- Page 1 Quick Start Guide FRDM-K32L2A4S FREEDOM DEVELOPMENT PLATFORM...
- Page 2 Quick Start Guide GET TO KNOW THE FRDM-K32L2A4S Open SDA Reset K32L2A Push Button NC-19 20-PTA12 MK20DX128VFM5 J2 Header PTE19-17 18-PTA13 PTE18-15 16-AREF PTE17-13 14-GND SDA_PTD5-2 1-PTA5 PTE16-11 12-PTD1 RGB LED P3V3-4 3-PTA6 PTE6-9 10-PTD2 RST-6 5-PTA7 8-PTD2 PTE3-7 7-PTA14...
- Page 3 HOW TO GET STARTED Connect the FRDM-K32L2A4S board to a PC using the included mini-USB cable to USB connector “SDA USB.” A green power LED will blink when connect to PC to indicate USB connection established. Your FRDM- K32L2A4S board comes loaded with a “bubble...
- Page 4 WARRANTY under “Jump Start Your Design” Visit www.nxp.com/warranty for at nxp.com/FRDM-K32L2A4S. complete warranty information. www.nxp.com NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective owners. © 2019 NXP B.V.
