Grayson 58" Kitchen Cart
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
Or visit our website 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # BJ58KTC-WW
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2021-07-20
LOT NUMBER:
DATE PURCHASED: /
OR
breakfast bar configuration
Rev. 0001-A
Convenient drop leaf
/
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Whalen Grayson BJ58KTC-WW
Summary of Contents for Whalen Grayson BJ58KTC-WW
- Page 1 LOT NUMBER: DATE PURCHASED: / Grayson 58" Kitchen Cart Model # BJ58KTC-WW Convenient drop leaf breakfast bar configuration ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased.
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Grayson 58" Kitchen Cart MODEL: BJ58KTC-WW MAXIMUM LOAD 18.1 kg / 40 lb...
- Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Cabinet B- Spice Rack Panel A C- Spice Rack Panel B (Qty. 1) (Qty. 1) (Qty. 1) D- Rack Shelf E- Towel Bar Support A F- Towel Bar Support B...
- Page 4 Assembly Instructions NOTE: DO NOT fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make it easier during assembly of unit. Unpack the unit and confirm that you have all the hardware and required parts listed. Remove the spice rack, towel rack and Casters (I and J) from the bottom of the Cabinet (A).
- Page 5 Assembly Instructions Fasten the Casters (I and J) to the bottom corner blocks using the open wrench enclosed. Make sure that two Lockable Casters (I) are located at the same short end. Two Lockable Casters (I) make the cart freely stop at your will. Step on the brake to lock the Casters (I) in place for safe, stable use.
- Page 6 Assembly Instructions Ask for assistance to lift the assembled unit upright. Pay more attention to the drawers and drop-down leaf when standing the kitchen cart upright to prevent any accidents or damage to the unit. To remove the drawers for the following assembly, pull the drawers all the way out, then simultaneously push the plastic release lever of the ball bearing slide up on one side and down on the other side, and then pull the drawers completely out.
- Page 7 Assembly Instructions Fully insert the Wood Dowels (4) into the non-threaded holes on the Spice Rack Panels (B and C) and Towel Bar Supports (E and F).
- Page 8 Assembly Instructions Insert one Metal Tube (H) between the Towel Bar Supports (E and F). Using the inserted wood dowels as a guide, orient and attach the previous assembly to either side of the cabinet depending on your habits. The towel rack and spice rack are interchangeable. 10.
- Page 9 Assembly Instructions 12. Attach both Spice Rack Panels (B and C) to the Rack Shelf (D) and the other Metal Tube (H) as shown. 13. Using the inserted wood dowels as a guide, orient and attach the assembled rack to the cabinet side panel with four 32 mm Bolts (1) and four Washers (2 and 3).
- Page 10 Assembly Instructions 15. Place the drawer back by pushing the ball bearing cart all the way to the end of the slides (in both sides) and align the slide runners on the drawer with the slide tracks on the unit and push it carefully inside until it stops.
- Page 11 Assembly Instructions 17. The Adjustable Shelf (G) is pre-installed when shipping. If the shelf position is not to your liking, you will need to reposition the shelf by following the steps below. a. Look at the bottom view of Adjustable Shelf (G) and locate the Wood Screws holding the Shelf to the Shelf Supports.
- Page 12 Assembly Instructions 18. The countertop is accompanied with a drop leaf bar, you can expand it when you need more counter space or just easily drop it down to make it compact to maximize the space. WARNING DO NOT use the kitchen cart as a seating surface. ...
-
Page 13: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
