If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our website 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Kitchen Cart
Model # BJKC
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2020-10-09 Rev. 0001-A
1-866-942-5362
LOT NUMBER:
DATE PURCHASED: /
/
Advertisement
Related Manuals for Whalen BJKC
Summary of Contents for Whalen BJKC
- Page 1 LOT NUMBER: DATE PURCHASED: / Kitchen Cart Model # BJKC ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Kitchen Cart MODEL # BJKC MAXIMUM LOAD 45.4 kg / 100 lb.
- Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
- Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Section (Qty. 1) B-Bottom Shelf (Qty. 1) C- Partition Panel (Qty. 1) D- Side Frame (Qty. 2) E- Adjustable Shelf (Qty.
- Page 5 Assembly Instructions Left drawer Right drawer NOTE: DO NOT fully tighten all cam locks and bolts until you finish assembling all parts. Once assembled, go back and fully tighten all cam locks and bolts. 1. Unpack the unit and confirm that you have all the hardware and required parts. 2.
- Page 6 Assembly Instructions 5. Glue the Wood Dowels (3) into the inner holes on the Bottom Shelf (B) and Partition Panel (C) as shown. 6. Attach the Side Handles (G) to the Side Frames (D) using four 32 mm Bolts (5) with the Lock Washers (7) and Flat Washers (8).
- Page 7 Assembly Instructions 7. Attach one Side Frame (D) to the Top Section (A) with four 38 mm Bolts (6) and eight Washers (7 and 8). 8. Attach the Partition Panel (C) to the Top Section (A) by engaging two Cam Locks (1) Make sure that the cam locks point towards the right side of the unit.
- Page 8 Assembly Instructions 9. Align and attach the Bottom Shelf (B) to the Partition Panel (C) by engaging two Cam locks (1). 10. Continue to fasten the Bottom Shelf (B) to the Side Frame (D) using two 38 mm Bolts (6) with the Washers (7 and 8).
- Page 9 Assembly Instructions The nuts face inward 12. Fasten the Casters (F) to the joint between the Bottom Shelf (B) and Side Frames (D) with two 25 mm Bolts (4) and four Washers (7 and 8) per caster. 13. Ask for assistance to lift the previous assembly upright. 14.
- Page 10 Assembly Instructions Right drawer Left drawer Ball bearing cart FRONT FRONT Ball bearing cart 16. Now, go back and securely tighten all the cam locks and screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 17.
- Page 11 Assembly Instructions Wall Wall Long screw Metal bracket Wooden stud Short screw Wall Connector Steel cable Tools required: Phillips screwdriver, stud finder, pencil, tape measure, power drill and 1/8” drill bit. 18. Ask for assistance to position the assembled unit at the desired location against a wall. 19.
-
Page 12: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
