
• UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-04,
Audio, Video and Similar Equipment.
Input:
• 115VAC 60Hz, 1.5A.
Video:
• Eight (8) channels of video over twisted pair
up to a distance of 3000 ft.
• Eight (8) 75 ohm video outputs.
Data:
• RS422/RS485 data inputs.
Power:
• Individually selectable 24VAC or 28VAC
power outputs with OFF position.
• Unit provides up to 1A max. per channel not to
exceed a total of 5A (150VA) maximum current.
• PTCs are rated @ 1A per channel.
• Surge suppression.
HubWayLD82CDS
• HubWayLD8CDS with eight (8) UL Listed Accessory HubWayAv Video Balun/Combiners for
24VAC Cameras.
HubWayLD83CDS
• HubWayLD8CDS with eight (8) UL Listed Accessory HubWayDv Video Balun/Combiners for
12VDC Cameras.
WARNING: To reduce the risk of fire or electric shock do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes.
- 2 -
Overview:
HubWayLD8CDS Specifications:
Additional Models:
Visual Indicators:
• AC input power indicator.
• Eight (8) power LED indicators.
Features:
• Illuminated master power disconnect
circuit breaker with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Unit can be rack, wall or shelf mounted.
• 1U rack mount chassis for use in standard
EIA 19" rack.
Accessories:
• Video Balun/Combiners:
- HubWayAv:
- HubWayAv2:
- HubWayDv:
- HubWayDvi:
• Optional HubSat4D allows transmission of up to
four (4) video signals over a single CAT-5 or
higher structured cable.
for use with 24VAC cameras.
for use with 24VAC cameras.
for use with 12VDC cameras.
for use with non-isolated
12VDC cameras.
HubWayLD8CDS
