14.0 3200 Technical Specification

Power Supply Mains
Integral Charger
Auxiliary 24V output
Maximum Battery Size
Mains Fuse
Battery Fuse
Working Voltage
Current Consumption
Number of Detector Zones
Maximum Zone Cable Length
Maximum Zone Cable Capacitance
Maximum Zone Cable Resistance
Detector Circuit EOL Values
Maximum Quiescent Zone Load
Maximum Number of Detectors
Maximum Number of Devices
Manual Call Point Series Resistor Value
Number of Alarm Circuits
Alarm Circuit End Of Line Value
Maximum Alarm Load
Class Change Input
Remote Alarm Input
Global Fault Contacts
Global Fire Contacts
Temperature Range
Humidity Limit
Environment
Mounting
93-331-73 Issue 2
www.acornfiresecurity.com
230V AC. Nominal (+/-10%).
500mA switch mode, temperature compensated, 150mA battery charge
current. Batteries monitored for disconnection, failure and deep discharge.
24V dc, 100mA max, monitored for fuse failure. (Self-resetting Fuse)
2 x 12V 2.2Ah.
1 Amp HRC. ceramic 5 x 20mm.
1 Amp F 5 x 20mm.
20V to 30V dc.
11mA (24V dc. Supply, not in alarm, mains failed, buzzer slow pulse,
General and PSU fault light illuminated) + detector load.
2
500 Metres
0.27µF (measured with no end of line fitted)
15Ω per conductor.
Resistive (8.2kΩ) or capacitive (100µF/22Ω).
1.5mA per zone.
20 per zone (smoke or heat)
32 (Manual Call Points and Detectors) per zone
180Ω 5%
2 (open and short circuit monitored).
10kΩ 1/4W 5%.
150mA from each alarm output. Sounders must be polarised and
suppressed.
Activates alarm outputs when connected to 0V.
Activates alarm outputs, internal buzzer and general fire indicator when
connected to 0V.
Rated at 24V dc 1 Amp maximum
Rated at 24V dc 1 Amp maximum
0 to 40 degrees C.
85% Non-Condensing.
Meets IP30 if mounted in a dry position that does not exceed the temperature
and humidity limits given.
3 points surface mount.
Page 25 of 32 © Protec Fire Detection PLC 2013
